INSTRUCTION MANUAL
Ultrasonic Level Meters RIL330
Ultrasonic Level Meters RIL331
Before the first use of the level meter please read carefully the instructions provided in this User's Guide
and keep it for future use. The manufacturer reserves the right to make changes without previous notice.
RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RIL330 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Riels RIL330

  • Page 1 Before the first use of the level meter please read carefully the instructions provided in this User's Guide and keep it for future use. The manufacturer reserves the right to make changes without previous notice. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 2 RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 3: Table Of Contents

    16  . Use, manipulation and maintenance..................22 17  . General conditions and warranty ....................23 18  . Marking of labels ........................23 19  . Technical specifications ......................25 19  . Packing, shipping and storage ....................27 RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 4: Basic Description

    The output is then set on the basis of the surface height. The outputs of the RIL330 level meter are current 4 -20 mA, voltage 0 - 10 V and industrial line RS-485 with Modbus RTU communication. The output of the RIL331 sensor consists of a PNP transistor with an open collector and a two-state current switch 4 mA / 20 mA.
  • Page 5: Range Of Application

    G 2 ¼“. –_ –20–_ measurement range 0.5 m to 20 m, all-plastic case, source of PVDF, RIL330 mechanical connection with flange of aluminium alloy. 4 .  Dimensional drawing RIL330–_–01–_ RIL330–_–02–_ RIL330–_–06–_ RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 6: Installation And Putting Into Operation

    If the measured surface interferes with the dead zone, the device will not measure properly. *) To loosen the level meter can be used suitable wrench. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 7 RIL330–20 b > 150 mm a – neck height from source edge b – neck width m – dead zone Fig. 5: Installation of the device in the installation neck RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 8 (min. 200 mm) x – distance from the edge of the longest object c – maximum reach of the level meter Fig. 9: Minimum distance from close objects in the tank RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 9 • The cable gland as well as the connector shall be tightened sufficiently to prevent penetra- Fig. 15: Protection against tion of moisture. penetration of moisture RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 10: Electrical Connection

    7.1. Connection through ISO connector Valid for: RIL33_-_-_ _-_-_-G-_ The RIL330 level meter or RIL331 level sensor with a G type cable gland are connected to processing (display) units by means of a cable with an outer diameter of 6 to 8 mm (recommended...
  • Page 11: Connection Through M12 Connector

        The RIL330 level meter or ULS level sensor with a C type cable gland are connected to processing BN ( ) 1 (display) units by means of a cable with an outer diameter of 4 to 6 mm (recommended wire cross- section 0.5 to 0.75 mm...
  • Page 12: Connection Via Pg 11 Gland Or Gland For Protective Hoses

    BU ( ) 2 or gland for protective hoses Valid for: RIL330-_-_ _-_-_-B(H)-_ The RIL330 level meter or ULS sensor with a B or H type cable gland are connected to processing (display) units by means BN ( ) 1 a fixed of PVC cable 5 m long. PG 11 (B) or plastic bushings with a thread for protective hoses (H) can be used as a cable gland.
  • Page 13 Wiring operations shall only be carried out without voltage! Taking into account the potential occurrence of electrostatic discharge on non-conducting parts of the level meter, it is necessary to ground the flange of level meters RIL330–Xi– 20–F and sensors RIL331–Xi–20–F, located in an explosive atmosphere, using a ground terminal! It is also necessary to design and take measures to reduce the effects of static electricity to a safe level in the wiring.
  • Page 14: Control Elements

    RIL330 (or "OFF" for ULS) • open the setting mode connector DOWN button ("OFF") • for RIL330: direct setting of the value 4 mA (0 V) UP button ("ON") • for RIL331: setting limit for output disconnection locking screw •...
  • Page 15: Settings

    RS-485 industrial bus with the Modbus RTU protocol. A list of applicable registers is given in a separate appendix. To set up the level meter and collect measured data, you can use the software application „Basic SCADA level“, which is freely available to tecnico@riels.it Fig. 32: Default mode Fig.
  • Page 16 1. Disconnect the level meter from supply voltage (e.g. by disconnecting the connector). 2. While there is no supply voltage, apply the magnetic pen on one of the sensitive areas. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 17: Setting Procedure For Level Sensors Ril331

    1. Disconnect the sensor from supply voltage (e.g. by disconnecting the connector). 2. Press the OFF and ON buttons at the same time while supply voltage is disconnected. 3. Connect supply voltage while keeping the OFF and ON buttons pressed. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 18 If no button is pressed in the setting mode within 20 s, the measurement mode of the level meter will be restored. The newly set values will not be saved. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 19: Function And Status Indication

    – sensor output is connected (ON) Setting indication • slow flashing – setting indication for the disconnected status • fast flashing – setting indication for the connected status • 3 short flashes – setting confirmation RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 20: Protocol Modbus

    To set up the level meter and collect measured data, you can use the software application „Basic SCADA level“, which is freely available asking to tecnico@riels.it. Connecting the level meter to a peripheral device can be performed using a converter URC-485, see image 35.
  • Page 21: Correct Specification Examples

    IP67 coverage (type GAN-DADE 7A) with 5m cable (for current output and ISO type connector) • connector with IP67 coverage (type GAN-DAEE 7A) with 5m cable (for voltage output and ISO type connector) • converter URC-485 (for the Modbus version) RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 22: Safety, Protection, Compatibility And Explosion Proof

    The device shall be installed in a way to prevent mechanical damage to the sensor face. 16 .  Use, manipulation and maintenance The RIL330 level meter and the RIL331 sensor do not require any maintenance for operation.During operation, the operators of the technology are informed of the level height of the measured material through a connected display unit.
  • Page 23: General Conditions And Warranty

    Ambient temperature range: ta = -30 ... +_ _°C (Temperature range according to the type) Mark of non-explosive device: (applies to version RIL330-Xi) Variant: II _ G Ex ia II_ T5 _/_, see Classification of non-explosive design (applies to version RIL330-Xi) RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 24 Number of certificate of intrinsic safety: FTZÚ 09 ATEX 0119X (applies to version RIL330-Xi) Number of authorized person Protection class: IP67 or IP68; Compliance mark: supervising over the quality system: 1026 (applies to version RIL330-Xi) Electro-waste take-back system mark: Labels for device of the type...
  • Page 25: Technical Specifications

    From the last six measurements are taken out extreme values MAX and MIN, then the remaining four measurement was performed arithmetic average Dead zone = blind zone = blocking zone. RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 26 20 m RIL331-_–01 RIL331-_–02 RIL331-_–06 RIL331-_–10 RIL331-_–20 Connection level (ON) 0,45 m 0,90 m 2,7 m 4,5 m Disconnection level (OFF) 0,65 m 1,30 m 3,9 m 6,5 m 13 m RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
  • Page 27: Packing, Shipping And Storage

    Intrinsically safe isolating repeater (e.g. IRU–420). 19 .  Packing, shipping and storage The RIL330 or RIL331 device is packed in a cardboard packaging and the whole shipment is placed in a cardboard box. The cardboard box is suitably filled to prevent mechanical damage during transport.
  • Page 28 RIELS INSTRUMENTS SRL | ph. +39 049 8961771 | www.riels.it...
