- Page 1 Operator′s Manual EN p. 2 16-inch 10a Electric Fixed Line Trimmer CAUTION: To reduce the risk of injury, the user must read and understand the operator's manual before using this product.
-
Page 2: Table Of Contents
■ Assembly ................................9 ■ Operation ................................10 ■ Care and maintenance ............................11 ■ Troubleshooting ..............................12 ® ■ Lawnmaster warranty ............................13 ■ Illustrated parts list ............................14-15 INTRODUCTION This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have been given top priority in the design of this product making it easy to maintain and operate. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS ■ Never operate the line trimmer with damaged guards or without the guards in place. IMPORTANT! When using electric ■ Keep hands and feet away from the cutting means at gardening appliance, basic safety precautions should all times and especially when switching on the motor. - Page 4 IMPORTANT SAFETY INSTRUCTIONS MAINTENANCE WARNING! ■ After use, disconnect the machine from the mains - Cutting elements continue to rotate after the motor is and check for damage. switched off; ■ When not in use store the machine out of the reach - Keep extension cords away from cutting elements;...
-
Page 5: Symbols
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second) - Page 6 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates an imminently hazardous situation, which, if not avoided, will result DANGER in death or serious injury. Indicates a potentially hazardous situation, which, if not avoided, could result WARNING in death or serious injury.
-
Page 7: Features
FEATURES PRODUCT SPECIFICATIONS Voltage..............................120V~ 60Hz Current................................10 AMP Revolutions Per Minute ..........................6650 rpm Line Diameter ..........................0.08 inch (2 mm) Feed System ............................Fixed Line Cutting Width ..............................16 inch Weight ............................10.5 lbs (4.75 kg) NOTE: Always use .080" (2mm) round trimmer monofilament line as replacement line. CORD RETAINER KNOW YOUR LINE TRIMMER See Figure 1. -
Page 8: Electrical Information
ELECTRICAL INFORMATION WARNING! GROUNDING INSTRUCTIONS To avoid electrical hazards, fire hazards, or damage to the tool, use proper circuit IN THE EVENT OF A MALFUNCTION OR protection. Your line trimmer is wired at the factory for BREAKDOWN, grounding provides the path of least 120 v operation. -
Page 9: Assembly
ASSEMBLY UNPACKING WARNING! The line cut-off blade on the This product requires assembly. safety guard is sharp. Avoid contact with the blade. ■ Carefully remove the product and any accessories Failure to avoid contact can result in serious personal injury. Never use the line trimmer unless the guard is from the box. -
Page 10: Operation
OPERATION OPERATING THE TRIMMER WARNING! If any parts are damaged or See Figure 12. missing, do not operate this product until the parts are ■ Hold the line trimmer as shown. Keep a firm grip with replaced. Failure to heed this warning could result in both hands while in operation. -
Page 11: Care And Maintenance
CARE AND MAINTENANCE LINE REPLACEMENT Your line trimmer has been designed to operate over See Figure 15. a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper ■ Unplug the line trimmer. tool care and regular cleaning. ■... -
Page 12: Troubleshooting
TROUBLESHOOTING If your line trimmer does not seem to operate properly, WARNING! Before proceeding, switch off first consult the Troubleshooting Table below. and unplug. If the solution to your trimmer problem is not found in the Troubleshooting information, take the trimmer to a qualified service dealer for inspection and possible repair. -
Page 13: Lawnmaster ® Warranty
LAWNMASTER WARRANTY We take pride in producing a high quality, durable product. This Lawnmaster® product carries a limited two (2) year warranty against defects in workmanship and materials from date of purchase under normal household use. If product is to be used for commercial, industrial or rental use, a 30 day limited warranty will apply. -
Page 14: Illustrated Parts List
16-inch LINE TRIMMER – MODEL NUMBER GT1644 1201 The model number will be found on a label attached to the motor housing. - Page 15 16-inch LINE TRIMMER – MODEL NUMBER GT1644 1201 The model number will be found on a label attached to the motor housing. ITEM NO. PART NO. DESCRIPTION 121017101 Power Cord with Plug 121017102 Press Board 121017103 Motor Assembly 121017104 Motor Housing Assembly...
- Page 16 See this section for all of the figures referenced in the operator’s manual. Fig. 1 A - Cord Retainer B - Power Head C - Main Handle D - ON/OFF Switch Trigger E - Safety Switch F - Auxiliary Handle G - Coupler Tightening Knob H - Trimmer Shaft I - Safety Guard...
- Page 17 Fig. 2 Fig. 5 A - Wing Nut B - Tab C - Slot D - Safety Guard Fig. 3 E - Mounting Bracket Fig. 6 A - Auxiliary Handle Fig. 4 Fig. 7 A - Attachment Shaft B - Coupler Tightening Knob A - Bolt C - Positioning Hole B - Wing Nut...
- Page 18 Fig. 8 Fig. 9 A - Securing Clip B - Loop Fig. 10 Fig. 11 A - Plug A - Safety Switch B - Cord Retainer B - Switch Trigger Fig. 12 Fig. 13...
- Page 19 Fig. 14 Fig. 15 A - Trimming Head A - Trimming Line B - Backing Flange B - Button C - Spindle Lock Rod C - Trimming Head...
