Shuttle P21WL01 User Manual

Hide thumbs Also See for P21WL01:
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
P21WL01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P21WL01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shuttle P21WL01

Summary of Contents for Shuttle P21WL01

  • Page 1 User Manual P21WL01...

  • Page 2: Notice

    Notice The illustrations in this user’s manual are for reference only. Actual product specifications may vary with territories. The information in this user’s manual is subject to change without notice. THE MANUFACTURER OR RESELLER SHALL NOT BE LIABLE FOR ERRORS OR OMISSIONS CONTAINED IN THIS MANUAL AND SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES, WHICH MAY RESULT FROM THE PERFORMANCE OR USE OF THIS MANUAL.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Notice ....................2 Preface .....................4 1.1 Regulations information ...........4 1.2 Safety instructions ............5 1.2 Consignes de sécurité............6 1.3 Notes for this manual ............7 1.4 Release history ..............7 Getting to know the basics ...............8 2.1 Product specification ............8 2.2 Product overview............10 Getting Started ................12 3.1 How to replace the 2.5"...

  • Page 4: Preface

    Preface 1.1 Regulations information • CE compliance This device is classed as a technical information equipment (ITE) in class A and is intended for use in commercial, transport, retailer, public, automation…field. • FCC rules This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Safety Instructions

    1.2 Safety instructions The following safety precautions will increase the life of the panel PC. Follow all Precautions and instructions. Do not place this device underneath heavy loads or in an unstable position. Do not use or expose this device around magnetic fields as magnetic interference may affect the performance of the device.

  • Page 6: Consignes De Sécurité

    1.2 Consignes de sécurité Les mesures de précaution suivantes servent à prolonger la durée de vie de l'ordinateur. Par conséquent, veuillez observer l'ensemble des mesures de précaution et des instructions. Ne pas poser d'objets lourds sur l'appareil ou ne pas le mettre pas dans une position instable. Ne pas exposer l'appareil à...

  • Page 7: Notes For This Manual

    1.3 Notes for this manual CAUTION! Important information that must be followed for safe operation.  NOTE: Information for special situations. 1.4 Release history Date Version Revision note 06.2020 First released...

  • Page 8: Getting To Know The Basics

    Getting to know the basics 2.1 Product specification This User’s Manual provides instructions and illustrations on how to operate this panel PC. It is recommended to read this manual carefully before using this panel PC. ・Physical characteristic Dimension 543 x 334 x 49.9 mm Weight 7.6~8 kg (net) (depend upon the actually shipping product)
  • Page 9 Webcam Built-in FHD webcam module ・Other M.2 E 2230 for Wlan card CAUTION: MODEL P21WL01 IS DESIGNED TO USE WITH THE DC INPUT: (19Vdc / 4.74A) ADAPTERS. CAUTION! Adapter watt should follow default setting or refer to rating label information.

  • Page 10: Product Overview

    2.2 Product overview Refer to the following illustration to identify the components on this side of the panel PC. Features and configurations vary by model.  NOTE: The product’s color, I/O port, indicator location, and specification will depend upon the actually shipping product.
  • Page 11 Webcam 21.5" FHD LCD display (True-Flat PCAP touch) Connector for external antenna (optional) SSD 2.5", 7mm Potential equalization pin (POAG) (optional) DVI-I (Single Link) (optional) COM 3 port (RS232/ RS422/ RS485) COM 2 port (RS232/ RS422/ RS485) Headphone / Line-out jack Microphone jack LAN (RJ45) ports : 1st LAN on MB, 2nd LAN via optional daughter board (support wake on LAN)

  • Page 12: Getting Started

    Getting Started Before using the rear I/O connectors, you need to remove the connector cover first. CAUTION: For safety reasons, please ensure that the power cord is disconnected before opening the case.  Follow the steps 1 → 2 to remove the connector cover. ...

  • Page 13: How To Replace The 2.5" Ssd

    3.1 How to replace the 2.5" SSD 1. If you want to replace the 2.5" SSD, unscrew the thumbscrew and two screws of the bracket and remove it. Old SSD 2. Unfasten the two screws (M3 x 4L) New SSD and remove old SSD.

  • Page 14: Wifi Antennas Installation (Optional)

    3.2 Optional installation of WLAN antennas (appropriate chassis version required) Take the two antennas out of the accessory box. Screw the antennas on to the appropriate connectors on the back panel. Make sure the antennas are aligned vertically or horizontally to achieve the best possible signal reception.

  • Page 15: Powering On The System

    3.3 Powering on the system Follow the steps (1-3) below to connect the AC adapter to the power jack (DC-IN). Press the power switch/button (4) to turn on the system. DC-IN Method 1: Depending on the model, press the power switch (a or b) to turn on the system.

  • Page 16: Potential Equalization (Optional)

    3.4 Potential equalization (optional) When potential equalization between the panel PC and other devices is required then connect the potential equalization pin (POAG) to the potential equalization terminal of the equipment. Potential equalization pin (POAG) Potential equalization cable (with 2 POAG-plugs) Other devices...

  • Page 17: Vesa Mounting To The Wall (Optional)

    3.5 VESA mounting to the wall (optional) The standard VESA openings show where an arm / wall mount kit which is available separately can be attached. Support VESA Mount 100 x 100 mm Screws M4x6L*4pcs  NOTE: The Panel PC can be wall-mounted using a VESA compatible 100 mm x 100 mm wall / arm bracket.

  • Page 18: How To Use Touch Panel

    3.6 How to use the Touch Panel Touch panel brings digital life for an easy touch experience. Experience the ease of managing your digital life with a few touches. Your touch functions like a mouse device and all you need to interact with the touch panel.

  • Page 19: Using The Vertical Stand (Optional)

    3.8 Using the Vertical Stand (optional) 1. Tighten the vertical stand securely with four screws (M4 x 12L) 2. Properly tighten the vertical stand with four screws (M4 x 10L) at the rear of the Panel PC. Screws M4 x 10L * 4pcs Screws M4 x 12L * 4pcs...

  • Page 20: Bios Setup

    BIOS Setup 4.1 About BIOS Setup The default BIOS (Basic Input/Output System) is already properly configured and optimized, there is normally no need to run this utility. 4.1.1 When to Use BIOS Setup ? You may need to run the BIOS Setup when: ・...
  • Page 21 ・ When OS support is Windows 10 : 1. Click the Start menu and select Settings. 2. Select Update and Security. 3. Click Recovery 4. Under Advanced startup, click Restart now. The system will restart and show the Windows 10 boot menu. 5.

This manual is also suitable for:

P21wl01-i5waP15wl01P21wl01-i3xa
