Adjusting the Transport Lock

Attempting to engage the transport lock without proper adjustment may cause damage to the door
1. To verify the transport lock adjustment is working properly, the SolidStep 4.0 should be in the stored
position (Fig. 5). Make sure transport latch flanges (Figs. 5A, 6A, and 7A) are resting against the door
frame. If final adjustment is required, loosen the two bolts (Fig. 6B and Fig. 7B) on either side of the
adjustable transport lock. This allows for side-to-side adjustment in the latch mechanism.
A
Rev: 10.04.23
frame or step assembly.
A
Fig. 6
Fig. 5
B
B
Page 6
A
Fig. 7
B
B
A
CCD-0007740
