- Page 1 INSTALLATION MANUAL SPLIT SYSTEM Air Conditioner MODELS Floor Standing type Page No. INDOOR OUTDOOR Installation Manual IDU..01-23 English Installation Manual ODU ..24-60 FVFC71AV16 RZVF71BSV16 R-32 Split Type Air Conditioner FVFC100AV16 RZVF100BSV16 FVFC140AV16 RZMF140BSV16 CAREFULLY READ THESE INSTRUCTIONS BEFORE INSTALLATION.
-
Page 3: Table Of Contents
CONTENTS OUTLINE DIMENSIONS INDOOR UNIT..................2 ABOUT INSTALLATION SAFETY PRECAUTIONS..............3 BEFORE INSTALLATION ..............5 CHOOSING AN INSTALLATION SITE..........6 INDOOR UNIT INSTALLATION............7 ELECTRICAL WIRING CONNECTION..........13 REFRIGERANT PIPING WORK............14 ABOUT OPERATION CONTROLLER PART NAMES AND FUNCTIONS......18 OPERATING INSTRUCTION............ -
Page 4: Outline Dimensions
OUTLINE DIMENSION INDOOR UNIT [FVFC] All dimensions are in mm I J K Dimension Model 1850 100/140A 1850... -
Page 5: Safety Precautions
DAIKIN AIR CONDITIONER INSTALLATION MANUAL SAFETY PRECAUTIONS Read the precautions in this manual This appliance is filled with R32. carefully before operating the unit. • The precautions described herein are classifi ed as WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. - Page 6 WARNING • During pump down, stop the compressor before removing the refrigerant piping. If the compressor is still running and stop valve is open during pump-down, air will be sucked in when the refrigerant piping is removed, causing abnormal pressure in refrigeration cycle, which may result equipment damage and even injury. •...
-
Page 7: Before Installation
BEFORE INSTALLATION • Make sure to use R32 refrigerant before the installation work. Otherwise, the unit cannot operate normally. • Do not throw away the accessories required for installation until the installation is finished. • Be sure to instruct the customer how to properly operate the system (particularly the cleaning of air filter, operation method, temperature adjusting method) showing the attached operation and installation manual to the person. -
Page 8: Choosing An Installation Site
CHOOSING AN INSTALLATION SITE • Before choosing the installation site, obtain user approval. Wireless Remote Controller Indoor Unit • Do not expose the remote controller to direct sunlight The indoor unit should be sited in a place where: (this will hinder receiving signals from the indoor •... -
Page 9: Indoor Unit Installation
INDOOR UNIT INSTALLATION INSTALLATION DIAGRAM Indoor Unit Air Discharge Louver Signal Receiver Indicator Lights Air Intake Grille Air Filters (Inside Air Intake Grille) Wrap the insulated pipe with the finishing tape from bottom to top Air Intake Air Intake Outdoor Unit Air Discharge Figure A INSTALLATION CLEARANCE... - Page 10 INDOOR UNIT INSTALLATION Fixing Procedure • Fix the indoor unit by using embedded bolt, etc. to prevent falling down of the vertically-long shaped unit. 1. Detach the air intake grille. Remove the screw (Right, Left, total 2) holding the grille. Then, (1) lean the grille forward you, and (2) lift upward and out.
- Page 11 < Method 2 > Fix the indoor unit to the floor with Anchor bolts (to be locally procured) using fixing holes (x4) on the bottom frame. All dimensions are in mm 57, (79) 144, (202) <Bottom> Fixing Hole (x 4) Bottom frame * Dimension in ( ) for 40-60 models.
- Page 12 < In case of rear piping > 1. Open the holes on the rear panel. (Refer to Figure G). 2. Pass refrigerant pipes, drain pipes, and unit wiring through the hole on the rear panel. < In case of downward piping > 1.
- Page 13 Drain Piping Work 1. Rig the drain piping. Rig the drain line to ensure proper drainage. Also, observe the following to prevent leaks. Drain hose inside the unit Fan housing Bottom Frame Liquid pipe Anchor hose here Gas pipe Drain hose (Procure in field). Figure H Vinyl Tube (Pipe size 20mm).
- Page 14 Intake Grille Intake grille must be installed as step below. 1. Hook the air intake grille on the groove on the unit’s bottom frame in order of (1) -> (2). (Refer to Figure J). Figure J 2. Fit the grille stopper (front panel) into the groove on the air intake grille and lock the grille down in its original place by screw.
-
Page 15: Electrical Wiring Connection
ELECTRICAL WIRING CONNECTION • All wires must be firmly connected. • Make sure all the wire do not touch the refrigerant piping, compressor or any moving parts. • The connecting wire between the indoor unit and the outdoor unit must be clamped by using provided cord anchorage. •... -
Page 16: Refrigerant Piping Work
REFRIGERANT PIPING WORK • For the outdoor unit refrigerant piping, refer to the installation manual attached to the outdoor unit. FLARING THE PIPE END Cut the pipe end with a pipe cutter. (Cut exactly at Remove burrs with the cut surface facing downward so that right angles.) Remove burrs. - Page 17 WARNING Prior to installation, ensure risk of ignition is minimised and avoid working in confined space. Ensure adequate ventilation is available by opening windows or doors. • When flared joints are reused indoors, the flare part shall be re-fabricated. • Avoid installation of the air conditioner in a place where there is danger of exposure to continuously operating open flames (for example an operating electric heaters).
