Instructions - Parts
Gun Service Kits
For use with all Graco/Gusmer spray guns (not included).
Part No. 296980
1 quart (0.95 liter) Solvent Cup
120 psi (0.83 MPa, 8.3 bar) Maximum Working Fluid Pressure
Part No. 296981
3 gallon (11.36 liters) Solvent Tank
90 psi (0.63 MPa, 6.3 bar) Maximum Working Fluid Pressure
1 Quart Solvent Cup
Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441
Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001
Important Safety Instructions
Read all warnings and instructions
in this manual. Save these instructions
3 Gallon Solvent Tank
311340A
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 296980 and is the answer not in the manual?

Questions and answers

Related Manuals for Graco 296980

Summary of Contents for Graco 296980

  • Page 1 Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions 1 Quart Solvent Cup 3 Gallon Solvent Tank Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001...

  • Page 2: Table Of Contents

    Grounding ......6 Part No. 296980 ....11 Pressure Relief Procedures .

  • Page 3: Warnings

    Warnings Warnings The following general warnings are for the setup, use, grounding, maintenance, and repair of this equipment. Additional, more specific warnings may be found throughout the body of this manual where applicable. Symbols appearing in the body of the manual refer to these general warnings. When these symbols appear throughout the manual, refer back to these pages for a description of the specific hazard.
  • Page 4 Graco/Gusmer replacement parts only. • Do not alter or modify equipment. • Use equipment only for its intended purpose. Call your Graco/Gusmer distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
  • Page 5 Warnings WARNING PRESSURIZED EQUIPMENT HAZARD Fluid from the gun/dispense valve, leaks, or ruptured components can splash in the eyes or on skin and cause serious injury. • Follow Pressure Relief Procedure in this manual, when you stop spraying and before cleaning, checking, or servicing equipment. •...

  • Page 6: Grounding

    Grounding Grounding Ground all solvent pails used when flushing, To maintain continuity when flushing or reliev- following your local code. Use only metal pails, ing pressure, hold a metal part of spray gun which are conductive, placed on a grounded firmly to side of grounded metal pail.

  • Page 7: Pressure Relief Procedures

    Pressure Relief Procedures Pressure Relief Procedures Relieve Fluid Pressure in 3. Disengage safety lock. 4. Trigger gun onto cardboard or into waste container to relieve pressure. Relieve pressure before cleaning or repairing gun. 1. Engage safety lock. CAUTION Air supply is required for gun actuation. Do not disconnect gun air supply until fluid pres- sure is relieved.

  • Page 8: Relieve Air Pressure

    Pressure Relief Procedures Relieve Air Pressure 3 Gallon Tank (Model 296981) 1 Quart Cup (Model 296980) Never transport tank while pressurized. Always relieve air pressure from tank before 1. Unscrew plastic cap (A) from air valve (B) removing cover. in fill cap (C).

  • Page 9: Operation

    Operation Operation Allow chemicals in spray gun to cool before vent. Retighten fill cap (C) snugly. cleaning. See F . 3. At least 1/3 of container must be empty so it can be pressurized with air. Flush Gun 1. Set safety stop to CLOSED (SERVICE). Do not overpressurize container.
  • Page 10 Operation 10. Release trigger and close manual valve on 13. Remove service block of gun service kit service block. from spray gun. 11. Repeat steps 8-10 for other side of gun. 14. Set safety to CLOSED (SERVICE). 12. After initial cleaning, remove air cap, PCD 15.

  • Page 11: Parts

    Parts Parts Part No. 296980 1 or 5 Ref. Part No.Description Qty. Ref. 297062 BLOCK, service Part No.Description Qty. 108047 SPRAYER, solvent flush 297066 FITTING, #4 JIC x 3/8 npt(f) 296979 SCREW, mounting, block, cou- 150136 CHUCK, air, 1/4 npt (not...

  • Page 12: Part No. 296981

    Parts Part No. 296981 2 or 7 Ref. Ref. Part No.Description Qty. Part No.Description Qty. 297072 BUSHING 297108 GASKET, cover (not shown) 297073 TANK, 3 gallon 296979 SCREW, mounting, block, 297074 FITTING, adaptor 297075 FITTING, adaptor, swivel coupling (2 pack) 297079 FITTING, #4 JIC x 1/4 npt(f) (GX-7 gun only) 297080 VALVE, needle...

  • Page 13: Technical Data

    Technical Data Technical Data Category Data Maximum Fluid Working Part No. 296980: 120 psi (0.83 MPa, 8.3 bar) Pressure Part No. 296981: 90 psi (0.63 MPa, 6.3 bar) Maximum Air Operating Part No. 296980: 120 psi (0.83 MPa, 8.3 bar) Pressure Part No.

  • Page 14: Graco Standard Warranty
