Vulcan-Hart ESB36 Specifications

Model ESB36 Shown
SPECIFICATIONS:
Medium duty electric elevated broiler, Vulcan-Hart Model No.
(ESB36) (ESB60) for use over Vulcan Model No. __________
electric range. Stainless steel front, sides, top and backsplash.
Broiler grid measures 25"w x 13"d and has three locking positions.
One gallon capacity drip pan located outside of the heat zone.
Two solid sheathed heating elements rated at 3 KW each, 6 KW
total input. Elements are controlled individually by separate
infinite heat control switches. Requires 208 volt or 240 volt, 1 or
3 phase power supply.
NSF listed. U L listed. U L listed to Canadian safety standards.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32250 (10-02)
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
ESB SERIES
MEDIUM DUTY ELECTRIC ELEVATED
SALAMANDER BROILERS
ESB36 For use with a 36" wide range.
ESB60 For use with a 60" wide range. Includes a EDD24
double deck high shelf with left end cap.
STANDARD FEATURES
Stainless steel front, sides, top and backsplash.
Two 3 KW solid sheathed heating elements, 6 KW total input.
Elements controlled individually by separate infinite heat
switches.
Three position broiler grid measures 25"w x 13"d.
208 or 240 volt, 1 or 3 phase.
One year limited parts and labor warranty.
OPTIONS
Stainless steel finishing back.
Second year extended limited parts and labor warranty
contract.
C.S.I. Section 11420
