12/23
AC Series
Access Control System
Quick Start Programming Guide for AC Nio
ATTENTION:
This is an abbreviated programming manual addressing basic program settings for an AC Series system using AC Nio.
A complete set of instructions can be found in AC Nio's left-hand side menu or downloaded from
www.aiphone.com
1 | AC Series - Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC Series and is the answer not in the manual?

Questions and answers

Related Manuals for Aiphone AC Series

Summary of Contents for Aiphone AC Series

  • Page 1 Quick Start Programming Guide for AC Nio ATTENTION: This is an abbreviated programming manual addressing basic program settings for an AC Series system using AC Nio. A complete set of instructions can be found in AC Nio’s left-hand side menu or downloaded from www.aiphone.com...

  • Page 2: Table Of Contents

    Introduction AC Nio is a web-based software for programming the AC Series access control system. AC Nio is used to monitor and administer the system. This guide will cover basic programming and does not include advanced features, installing AC Nio software on a PC, or AC Series hardware and wiring.

  • Page 3: Initial Setup

    Create Customer appear. Use the created administrator's email address and password to proceed. Administrator Email Administrator Username (Can be the same as admin email.) Administrator First Name Administrator Last Name Administrator's Prefered Language 3 | AC Series - Quick Start Guide...

  • Page 4: Creating Partitions, Sites

    Areas are primarily used for anti-passback and user tracking via a Muster Report. To add a new area, . For the first area, rename the field labeled No Area. If adding more than one area, enter click on the cogwheel icon, then click Areas in the name and click 4 | AC Series - Quick Start Guide...

  • Page 5: Creating Schedules

    Select the Partition(s) the schedule will used for. Partition Name Select the access to schedule. Click and drag the mouse over the date and time access is being set for. Once the schedule is configured, click +Save 5 | AC Series - Quick Start Guide...
  • Page 6 Door Contact function. If there is not a door contact connected to the input when the settings are uploaded to the panel, AC Nio will report that the door has been forced open and the door will not function. 6 | AC Series - Quick Start Guide...

  • Page 7: Adding Panels

    Next, the settings for the reader itself need to be configured. Assign the reader a Name and detailed Description. Select the Wiegand port the door's card reader will be wired to from in the Port on Panel field. Reader Name Reader Description Wiegand Port the card reader is wired up to. 7 | AC Series - Quick Start Guide...

  • Page 8: Creating Access Privilege Groups

    Access Group Name Access Group Partition Select any existing users to be added to the group. Users can also be added when they are added to the system. John Smith 8 | AC Series - Quick Start Guide...

  • Page 9: Adding Users/Credentials

    After clicking on the "Unknown user Denied Access" message, a page will load to add new user. The credentials are already input. Complete the First and Last Name fields. John Assign the user card Permissions. Add the user to at least one partition. Partition Name 9 | AC Series - Quick Start Guide...
  • Page 10 If folder or network permissions prevented the backup from being written, an error will be displayed. When performing the first backup, browse to the output and verify the backup has been written. This may take several minutes for larger databases. 10 | AC Series - Quick Start Guide...

  • Page 11: Input Functions

    Door Unlocked or Open/Prevent Unlock input on another panel controlling access to the same area. Connect to an input with the function “Door Prevent Unlock”. 11 | AC Series - Quick Start Guide...

  • Page 12: Output Functions

    An output that can be triggered from input changes or through AUX Output triple swipe commands. Network Ports The following ports are opened on the AC Nio server for programming AC series hardware. 9876 (TCP) Hardware communication to AC Nio 11001 (TCP) Web GUI for AC Nio.
