MULTISPAN MDT-4310N Operating Manual page 3

Thumbwheel
Switch Position
1 0 0
2 0 0
3 0 0
4 0 0
5 0 0
6 0 0
7 0 0
8 0 0
9 0 0
0 0 0
MDT-4310N
Reset Key + Power ON
Time unit (Sec,Min,Hour)
Time Range:
(999,99.9,9.99 For Sec.)
(999,99.9 For Min.)
(999,99.9 For Hour.)
Operating Relay Mode (Delayed ON, Delayed OFF)
Counting Direction (UP Or DOWN)
Memory ( YES Or NO)
Auto Manual Mode
( IF Time = 0 then manual mode is selected
IF Time = 0 (Range 1 - 99 SEC.) then auto mode selected)
OUT
Press reset key to Save & Exit
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
(Press reset key to change parameter value)
Page-3
