  • Page 1 MULTISCAN® VS USER MANUAL laser marking system...
  • Page 2 This manual is copyrighted with all rights reserved. Under copyright laws, this manual may not be copied in whole or part or reproduced in any other media without the express permission of Luxinar Ltd. Permitted copies must carry the same proprietary and copyright notices as were affixed to the original. Under law, copying includes translation into another language.
  • Page 3 Tel.: +1 (0)586 291 2709 www.luxinar.com Warranty shipments, returns and adjustments Warranty claims must be made promptly and must be received by Luxinar Ltd during the applicable warranty period. Always identify the product, by both model number and serial number, when contacting Luxinar Aftersales.
  • Page 4 Luxinar Aftersales. Service and repair Servicing or calibration of the system can only be carried out by trained Luxinar service engineers or customers who have undertaken and passed a Luxinar approved service training course. Details of training...

  • Page 5: Table Of Contents

    Table of contents Preface Audience How to use this manual Admonitions Connector labels and signal names Marking and printing Safety................................1.1. General safety information......................... 1.2. Label locations.............................1 1.3. Labels..............................1.4. Maximum Permissible Exposure and Nominal Ocular Hazard Distance..........1.5. Decommissioning and disposal......................2.
  • Page 6 5.10. Fume extractor..........................5.11. Product detectors..........................28 Installation..............................6.1. Unpacking and preparation.......................29 6.1.1. Delivery check..........................6.1.2. Unpacking...........................29 6.2. Mechanical Installation........................6.3. Safety guarding..........................6.4. Scanning head positioning........................ 6.5. Lens focus adjustment........................6.6. Lens protection shroud........................6.6.1. Static marking..........................34 6.6.2. On-the-fly marking........................6.6.3.

  • Page 7: Preface Audience

    Preface Audience This manual should be read by all personnel who install or operate the MULTISCAN® VS laser. Important! Read this manual carefully before operating the power supply for the first time. Pay special attention to the Safety chapter. The MULTISCAN® VS is designed and sold for use in Original Equipment Manufacturer (OEM) systems and is not to be used as a stand-alone laser.
  • Page 8 Preface 906-0248-00 REV 3...

  • Page 9: Safety

    Luxinar Aftersales office or distributor for advice before proceeding. The installation, operation, maintenance and repair of this laser equipment must only be carried out by Luxinar service personnel or trained staff who have received correct instruction concerning the hazards associated with this particular equipment.
  • Page 10 Figure 1 - Main cabinet left and rear internal view Figure 2 - Main cabinet rear 1. Safety 906-0248-00 REV 3...

  • Page 11: Labels

    Figure 3 - Main cabinet cover Figure 4 - Scanhead Label — Read the instructions for use Emission warning indicator Figure 5 - Control panel 1.3. Labels Figure 6 - Label 1 — Non-interlocked panel 906-0248-00 REV 3 1. Safety...
  • Page 12 Figure 7 - Label 2 — Class 4 laser warning and specification Figure 8 - Label 4 — Laser hazard AVOID EXPOSURE INVISIBLE LASER RADIATION IS EMITTED FROM THE APERTURE Figure 9 - Label 5 — Laser aperture WARNING Disconnect the mains supply before removing this cover Figure 10 - Label 6 —...

  • Page 13: Maximum Permissible Exposure And Nominal Ocular Hazard Distance

    Model number Part number Serial number Input Revision Weight IP rating Figure 13 - Label 9 — Product identification and certification Figure 14 - Label 10 — Read the instructions for use 1.4. Maximum Permissible Exposure and Nominal Ocular Hazard Distance The Maximum Permissible Exposure (MPE) is the level of radiation to which, under normal circumstances, persons may be exposed without adverse effects.

  • Page 14: Decommissioning And Disposal

    SC10 SC14 Wavelength 10.6 10.25 10.6 10.25 10.6 10.25 (µm) — — — — — — — — — Note: Beam divergences given in the following table apply only when the marking system is operated with the complete beam delivery system attached. Table 3 - Beam divergence for MULTISCAN®...

