MULTISPAN MDT-4310N Operating Manual page 2

Working
1).
Turn
on
the
instrument.
Set
time

through
thumbwheel
according







to
your
requirement.


2).
To
start
the
timer
with
power
on
short
terminal
no.
6
&
7.
3).
To
reset
timer,
press
front
reset
key
on
short
reset
terminal
no.
7
&
8.
Note :-
Parameter setting is done by using Left First thumb wheel and reset key.:
1. Left first thumbwheel is used to change parameter
2. Reset key is used to change parameter value
Parameter setting:
1. For parameter setting, Press reset key then power on, display will show by
default Parameter.
Connection Diagram
MDT-4310N
6
START
7
COM
RESET
8
9
10
Made in India
Page-2
1
L
~
100
270V AC
50/60 HZ
3VA
2
N
!
3
NC
www.multispanindia.com
4
COM
5
NO
