- Page 1 OPERATING MANUAL LM-H Temp. & RH Datalogger Model No.: 6xx... G-Tek Corporation Pvt. Ltd. 3, mahavir estate, karelibaug vadodara-390 018 tel.: +91-265-2461912 email: info@gtek-india.com url: www.gtek-india.com...
-
Page 2: Table Of Contents
List of Tables ............................3 Introduction ............................ 4 Manual Layout ........................4 LM Pro RF Description ......................4 Features ..........................5 Unpacking and inspection of LM Pro RF ................. 5 1.4.1 Status LEDs ........................6 1.4.2 Display LCD ........................6 Installation ............................ - Page 3 Figure 1 Front View of LM Pro RF ......................5 Figure 2 LCD Display ..........................6 Figure 3 Schematic diagram of Set up of LM Pro RF ................7 Figure 4 Internal Schematic diagram of LM Pro RF................. 8 Figure 5 5 VDC 1.2 Amp Adaptor ......................10 Figure 6 Ethernet Cable ........................
-
Page 4: List Of Tables
List of Tables IST OF ABLES Table 1 Manual Layout ..........................4 Table 2 Specification of LM Pro RF ......................11 Table 3 Sensor types and range ......................12 Table 4 LM Pro RF Order Code ......................13 G-Tek Corporation Pvt. LTD... -
Page 5: Introduction
1. I NTRODUCTION This manual is written to help the user to get familiar with the installation and operation of LM Pro RF. It is designed for reliable and convenient recording of process parameters in production, Research and Quality control applications. This device can sense the Temperature and Humidity, displaying them on LCD display ae well as sending these data via RF signal to Moderator device for monitoring on gtekNetTM. -
Page 6: Features
Ensure that all accessories and documentation is removed from the box. If the LM Pro RF is for immediate use, you can start installing it as per following instructions. Please preserve the original packing along with all internal packing for future transport requirements. -
Page 7: 1.4.1 Status Leds
Introduction 1.4.1 Status LEDs There are two status LEDs available on LM Pro RF device for the indication of device status. The meaning of both the LEDs are described as below: Heartbeat LED will be flickered at every 5 minutes for updating time of data, after that it will be OFF till next interval comes. -
Page 8: Installation
Installation NSTALLATION For the installation, the LM Pro RF is powered ON by inserting battery in the device. Switch ON the Moderator with 5 V DC adapter. Connect Moderator device with PC using ethernet cable for communication. Please refer the schematic diagram given in figure 3 for setting up the connection. -
Page 9: Operation
3.1 LM P RF I NTERNAL CHEMATICS IAGRAM The internal schematic of LM Pro RF consists of various blocks as shown in figure 4. Figure 4 Internal Schematic diagram of LM Pro RF 3.2 LM P RF OPERATION • Once the Setup is done as per the schematic diagram, LM Pro RF show Room Temperature and %RH on display continues Scrolling every 5 minutes. -
Page 10: Troubleshooting Guide
UP/Down arrow and “ALARM” message will be on top of the LCD display. The LCD display will be blinked on Alarm condition. • If LCD display is OFF, then what Check if battery is properly inserted in the device. should be done? G-Tek Corporation Pvt. LTD... -
Page 11: Standard Accessories
5.1 5 V DC @ 1.2 A ADAPTOR Figure 5 5 VDC 1.2 Amp Adaptor Input Voltage: 100-240 V AC 0.35 Amp. Operating Frequency: 50 to 60Hz. Output voltage: 5V DC 1.2 Amp 5.2 E THERNET ABLE Figure 6 Ethernet Cable G-Tek Corporation Pvt. LTD... -
Page 12: Specification
Specification PECIFICATION The Specifications of LM Pro RF are: Table 2 Specification of LM Pro RF Model No LM Pro RF Wireless RF Temperature / Humidity Product Code: Datalogger Display and Operator Panels Display Type 3½ digit LCD Display Unit Indication, High and Low Alarm Indication,... -
Page 13: Table 3 Sensor Types And Range
Parameter Sensor Range Accuracy Temperature Thermistor -20 to +60 °C ± 0.5 °C Temp.: -20 to +60 °C ± 0.5°C Temperature + %RH Solid state ±2% RH between 20-80 %RH %RH: 0-100 % ±3% RH otherwise G-Tek Corporation Pvt. LTD... -
Page 14: Ordering Code
Ordering Code RDERING LM Pro RF order code is as below: - Table 4 LM Pro RF Order Code Communication Series Input Type Power Supply Mounting Type Software Interface GtekNet LM Pro Battery Radio Frequency Temp Handheld Non- Operated (RF)