  • Page 15: General Description

    2. General Description 2.1. System overview The MULTISCAN® VS is a vector laser marking system comprising: • a Radio Frequency (RF) excited, diffusion cooled, CO industrial slab laser • a high-speed galvanometer scanning head • a computer-based controller to position the laser beam on the workpiece •...

  • Page 16: Typical Production Line Installation

    To mark characters and images, the laser beam is deflected by high-speed galvanometer mirrors controlled by a computer. The computer also switches the laser beam on and off to form individual characters. The computer is connected to a galvanometer control board via a digital interface which sends varying X and Y co-ordinate deflection values to the vector scanning head.
  • Page 17 The MULTISCAN® VS is intended to be used for marking materials in an industrial environment. Use of the equipment for applications other than the intended one constitutes misuse and the laser manufacturer, Luxinar Ltd does not accept liability for any damage or injury howsoever caused or arising.
  • Page 18 User control panel Articulated beam delivery system Scanning head Main cabinet Laser beam stop Product detector Product detector retro-reflector Fume extractor 8A Flexible fume extraction hose and nozzle Compressed air source for lens shielding Shaft encoder Guarding Product to be marked Figure 17 - Typical conveyor-type marking installation Position the user control panel (1) so that it is easily accessible and visible to the operator.

  • Page 19: System Components

    degradation of mark quality and possible damage to the lens. This is prevented by blowing clean compressed air across the lens to form an air curtain. The compressed air is filtered and regulated down to an appropriate pressure by an air purification unit (9). To provide optical protection from the laser beam, guarding must be installed to protect the operator and other personnel.

  • Page 20: Scanning Head

    2.7. Scanning head The scanning head directs the laser beam to follow a programmed path on the product to be marked. The beam is directed by high-speed galvanometer mirrors within the head and is focussed by a final focus lens mounted on the output face of the head. Figure 19 - Typical scanning head A range of scanning heads and final focus lenses is available to match the size of the marking field and the code geometry.

  • Page 21: Specifications

    Table 4 - Control panel features Feature Description Power on key-switch Three-position switch for Off, On and Start (momentary). The key is removable only in the Off position. Shutter key-switch Two-position switch for Shutter open and Shutter closed. The key is removable only in the Shutter closed position.

  • Page 22: External Interface

    2.9.2. External interface Table 5 - External interface features Feature Description Product detector input Two independent inputs for NPN or PNP product detector, 24 or 12VDC Product detector output Two independent outputs for external monitoring of the product detector input signals Shaft encoder (tacho) Input for control of "on-the-fly"...

  • Page 23: External Materials

    2.9.5. External materials System unit Material Main cabinet 303 stainless steel with chrome-plated mild steel fittings Control unit frame Anodised aluminium Articulated arm Anodised aluminium Scanning head Anodised aluminium 2.9.6. Electrical supply Item Specification Mains electrical supply 230VAC ± 10%, single or bi-phase, 50/60Hz Power consumption 2.4kVA peak for continuous laser output.

  • Page 24: Optics Purge Gas

    Ambient temperature (°C) Table 9 - Coolant specification (water cooled systemns only) Item Specification Minimum flow rate (L/min) Recommended flow rate (L/min) Maximum pressure 6.0bar (88psi) Dissipation Required refrigeration capacity Coolant temperature 19–30°C (Optimum temperature 21°C. Allow 1% output power drop per 1°C increase.) Refer to document 906-0202-99 for more details.

  • Page 25: Laser Characteristics

    2.9.10. Laser characteristics The laser head is a model SR 10i sealed cavity, RF excited, diffusion cooled slab CO laser. Table 12 - Laser performance Wavelength 10.6µm 10.25µm 9.3µm Wavelength range (µm) 10.17–10.7 10.17–10.33 9.2–9.4 Rated output power (W) Typical shipment power Peak power (W) Pulse energy (mJ) 5–100...
  • Page 26 SC10 SC14 Field size for 300mm focal length lens — — 210x210mm Field size for 360mm focal length lens — — 250x250mm 2. General Description 906-0248-00 REV 3...

