- Page 1 Instruction Manual Disc Harrow $0$=21( %%* Taurus 4000/3000 MG 778 Before starting to oper- DB 3070.1 (GB) 06.02 ate, please carefully Printed in Germany read and adhere to this operation manual and safety advice.
- Page 2 Copyright © 2002 AMAZONEN-WERKE H. DREYER GmbH & Co. KG D-49502 Hasbergen-Gaste Germany All rights reserved Taurus 4000/3000 DB3070 06.02...
-
Page 3: Table Of Contents
Contents Details about the machine ........................5 Range of application ........................5 Manufacturer..........................5 Conformity declaration........................ 5 On requesting after sales service and parts ................5 Type plate ........................... 5 Technical data ..........................6 1.6.1 Required on the hydraulic system/tractor ..............7 1.6.2 Details about noise level .................... - Page 4 Contents Cleaning, maintenance and repair ..................... 23 Hydraulic hoses ........................23 9.1.1 Exchange intervals ...................... 24 9.1.2 Marking ........................24 9.1.3 Please observe when fitting and removing..............24 Lubrication advice Taurus 4000/3000..................25 Special optional equipment ........................ 26 10.1 Options at random ........................26 10.1.1 Wheels 11.5/80 –...
-
Page 5: Details About The Machine
Details about the machine Type plate Details about the machine Type plate on the machine Range of application The disc harrow Taurus 4000/3000 is designed for the usual soil tillage operation in agriculture. Manufacturer %%* Bodenbearbeitungsgeräte Leipzig GmbH & Co. KG A company of the $0$=21(1 -Group Weidenweg 19 D-04249 Leipzig... -
Page 6: Technical Data
Details about the machine Technical data Taurus 3000 Taurus 4000 Nominal working width 3000 4000 Transport width, min. 2970 2950 Transport height 1310 1820 Transport length, depending on roller diameter 7005 7405 Ground clearance during transport, max. Permissible tilting to the side (transport position) Total weight, depending on execution max. -
Page 7: Required On The Hydraulic System/Tractor
Under "designated use" also the manufacturer’s pre- scribed operation, maintenance and repair conditions must be adhered to as well as the exclusive use of original AMAZONE-BBG-spare parts. Any damage resulting from arbitrary changes on the machine rule out the responsibility of the manufacturer. -
Page 8: Safety
Safety Safety This instruction manual contains basic advice, Identification of advice in this which has to be observed when mounting, operat- instruction manual ing and maintaining the machine. Thus, this in- struction manual has implicitly to be read by the operator before starting to operate and this book must be made available to him. -
Page 9: Warning Pictographs And Hint Symbols On The Machine
Safety Warning pictographs and hint symbols on the machine • The warning pictographs indicate dangerous MD 095 MD 078 points on the machine. Observing these picto- graphs means safety for all persons using this machine. The hint symbols always are linked to safety/warning symbols. -
Page 10: Safety Conscious Operation
Safety Safety conscious operation 18. Do not stand near rotating and swivelling parts of the machine. 19. Hydraulic folding frames must only be activated Besides the safety advice in this instruction manual after making sure no-one is standing near the additionally, the national, and generally valid opera- machine. -
Page 11: Brakes
Safety 2.6.2 Brakes cuits made of thermoplasts other guide lines may prevail. 8. Before starting to do repair work to the hydraulic 1. Check function of brake before travelling on system release the pressure and stop tractor public roads. engine. 2. -
Page 12: Transport On Public Roads
Safety Transport on public roads Please observe the following hints. They help to prevent accidents in pub- lic road traffic. 1. The permissible transport speed with unbraked axle load is 25 km/h. 2. When driving on public roads with lifted imple- ment the control lever has to be locked against unintended lowering. -
Page 13: Description Of Product
Description Description of product The disc harrow Taurus 4000/3000 (Fig. 3) is suit- able for the use in minimum soil tillage on medium and heavier soils. The X-Pack formation of the disc gangs is used to avoid any side forces on the tractor. (Fig. 4). Due to the staggered arrangement of the discs in the cen- tre the soil is moved across the entire working width. -
Page 14: On Receipt Of The Machine
On receipt of the machine On receipt of the machine Check that no damage has been caused in transit and that all parts are present. Otherwise no responsi- bility can be accepted by the manufacturer or the carrier. Check whether all parts (and options) listed up in the delivery note are present. -
Page 15: Mounting And Dismounting
Mounting and dismounting Mounting and dismounting Dismounting When mounting the soil tillage imple- ment to the tractor observe the safety Control unit for transport wheels in floating posi- advice. tion Attach implements as advised and only Lower implement until it rests on the discs/rollers to the attachment points provided. -
Page 16: Transport To The Field - Transport On Public Roads And Ways
Transport to the field – Transport on public roads and ways Transport to the field – Transport on public roads and ways When travelling on public roads and ways during transport to the field trac- tor and implement have to correspond to your national road transport and traffic rules. - Page 17 Transport to the field – Transport on public roads and ways Take the guard canvass from the retainer un- derneath the rear of the frame and attach to the disc gangs by using tension rubber bands (Fig. 6). When driving on public roads with lifted implement the control lever has to be locked against unintended lower- ing.
