6. Component information

For any question on this chapter, please contact
product.management@fairphone.com.
Fairphone 5 contains the following key components with the following key data
points:
Component
Battery
Chipset
Display
Part details Vendor
Model: Kayo
F5AC1
QCM6490 Qualcomm
BF065GBM- BOE
TK0-7DP0
Key specs
Capacity : 4200 mAh
Nominal Voltage: 3.87 V
Cut off Voltage: 3.0 V
Charging Voltage: 4.45 V
Dimensions: 77.4 x 60.45 x 6.2 mm
DC Internal Impedance < 130 mΩ
Standard discharge: Continuous 0.2 to 3.0 V
Operational Charging Temperature Range: 0-60 ℃
Operational Discharge Temperature Range: -20 - 60 ℃
Recommend full charge & discharge cycle once every 3-6
months.
64 bit application processor
Low-power island (LPI): contains DSP and embedded AI
accelerator
Supports: GNSS, WLAN/BT, LTE, TD-SCDMA, WCDMA, GSM
5G NR and EN-DC.
Support camera interfaces: 3 x 14 bit ISP + 2x ISP-lite,
22+22+22 MP
Adreno 642L GPU
Qualcomm® Universal Bandwidth Compression (UBWC)
with camera, display, GPU, video, and compute DSP
FHD+, 10 bit DisplayPort, eight hardware layers,
improved HDR10+, and wide color Gamut, Qualcomm®
Low-Power
Picture Enhancement display feature, and Qualcomm®
True Palette
Display feature, VESA DSC 1.2
One 4-lane DSI DSC1.2, D-PHY 1.2, or C-PHY 1.0
6.46"
Outline: 68.15(W)*149.85(H)*0.038(T) mm
Active area: 67.7484(W)*149.445(H) mm
Number of dots: 1224(W)* 27000(H)
Frequency: 60/90 Hz
MIPI Differential Input: -0.3 to 1.35 V
Supply Voltage -(I/II/LV): -0.3 to 3.6/5.5/1.26 V
Logical input & output voltage: -0.3 to 0.3 V
ELVDD: 4.6 V (4.6 to 5.0 V)
ELVSS: -3.5 V (-6 to -0.8 V)
AVDD: 7.6 V (4.5 to 8 V)
VCI: 3.0 V (2.6 to 3.6 V)
VDDIO: 1.8 V (1.65 to 1.95 V)
DVDD: 1.2 V (1.1 to 1.25 V)
VGH: 3 V to 15 V
VGL: -15 V to -3 V
Operating Temp: -40 to 85 °C