  • Page 27: Operation

    3. Operation WARNING Risk of injury to eyes and exposed skin Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser radiation exposure. This is a Class 4 (Class IV) Laser and the beam is invisible to the eye.

  • Page 28: Preliminary Checks

    Symbol Explanation Shutter key switch: shutter closed position Shutter key switch: shutter open position Laser emission indicator Maintenance fault indicator. This fault prevents the system from marking. System standby indicator (conforms to 417-IEC-5009a). When in standby mode, the system will not mark until the operation indicated on the control panel has been performed.

  • Page 29: Shut-Down

    Important! Changing to different screens (status, settings, edit, etc.) incurs an additional processor load that may interrupt repetitive mark cycles. If possible, avoid changing screens during marking. 3.3. Shut-down Stop the flow of products past the detector(s). On the control panel, press F5 for Shutdown, then press Yes to confirm shutdown. Turn the shutter key to the Shutter closed position.
  • Page 30 Products that trigger the detector(s) will be marked using the code displayed on the screen. • Interlock mode 1 Press the Print button. Press 'Yes' to confirm laser activation. • Interlock mode 2 This is an automatic restart mode. The system will restart and the laser will be re-enabled as soon as the interlock is reset.

  • Page 31: Diagnostics And Troubleshooting

    4. Diagnostics and troubleshooting Covers must be removed to view the following status indicators. 4.1. Status indicators The system fuse board has a number of indicator LEDs as detailed in the table below. Table 15 - Fuse board status indicators Indicator number Function 24V interlock voltage present...
  • Page 32 4. Diagnostics and troubleshooting 906-0248-00 REV 3...

  • Page 33: Routine Maintenance

    Every 18 months This should be carried out by a Luxinar trained engineer. Other marking system components will also require periodic inspection and cleaning. These include the compressed air supply filter, the product detectors and the fume extractor filters. The maintenance interval for these components will depend on how they are integrated into the marking station.

  • Page 34: Interlocks

    The pH value, conductivity and dissolved solids levels can be measured using a portable meter. The bacterial contamination level can be checked using a test kit. For more information and advice, contact Luxinar Aftersales. Pay particular attention to the instructions provided by the manufacturer of the water treatment kit: 5.

  • Page 35: Frost Protection

    Where the marked product materials are altered or changed after initial installation, then consult Luxinar Aftersales and the manufacturer of the fume extractor for details of any required change to the extraction filter specification.

  • Page 36: Product Detectors

    5.11. Product detectors Always ensure that the marking system is switched off and isolated from the mains supply before attempting any cleaning of the product detectors. Product detectors can be occasionally wiped with a clean damp cloth to remove contamination from the active surfaces.

  • Page 37: Installation

    If any damage to the packaging or change to the tilt or shock labels has occurred in transit, inform both Luxinar Ltd and the shipping company before taking any other action. Insurance company inspection of the damage may be necessary before proceeding with the unpacking of the equipment.
  • Page 38 Box lid Main box Polystyrene top cover Polystyrene head support Accessories box Polystyrene insert Polystyrene insert Ramp Box base Pallet base Figure 22 - Packaging components CAUTION Risk of damage to the articulated arm Never apply excessive torque or leverage to the articulated arm. Although it is ruggedly constructed, the articulated arm is precision aligned and any distortion of the arm may result in misalignment of the laser beam within the scanning head.

  • Page 39: Mechanical Installation

    Luxinar does not accept liability for any damage or injury howsoever caused or arising. Before securing any item in a permanent position, it is recommended that the components are first placed in their approximate final positions to check for best orientation and location.

  • Page 40: Safety Guarding

    350mm between the marking point and the beam stop position. For longer separations, contact Luxinar Aftersales for advice before proceeding. The centre position of the beam stop must be positioned exactly on the centre line of the beam entry aperture.

  • Page 41: Lens Focus Adjustment

    A clamp is used to couple the scanning head to the support assembly and is supplied in the accessories kit. Diagrams showing all dimensions are included in Appendix A. Contact Luxinar Aftersales for details of available options. Important! It is essential that the products are accurately positioned at the marking position to prevent variations in mark quality.

