Patriot Lighting 343-4147 Quick Start Manual page 3

4.
Run the Landscape Wire (Not Included)
The landscape wire should run from the transformer to each light without being cut. Do not
run the landscape wire within 10 feet (3m) of a pool, spa or fountain. If the landscape wire is
too long, cut it with a cable cutter.
The landscape wire should be protected by routing it close to proximity of the light fixture
or next to a building, deck or fence. Use cable suitable for low voltage landscape lighting.
See chart below for recommended cable gauges.
*Suitable cable should be sized in accordance to the table, should be Type SPT-2W.
If you cannot find this cable at your local hardware or home improvement store then
please call customer service at 1-888-867-6095 or e-mail at
customerservice@sternohome.com to order the cable needed.
Combined wattage of all fixtures on line (in
Watts)
0-60
60-120
120-180
180-240
240-300
5.
Power up the transformer
• Plug the transformer into a GFCI electrical receptacle.
• The default mode for this transformer is «ON». At this
point, the fixtures will light up.
Wire Gage (0-75') Wire Gage (75'-150')
16 16
16 14
14 12
12 12
Not recommended
12
Transformer
Puissance total de toutes les fixtures sur la
Wire Gage (150'-250')
* llustration of fixtures is for example only.
14
12
12
Not recommended
Not recommended
Landscape wire to the fixtures.
Cable
Fixtures
Gauge du fil
ligne (en watts)
0-60
60-120
120-180
180-240
240-300
(0-75')
Gauge d
18
16
14
12
12
Pas rec
