- Page 1 MICROPROFILING SYSTEM USER MANUAL...
- Page 2 Manual Copyright © 2023 · Unisense A/S Version November 2023...
-
Page 3: Table Of Contents
MICROPROFILING SYSTEM USER MANUAL UNISENSE A/S TABLE OF CONTENTS WARRANTY AND LIABILITY ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ ⸀ 6 CONGRATULATIONS WITH YOUR NEW PRODUCT! ⸀... -
Page 4: Warranty And Liability
Sensors and electrodes cannot be repaired ⸀ Equipment that is not covered by the warranty will, if possible, be repaired by Unisense A/S with appropriate charges paid by the customer ⸀ In case of return of equipment please contact us for return authorization ⸀... -
Page 5: Congratulations With Your New Product
• The seal is still intact. • The sensors are returned to Unisense for inspection within two weeks. • The sensors are correctly packed for return to Unisense, in accordance with the note included in the sensor box. -
Page 6: Overview
This manual gives an overview of the components of a Unisense profiling measurement set-up and how to connect them ⸀ For details on each component, please consult the individual manuals ⸀... -
Page 7: Microsensor Amplifiers
Amperometric microsensors (e ⸀ g ⸀ O S, H ) require either a versatile amplifier with adjustable polarization like the MultiChannel UniAmp fx-6 or fx-3 or a picoammeter with preset polarization like the O UniAmp ⸀ Potentiometric microsensors (e ⸀ g ⸀ pH and Redox) require a high-impedance millivoltmeter like the pH/Redox UniAmp or a MultiChannel UniAmp ⸀... -
Page 8: Manual Micromanipulators
(MM33) or two sensors (MM33-2), which facilitate reliable measurements and minimize the risk of breaking the microsensor ⸀ Mounted on a suitable laboratory stand (e ⸀ g ⸀ the Unisense LS), the micromanipulator provides a robust and precise tool for positioning microsensors with a z-axis precision of 10 microns ⸀... -
Page 9: Motorized Systems
MOTORIZED SYSTEMS For precision below 10 micron in the x-axis and for automated measurements, the MM33 (or MM33-2) can be mounted on a micromanipulator Motor Stage (MS-15), which is positioned via the PC data acquisition and motor control software (SensorTrace Suite) and a motor controller (MC-1, MC-2, or MC-3) ⸀... -
Page 10: Pecifications For Otor Ontroller
Mc-1, Mc-2, Mc-3 pecifications for otor ontroller • AC power supply adaptor: In: 100-240 VAC, 60-50 Hz, 1 ⸀4 A Out: 24VDC, 5A, 120 W max • Interface: USB • Con昀椀gured for: UniMotor Stage 15 cm (MS-15) • Operating temperature: 0-70°C (32 to 158°F) •... -
Page 11: Micromanipulator Stands
MICROMANIPULATOR STANDS The LS is a highly stable, corrosion-protected laboratory stand, which makes it possible to maintain the precision of the MM33, MM33-2 and the motorized micromanipulator stage ⸀ The in situ stand IS19 is a light-weight micromanipulator stand for field use in soft substrates such as mud or sediments ⸀... -
Page 12: Setting Up
Please consult separate manuals for the individual components for further details ⸀ 1 ⸀ Install the Unisense SensorTrace Suite software ⸀ 2 ⸀ Place the laboratory stand LS on a stable and smooth surface ⸀ Adjust the feet to prevent the stand from rocking ⸀ If the sample is... -
Page 13: Assembly Procedure 1D Motorized System
ASSEMBLY PROCEDURE 1D MOTORIZED SYSTEM 1 ⸀ Connect the Motor Stage, MS-15, to the UniMotor Controller, MC-1, and connect this to power ⸀ 2 ⸀ Use the hex key to separate the Tilting Base from the Micromanipu- lator itself (Fig ⸀ 1) ⸀ 3 ⸀ Mount the u-shaped spacer on the tilting base using the provided bolts (Fig ⸀... - Page 14 Fig. 4 Fig. 7 Fig. 5 Fig. 6 Fig. 9 Fig. 8...
-
Page 15: Assembly Procedure 2D Motorized System
ASSEMBLY PROCEDURE 2D MOTORIZED SYSTEM (BEFORE NOVEMBER 2023) 1 ⸀ Follow step 1 and 2 from the 1D assembly procedure ⸀ 2 ⸀ Mount one motor stage across the U-pro昀椀le (see picture). Move the stage plate completely down by turning the spindle joint with a 昀椀nger and mount two of the provided large screws in the two upper of the four central holes in the back of the stage as shown below ⸀... -
Page 16: Assembly Procedure 3D Motorized System
ASSEMBLY PROCEDURE 3D MOTORIZED SYSTEM (BEFORE NOVEMBER 2023) 1 ⸀ Mount the 3D arm on the vertical post of the Laboratory Stand ⸀ To do this, put the aluminium 昀椀nger bolts into the holes on the 3D arm and mount the elongated nuts by one to two rounds ⸀ Slide the nuts into the groove of the stand ⸀... - Page 17 5 ⸀ Mount the micromanipulator on the third MMS ⸀ First remove the tilting base from the micromanipulator, mount the square plate on the micromanipulator with 2 short 4 mm bolts ⸀ Then mount the square plate to the moving stage of the MMS with two long 4 mm bolts (see picture and Assembly procedure 1D motorized system above) ⸀...
-
Page 18: Storage And Maintenance
STORAGE AND MAINTENANCE Unisense recommends that the micromanipulator, lab stand, and in situ WARNING stand are protected with silicone spray before use ⸀ This will help to keep Do not spray the MMS with the surfaces clean and will prolong the lifetime of the unit ⸀...