  • Page 42: Static Marking

    CAUTION Risk of optical damage in the laser head If the laser beam falls onto the stainless steel window frame, it can be reflected back through the lens to a focal position within the laser head. Test marking, and the laser power used during test marking, must be kept to a minimum to avoid potential optical damage within the head.
  • Page 43 The window may be cut out to suit a larger marking area, using the following guidelines: Scanhead shroud Size Window size, as supplied 30mm x 12mm Nominal window size to achieve a full marking area (mm) VS70 VS105 VS140 OFFSET WINDOW CENTRAL WI NDOW VS70 OFFS ET WINDOW...

  • Page 44: Cooling System

    6.7. Cooling system 6.7.1. Internal cooling circuit — all versions Before switching on the system, the internal coolant reservoir must be filled with approved coolant. The approved coolant is Flowcool-plus mono propylene glycol, available from: ICS Cool Energy ICS House Stephenson Road Calmore Industrial Estate Totton, Southampton BD4 3SA...

  • Page 45: External Cooling Circuit - Liquid-Cooled Version

    A dedicated electrical power connection is recommended for the MULTISCAN® VS. The voltage value is set during final test of the system, in accordance with the customer’s order. If the voltage setting is incorrect then contact Luxinar Aftersales for detailed advice. Possible mains supply settings are 200/208/220/230/240VAC, single phase or bi-phase configuration, 50/60Hz and a supply current of 16A peak (12A average).

  • Page 46: Auxiliary Transformer Tap Configurations

    Figure 28 - System rear panel The MULTISCAN® VS has a plug and socket mains power connection. Connect the supply cable to the terminals in the power socket supplied with the accessories kit. Terminal designations are clearly marked. Use the L/+ terminal to connect the live wire in a single-phase installation. After making the connections and re-assembling the socket, tighten the cable gland to ensure a water and dust-tight seal around the cable.

  • Page 47: Lens Protection Air Supply

    15 litres per minute, using 6mm (¼ inch) polyethylene tubing. The tubing connects to the ‘push in’ connector on the side of the shroud. An air purification kit meeting these requirements is available from Luxinar. This consists of a two-stage regulating filter unit. The first stage regulates the factory line pressure down to 2.4bar (20psig) and filters bulk material down to 5µm particle size.
  • Page 48 In a typical marking installation, the extraction unit can be sited next to the MULTISCAN® VS or underneath the production line. The extraction nozzle should be installed on the upstream side of the scanning head, close to the marking point. Contact Luxinar Aftersales for more information about extraction options.

  • Page 49: Transport And Recommissioning

    7. Transport and recommissioning 7.1. Internal cooling circuit draining — all versions Switch off the system at the mains isolator on the front panel of the main enclosure. Disconnect coolant return pipe from coolant bottle carefully as there will be slight leakage, fit 12mm bung in to bottle return.

  • Page 50: External Coolant Draining - Liquid Cooled Version

    7.2. External coolant draining — liquid cooled version Before transporting the marking system, completely drain the cooling system to prevent damage during shipping. Use clean compressed air, at a pressure of 2bar, to blow out all traces of coolant in the cooling system pipework.

  • Page 51: Interfacing

    8. Interfacing Interface connectors are provided to connect product sensor and interlock signals when integrating the system with the production line. Water and dust-tight cable glands are provided on the rear panel to allow interface cables to enter the system and be connected to the user interface board. 8.1.

  • Page 52: Interlocks And Security

    Com 2 RS232 Interlock Com 1 RS232 chain 2 Detector Memory status select Interlock Shutter chain 1 status System enable Good Extractor fault mark Detector 1 Maintenance required Detector 2 Shaft encoder Product reject Ready to print System fault Extractor enable System on Figure 31 - User interface PCB layout...
  • Page 53 Table 19 - Interlock circuit connections Type Function Interlock chain 1, J14 Emergency stop 1, volt-free output Emergency stop contact Emergency stop 1 return, volt-free output Emergency stop contact External emergency stop 1 input 24VDC interlock circuit External emergency stop 1, return input 24VDC interlock circuit Remote interlock 1 input 12/24VDC interlock circuit...
  • Page 54 Figure 33 - External interlocks — JP1 mode (DC and shutter power) 906-0149-00 Rev 4 © 2019 Luxinar Ltd Additional Illustrations A2-1 8. Interfacing 906-0248-00 REV 3...

