INSTRUCTION MANUAL
AFSD101De
DECK MOUNTED AUTOMATIC
FOAM SOAP DISPENSER
R
Rev : B
Date : 29.06.2021
Advertisement
Table of Contents
Related Manuals for Rigel AFSD101De
Summary of Contents for Rigel AFSD101De
- Page 1 E-mail : sales.vn@rigel-group.com Website : www.rigel.com.vn AFSD101De CHINA RIGEL SANITARY SHANGHAI CO., LTD 锐佳洁具（上海）有限公司 | Sales & Marketing Office : 7th floor, Building 1 of Hongqiao Hub, 818 Shenchang Road, Shanghai ， 201107 Address E-mail : sales@rigel-group.com DECK MOUNTED AUTOMATIC Website : www.rigel.com.cn...
-
Page 2: Important Safety Information
SPARE PARTS and reference. Spare parts for all Rigel products are available for up to 10 years after the product's date of final manufacture. You should only purchase spare parts directly from our Customer Support Department, or from Rigel's Instructions accompanied by this symbol could lead to death or approved stockists or merchants to ensure authenticity and to maintain validity of your warranty. -
Page 3: Warranty
In the majority of installations, one or more of the above conditions will apply and it is Rigel will not be held liable for any incidental or consequential damages, including loss of profits or recommended that a 10mm² cable be installed. The minimum recommended cable size in ideal savings, arising from the use or misuse of the products. - Page 4 PART LIST & ILLUSTRATIONS (Foam) Soap Dispenser Operating Manual LED indicator showing which setting is currently under adjustment Description of setting Mode button: Setting selection Minus button: Setting decrement Plus button: Setting increment Adjusting for Air Volume, Soap Volume and Sensor Distance: To begin adjusting, touch on the Mode button once, a red LED will be lit up on the middle among the 5 LED indicators.
-
Page 5: Product Specifications
PRODUCT SPECIFICATIONS PRODUCT DIMENSIONS & INSTALLATION DIAGRAM Dimensions (faucet) 114(L) x Ø46(W) x 81(H)mm Material (faucet) Brass Finishing (faucet) Chrome Ø46 Power input 220-240V AC 50/60Hz Sensing range 100mm (default) Top view Soap viscosity <3 cPs (recommended) Discharge volume 0.5ml approx. / per dosage Discharge soap state Foam Finished wall... - Page 6 INSTALLATION GUIDE INSTALLATION GUIDE Mount the controller onto the bracket. Lock the controller by using the key as shown. Mount the spout from the top of the basin/ Note: countertop, fasten the washers, & nut from Improper connection may damage the product. Spout underneath the basin/ countertop.