-
Page 18: Settings
Settings Settings Adjustment of the cutting angle The usual adjustment for the traction force, the op- erational speed and the operational efficiency is: 18º on the scalloped disc gangs in the front, 15º on the rear plain disc gangs. 7.1.1 Hydraulic adjustment of the cutting angle Proceed as follows to change the cutting angle ad-... -
Page 19: Working Depth
Settings Working depth The implement is in the raised position The height adjustable rear mounted roller provides the accurate depth guidance. The resetting and/or twisting of the so-called eccentric pins allow a nearly infinitely variable setting of the working depth. Reset the eccentric pin (Fig. -
Page 20: Setting The Scrapers On The Wedge Ring Roller
Settings Setting the scrapers on the wedge ring roller The scrapers have been set by the factory. In order to adapt the setting to the operational condi- tions, proceed as follows: Slacken the bolted connection (Fig. 10/1), Adjust the scraper on the slotted hole, Retighten the bolted connection. -
Page 21: Operation
Operation Operation Mount the disc harrow onto the tractor. Connect hydraulic system. Remove the guard canvass from the disc gangs, roll them up and deposit into the retainers pro- vided on the rear of the frame. Secure with ten- sioning rubber bands. Raise the transport wheels so that the implement rests on the support rollers.. -
Page 22: Function Faults
Operation Function faults Fault Cause Remedy Ridges in the centre Discs operate deeper at the rear than at Bring implement into level position the front Disc angle clearly smaller at the front Adapt disc angle than at the rear The following roller is not entirely folded Fold down roller completely down Ridges in the side areas... -
Page 23: Cleaning, Maintenance And Repair
Cleaning, maintenance and repair Cleaning, maintenance and re- pair Repair-, maintenance- and cleaning operations as well as the remedy of function faults should principally be conducted with drive engine stopped. Remove ignition key. When conducting electrical welding operations on the tractor or on the mounted implement remove cable from the generator and the battery. -
Page 24: Exchange Intervals
Cleaning, maintenance and repair 9.1.1 Exchange intervals The period of use of any hydraulic hose circuit should not exceed 6 years (including a possible storing period of two years maximum). 9.1.2 Marking Hydraulic hoses are marked as follows: Name of the manufacturer Date of production Maximum dynamic operational pressure 9.1.3... -
Page 25: Lubrication Advice Taurus 4000/3000
Cleaning, maintenance and repair Lubrication advice Taurus 4000/3000 Item Description Qty. Lubricating Lubricant Comment interval Drawbar carrying pin 50 Operational hours SWA 523 Grease nipple Lifting ram, axle, upper and lower 50 Operational hours SWA 523 Grease nipple joints Axle, axle pin, greased 50 Operational hours SWA 523 Grease nipple... -
Page 26: Special Optional Equipment
Special optional equipment Special optional equipment 10.1 Options at random 10.1.1 Wheels 11.5/80 – 15.3 10PR Order No. 78230308 10.1.2 Wheels 15.0/55 – 17 10PR ET –85 Order No. 78230312 10.1.3 Wheels 19.0/45-17 10 PR ET 70 Order No. 1201112 10.1.4 Cage roller SW 401-2/520 w. -
Page 27: Carrying Arms For Fitting Sw Or Kw, Rigid
Special optional equipment 10.1.10 Carrying arms for fitting SW or KW, rigid Order No. 78230309 10.2 Additional equipment 10.2.1 Hydraulic cutting angle adjustment T3000 Order No. 78230307 10.2.2 Hydraulic cutting angle adjustment T4000/2, double acting connections Order No. 78240401 10.2.3 Hydraulic cutting angle adjustment T4000/3, double acting connections Order No. - Page 28 Notes Taurus 4000/3000 DB3070 06.02...
- Page 29 Special optional equipment Taurus 4000/3000 DB3070 06.02...
- Page 30 Notes Taurus 4000/3000 DB3070 06.02...
- Page 31 H. DREYER GmbH & Co. KG Postfach 51 Tel.: ++49 (0) 54 05 50 1-0 Telefax: ++49 (0) 54 05 50 11 93 D-49202 Hasbergen-Gaste e-mail: amazone@amazone.de http:// www.amazone.de Germany Bodenbearbeitungsgeräte Leipzig GmbH& Co.KG Postfach 341152 Tel.: ++49 (0) 3 41 4 27 46 00...