  • Page 55: Shutter Status Output, J12

    8.3. Shutter status output, J12 The Shutter status output monitors the position of the internal safety shutter. The shutter remains closed until the system is ready to print. 906-0149-00 Rev 4 © 2019 Luxinar Ltd Additional Illustrations A2-2 906-0248-00 REV 3 8. Interfacing...

  • Page 56: Scanning Head To Main Enclosure Cable

    Table 20 - Shutter status output Type Function 12V @ 100mA 12V resettable fused source Open collector resettable fused, current Shutter closed, NPN mode limited input. 24V max. 100mA current source Shutter closed, PNP mode Open collector resettable fused, current Shutter open, NPN mode limited input.

  • Page 57: Dual Detector Installation

    Figure 37 - Detector edge selection Many types of product detectors are available and must be selected for reliable operation with the product or surface to be marked. For advice about selection of product detectors, contact Luxinar Aftersales. 8.5.1. Dual detector installation The MULTISCAN®...

  • Page 58: Tacho (Shaft Encoder) J19

    Production Line Direction Detector 1 Detector 2 Product being marked 3A Next product Mark position Figure 38 - Dual-detector configuration In a dual-detector configuration, the detectors are mounted so that a gate signal from detector 2 is followed by a mark trigger signal from detector 1 and before detector 2 sends a new gate signal when it detects the next product.

  • Page 59: Calculation Of Friction Wheel Diameter

    -Calculated wheel diameter = 166.67/π = 53mm (where π = 3.14159) Refer to the Software manual for more details concerning calculation of the shaft encoder (tacho) resolution. For more information about shaft encoder options contact Luxinar Aftersales. 8.7. Detector status output, J13 The Detector status output monitors the outputs of product detectors connected to the system.

  • Page 60: Com 1 Rs232, J7

    8.9. Com 1 RS232, J7 The RS232 interface allows a remote controller to interrogate and control the system. 1 DCD 1 DCD 2 RXD 2 RXD 3 TXD 3 TXD 4 DTR 4 DTR 5 GND 5 GND 6 DSR 6 DSR 7 RTS 7 RTS...
  • Page 61 Maintenance required, J17 The Maintenance required output becomes active when an error or fault condition is detected that is not serious enough to prevent marking but should be promptly corrected. It will be active for the following conditions: • VSWR fault •...
  • Page 62 • Product reject (J24) The Product reject output becomes active for 40ms when system errors are detected during the mark. It will become active for the following conditions ➢ VSWR fault ➢ RTC (Real-Time Control) fault (galvo overscan, mark incomplete) ➢...

  • Page 63: Remote Control Panel (Optional)

    Output 24V @ 1A User 24V source Ethernet Contact Luxinar Aftersales for further information. 8.11. Remote control panel (optional) Figure 40 - Control panel An optional remote control panel is available which allows the operator to control the marking system from a few meters further away from the marking station, for example outside a hazardous area where machines are operating.
  • Page 64 Attach the socket end of the umbilical to the control panel bulkhead connector and tighten the screw locks using the thumb screws. Fasten the control panel to a sturdy support or a wall using the mounting options on the rear of the housing.

  • Page 65: Software Configuration

    9. Software configuration 9.1. Service menu Software configuration options are available on the Service menu screen. Access to this screen is only possible using the Service password. To access the screen: From the home screen, Press F9 for Menu. The main menu displays. Press F4 for Login.
  • Page 66 Enter the Service password and press F10 for OK. The main menu displays with Setup activated. Press F2 for Setup. The setup menu displays. Press F2 for Service. The service menu displays. • Press F1 for PC options — see section •...

  • Page 67: Pc Options

    9.2. PC options Use the up/down arrows or function keys to select fields and values. Shutdown type Select the termination method for MVSEditor. Shutdown system on quit closes all operations so that the system can be switched off. Exit to Windows on quit closes MVSEditor and returns control to the operating system.