- Page 18 • Removal and evacuation When breaking into the refrigerant circuit to make repairs – or for any other purpose – conventional procedures shall be used. However, it is important that best practice is followed since flammability is a consideration. The following procedure shall be adhered to: •...
- Page 19 Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge are available.
-
Page 20: Controller Part Names And Functions
CONTROLLER PART NAMES AND FUNCTIONS Cooling Model COOL AUTO KEY LOCK SWING TURBO TIMER SWING MODE TURBO OPERATION MODE SELECTOR BUTTON TEMPERATURE SETTING BUTTON Press the button to select OPERATION MODE Press the button to decrease set temperature in °C or °F (Cool/Dry/Fan) TURBO BUTTON FAN SPEED CONTROL BUTTON... -
Page 21: Operating Instruction
OPERATING INSTRUCTION 1.1 MODE Button Press the MODE button to select the type of operating mode. • For cooling only unit, the available modes are: COOL ( ), DRY ( ) and FAN ( ). • For heat pump unit, the available modes are: AUTO ( ), COOL ( ), DRY ( ), FAN ( ) and HEAT ( ). •... -
Page 22: Indicator Lights
INDICATOR LIGHTS FAULT DIAGNOSIS When there is an abnormality happens, error code may show on display panel, refer to error code list below for fault diagnosis. ERROR CODE MEANING NORMAL RISK OF REFRIGERANT LEAKAGE INDOOR PCB ERROR DRAIN PUMP ABNORMAL ANTIFREEZE (COOLING)/HEAT EXCHANGER OVERHEAT (HEATING) INDOOR FAN MOTOR ABNORMAL ELECTRICAL AIR CLEANER ABNORMAL... -
Page 23: Troubleshooting
TROUBLESHOOTING For any enquiries on spare parts, please contact your authorized dealer. If any malfunction of the air conditioner unit is noted, immediately switch off the power supply to the unit. Check the following fault conditions and causes for some simple troubleshooting tips. Fault Causes / Action 1. -
Page 24: Overall Checking
OVERALL CHECKING • Ensure that The unit has been mounted solidly and rigid in position. The piping and connections are leak-proof after the charging. Proper wiring has been installed. • Drainage check pour some water into the left side of the drain pan (the drainage is at the right side of the unit). –... - Page 25 Lot 60334, Persiaran Bukit Rahman Putra 3, Taman Perindustrian Bukit Rahman Putra, Umeda Center Bldg., 2-4-12, Nakazaki-Nishi, 47000 Sungai Buloh, Selangor Darul Ehsan, Kita-ku, Osaka, 530-8323 Japan Malaysia. Tokyo offi ce: JR Shinagawa East Bldg., 2-18-1, Konan, Minato-ku, Tokyo, 108-0075 Japan http://www.daikin.com/global/...
- Page 26 RZVF71BSV16 RZVF71BSV16...
- Page 27 RZVF71BSV16...
- Page 28 RZVF71BSV16...
- Page 32 RZVF71BSV16...
- Page 33 RZVF71BSV16...
- Page 36 RZVF71BSV16 RZVF71BSV16...
- Page 38 RZVF71BSV16 RZVF71BSV16...
- Page 39 RZVF71BSV16 RZVF71BSV16...
- Page 42 RZVF100BSV16, RZMF140BSV16 UNPACKING & PACKING INSTRUCTION OF OUTDOOR UNIT Outdoor Unit Design Pressure RZVF100BSV16 High 4.15 RZMF140BSV16 3.30...
- Page 49 RZVF100BSV16 RZMF140BSV16 RZVF100BSV16 RZMF140BSV16...
- Page 52 RZVF100BSV16 RZMF140BSV16 RZVF100BSV16 RZMF140BSV16...
- Page 54 RZVF100BSV16, RZMF140BSV16...
- Page 55 RZVF100BSV16, RZMF140BSV16 RZVF100BSV16 RZMF140BSV16...
- Page 57 • When doing trial operation, it may take about 1 minute until the compressor begins to function, but this is not abnormal. • When using the system the first time after installation, even if heating operation is selected, cooling operation will take place for about 3 to 5 minutes.
- Page 58 (RZVF100BSV16, RZMF140BSV16)
- Page 60 RZVF100BSV16 RZMF140BSV16...
- Page 61 14. Unpacking & Packing of the Outdoor Unit 14-1 Unpacking ❷ ❶ Strap Starp Cutter Top corrugated cardboard sheet with d) Cardboard Box e) Bottom Skid Cut all the straps (a) from the unit • using strap cutter(b) as shown in Remove the Top corrugated •...
- Page 62 14-2 Packing ❷ ❶ Strap Starp Cutter Top corrugated cardboard sheet with d) Cardboard Box e) Bottom Skid f) Portable strap fixing machine Cover the unit with polythene product • cover, then pick the unit up and settle it down on the bottom skid(e) as shown in figure.
- Page 64 DAIKIN AIRCONDITIONING IND/A PVT. LTD. 12th Floor, Building No. 9, Tower A, DLF Cyber City, DLF Phase - Ill Gurgaon - 122002, Haryana (India) Tel: +91-0124-4555444 Fax: +91-0124-4555333 3P754599-1...
