7 Adjustment

7.1. Matrix Table of Necessary Adjustment when Replacing Parts

The table shows necessary adjustment when replacing parts.
Replacement Part
DECORING UNIT
FILTER RING
L MOUNT
MOUNT RUBBER
REAR FRAME UNIT
SHADING FRAME
MOUNT CONTACT UNIT
1ST LENS FRAME UNIT
7TH LENS FRAME UNIT

7.2. Matrix Table of Necessary Adjustment when Cleaning

The table shows necessary adjustment when cleaning.
Cleaning Portion
Outside surface of the Lens
Inside surface of the Lens
1st Lens Frame Unit
Necessary Adjustment
Simple Resolution
Real Time Adjustment
- - -
- - -
- - -
- - -
- - -
- - -
- - -
◎
◎
Necessary Adjustment
Simple Resolution
Real Time Adjustment
- - -
◎
Cleanable area
25
Electrical
Adjustment
- - -
- - -
- - -
- - -
- - -
- - -
- - -
◎
◎
Electrical
Adjustment
- - -
- - -
7th Lens Frame Unit