  • Page 68: Print Screen Configuration

    Press F10 for OK to save any changes and return to the previous menu. Cancel Press F5 for Cancel to discard any changes and return to the previous menu. 9.2.1. Print Screen Configuration The CTRL and ALT keys can be configured to perform various functions within the main Print screen. Disable Both keys are disabled and have no effect when pressed.

  • Page 69: Galvo Options

    9.3. Galvo options Use the up/down arrows or function keys to select fields and values. Head type This field selects the scanning head and lens combination fitted to the system. Any change to this setting requires a complete system restart for the change to take effect. Galvo scaling This field selects a scaling factor to adjust the overall mark size.

  • Page 70: Setup I/O

    9.4. Setup I/O Use the up/down arrows or function keys to select fields and values. Good Mark duration (ms) This field sets the duration of a Good Mark output signal in milliseconds. Bad Mark duration (ms) This field sets the duration of a Bad Mark output signal in milliseconds. Maximum Buffered Triggers This field sets the maximum number of trigger signals that can be buffered before initiating a mark.
  • Page 71 Shutter power monitor Note: This option is available as from MVSEditor V5.55.001. This option should only be enabled on systems that support shutter power monitoring. When enabled, this option activates additional safety monitoring. If the shutter is powered on in an incorrect safety state (e.g.
  • Page 72 9. Software configuration 906-0248-00 REV 3...

  • Page 73: Appendix A. Dimensional Drawings

    Appendix A. Dimensional drawings Figure 41 - Main cabinet Figure 42 - Remote control panel 906-0248-00 REV 3 A. Dimensional drawings...
  • Page 74 Figure 43 - Articulated arm orientations and reaches A. Dimensional drawings 906-0248-00 REV 3...
  • Page 75 Figure 44 - Scancube 7 906-0248-00 REV 3 A. Dimensional drawings...
  • Page 76 Figure 45 - Scancube 10 A. Dimensional drawings 906-0248-00 REV 3...
  • Page 77 Figure 46 - Scancube 14 906-0248-00 REV 3 A. Dimensional drawings...
  • Page 78 Figure 47 - Scancube 10 arm interface plates A. Dimensional drawings 906-0248-00 REV 3...
  • Page 79 Figure 48 - 7-knuckle articulated arm 906-0248-00 REV 3 A. Dimensional drawings...
  • Page 80 A. Dimensional drawings 906-0248-00 REV 3...

  • Page 81: Appendix B. Calculations For Laser Safety Glasses Selection

    Appendix B. Calculations for laser safety glasses selection The Maximum Permissible Exposure (MPE) is the level of radiation to which, under normal circumstances, persons may be exposed without adverse effects. The MPE represents the maximum level to which the eye or skin can be exposed without consequential injury and is related to the wavelength of the laser radiation, the pulse duration or exposure duration, and the tissue at risk.
  • Page 82 Scanning head Final lens focal Beam NOHD (m) Irradiance Radiant Optical density aperture (mm) length (mm) diameter (mm) exposure 0.16 2.8x10 1.9x10 0.25 1.2x10 8.0x10 0.34 6.5x10 4.3x10 0.43 4.1x10 2.7x10 0.53 2.7x10 1.8x10 0.65 1.8x10 1.2x10 0.08 1.1x10 7.4x10 0.11 6.4x10 4.3x10...
  • Page 83 Table 33 - Optical density calculation for the MULTISCAN® VS with SC7, SC10 and SC14 scanning heads — wavelength 9.3µm Scanning head Final lens focal Beam NOHD (m) Irradiance Radiant Optical density aperture (mm) length (mm) diameter (mm) exposure 0.17 2.0x10 1.4x10 0.23...
  • Page 84 Invisible laser radiation and schematics contained herein are subject to change without notice. Avoid eye or skin exposure to direct or scattered radiation Luxinar Ltd Tel: +44 1482 650088 Meadow Road sales.uk@luxinar.com Bridgehead Business Park www.luxinar.com...
