Summary of Contents for Dahua Technology DH-OTE100T-G
- Page 1 Fiber Optical Transceiver User's Manual ZHEJIANG DAHUA VISION TECHNOLOGY CO., LTD. V1.0.0...
-
Page 2: Foreword
(hereinafter referred to as "the device"). Read carefully before using the device, and keep the manual safe for future reference. Models DH-OTE100T-G, DH-OTE100R-G Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words... - Page 3 User's Manual We are not liable for losses incurred due to operating the product in ways that are not in ● compliance with the manual. The manual will be updated according to the latest laws and regulations of related jurisdictions. ●...
-
Page 4: Important Safeguards And Warnings
User's Manual Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage. Read carefully before using the device, and comply with the guidelines when using it. Transportation Requirements Transport the device under allowed humidity and temperature conditions. - Page 5 User's Manual Operation Requirements Do not disassemble the device without professional instruction. ● Operate the device within the rated range of power input and output. ● Make sure that the power supply is correct before use. ● Make sure the device is powered off before disassembling wires to avoid personal injury. ●...
-
Page 6: Table Of Contents
User's Manual Contents Foreword................................I Important Safeguards and Warnings......................III 1 Overview................................1 1.1 Introduction....................................1 1.2 Features......................................1 2 Installation............................... 2 2.1 Indicator Description.................................2 2.2 Specifications....................................3 Appendix 1 Cybersecurity Recommendations....................5... -
Page 7: Overview
User's Manual 1 Overview 1.1 Introduction The product can be used for a wide range of network access and networking requirements. As a transmission carrier for switches and devices, the sending end of the transceiver can transfer from electrical signal to optical signal, and then the receiving end can transfer from optical signal to electrical signal. -
Page 8: Installation
User's Manual 2 Installation 2.1 Indicator Description The panel diagram of the 10/100/1000 Mbps optical fiber transceiver is as follow. Figure 2-1 Indicator diagram Table 2-1 Indicator description Name Color Status Description Ethernet port works at 1000 Mbps. 1000 Mbps Green Flashes Optical port receives CRC error packet. -
Page 9: Specifications
User's Manual 2.2 Specifications Ports Figure 2-2 Port Table 2-2 Port description Description 1000 BASE-SC single mode single fiber port 10/100/1000 BASE-T Self-adaptive Ethernet RJ-45 port DC power port (5 V, 1 A) Working Environment Requirement Table 2-3 Environment requirements Name Description Working environment... - Page 10 Table 2-4 Electricity feature Model Name Description Input voltage 5 VDC DH-OTE100T-G/ DH- OTE100R-G Input current Dimensions and Package Dimensions for device: 105 mm × 70 mm × 26 mm (4.02'' × 2.76'' × 1.02'') ● Dimensions for package: 212 mm × 118 mm × 58 mm (8.35'' × 4.65'' × 2.28'') ●...
-
Page 11: Appendix 1 Cybersecurity Recommendations
User's Manual Appendix 1 Cybersecurity Recommendations Mandatory actions to be taken for basic device network security: 1. Use Strong Passwords Please refer to the following suggestions to set passwords: The length should not be less than 8 characters. ● Include at least two types of characters; character types include upper and lower case letters, ●... - Page 12 User's Manual According to business and management requirements, reasonably add users and assign a minimum set of permissions to them. 9. Disable Unnecessary Services and Choose Secure Modes If not needed, it is recommended to turn off some services such as SNMP, SMTP, UPnP, etc., to reduce risks.
