1.
OVERVIEW.......................................................................................................................................... 1
1.1. INTRODUCTION......................................................................................................................... 1
1.2. SYSTEM DIAGRAM ................................................................................................................... 1
2.
INSTALLATION................................................................................................................................... 3
2.1. FRAME ....................................................................................................................................... 3
2.2. BACKPANEL CONNECTIONS .................................................................................................. 3
2.2.1. Serial Control Port Connections............................................................................................ 3
2.2.2. Ethernet Connections............................................................................................................ 4
3.
STATUS INDICATORS AND DISPLAY .............................................................................................. 5
3.1. CARD EDGE............................................................................................................................... 5
4.
CONFIGURATION............................................................................................................................... 7
4.1. CONFIGURATION VIA CARD EDGE SERIAL CONNECTION ................................................. 7
4.1.1. Network Configuration........................................................................................................... 8
4.1.2. Serial Control Port Settings................................................................................................... 9
4.1.3. SNMP Settings...................................................................................................................... 9
4.1.4. Other Settings ..................................................................................................................... 10
4.1.5. Upgrading Firmware via Serial Connection......................................................................... 10
4.2. MATRIX CONFIGURATION USING SNMP ............................................................................. 10
4.2.1. Example 128x128 Configuration ......................................................................................... 11
5.
X-NCP2 PANEL OPERATION .......................................................................................................... 13
5.1. X-NCP2 CONTROL PANEL ..................................................................................................... 13
5.1.1. Example 1: Pushbutton Control to Switch Input 2 to Output 5 ........................................... 14
5.1.2. Example 2: Rotary Knob Control to Switch Input 2 to Output 5 ......................................... 14
5.1.3. Example 3: Setting the Gain to +6dB in Manual Model on All Inputs................................. 15
5.1.4. Example 4: Executing a Salvo Command .......................................................................... 15
TABLE OF CONTENTS
Revision 1.2
7700 MultiFrame Manual
7700SRV-XRF System Controller
Advertisement
Table of Contents
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
7700 MultiFrame Manual 7700SRV-XRF System Controller TABLE OF CONTENTS OVERVIEW............................1 1.1. INTRODUCTION......................... 1 1.2. SYSTEM DIAGRAM ........................1 INSTALLATION........................... 3 2.1. FRAME ............................3 2.2. BACKPANEL CONNECTIONS ....................3 2.2.1. Serial Control Port Connections.................... 3 2.2.2. Ethernet Connections......................4 STATUS INDICATORS AND DISPLAY .................... - Page 2 7700 MultiFrame Manual 7700SRV-XRF System Controller Figures Figure 1-1: Connection Diagram for System Controller with XRF6 Routers for a 128x128 System ....1 Figure 2-1: Rear Panel of 7700SRV-XRF ......................3 Figure 3-1: 7700SRV-XRF card edge ........................5 Figure 4-1: Upgrade Cable and PCB Connector for Serial Connection............... 7 Figure 4-2: Connection Diagram for 128x128 Matrix Using Four XRF6-64x64 Routers ........
- Page 3 Sept 09 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
- Page 4 7700 MultiFrame Manual SRV-XRF System Controller This page left intentionally blank Revision 1.2...
-
Page 5: Overview
1.1. INTRODUCTION The 7700SRV-XRF is the system controller (SC) for multi frame L band matrices comprised of Evertz Microsystems L band routers. A maximum matrix size of 512x512 is achievable with the XRF6 router. The 7700SRV-XRF hardware consists of a maximum of two SC cards housed in a 1RU 7701 multiframe with optional dual power supply. - Page 6 Control of the router system can be accomplished by using any combination of SNMP manager software (such as VL-Pro), X-NCP2 panels, or Evertz Router Control (ERC) protocol over the SC’s Serial Control Port (SCP). The control system(s) must interface with the active SC card.
-
Page 7: Installation
The second and third slots from the left (facing the front of the frame) are used for the 7700SRV-XRF cards. 2.1. FRAME The 7701 Evertz Microsystems multiframe has a door at the front which can be opened by loosening the two screws at the far sides of the door. 2.2. BACKPANEL CONNECTIONS The rear panel of the 7700SRV-XRF is illustrated in Figure 2-1. -
Page 8: Ethernet Connections
7700 MultiFrame Manual SRV-XRF System Controller Table 2-2 illustrates the pinout for the SCP when operating in RS422 mode. Pin Number Signal TX- (1) TX+ (1) RX- (1) RX+ (1) TX- (2) TX+ (2) RX- (2) RX+ (2) Table 2-2: SCP RS422 Pinout 2.2.2. -
Page 9: Status Indicators And Display
7700 MultiFrame Manual SRV-XRF System Controller STATUS INDICATORS AND DISPLAY The 7700SRV-XRF includes a number of status LEDs, a toggle switch and 4 character dot matrix display for monitoring and diagnostics. The large green and red LEDs next to the toggle switch are used to indicate the overall health of the card. - Page 10 7700 MultiFrame Manual SRV-XRF System Controller The large green and red LEDs at the top of the board indicate the card status. Only Status LED: one of these LEDs will be on at any time after power up. The Red LED ON indicates an error has occurred and has been logged in the event log.
-
Page 11: Configuration
Note: The following steps are to be repeated on any secondary SC card. 1. Connect a PC serial cable to the 4 pin 7700SRV-XRF connector J1 using the Evertz Microsystems upgrade cable ( female DB9 serial connector to 2x3 strip connector ) as illustrated in Figure 4-1. -
Page 12: Network Configuration
7700 MultiFrame Manual SRV-XRF System Controller The following menu will be displayed in the HyperTerminal session: ------------------------------------------------ Main Menu (7700SRV-XRF v1.00 b56) ------------------------------------------------ (1) Network Configuration (2) SNMP Setup (3) Database (4) Card status (5) Serial Control Port Configuration (6) Event log... -
Page 13: Serial Control Port Settings
SRV-XRF System Controller 4.1.2. Serial Control Port Settings The 7700SRV-XRF can be controlled via the proprietary Evertz Router Control ( ERC ) protocol. To configure the settings of this port, use menu item (5). The following selections are displayed for each... -
Page 14: Other Settings
SNMP. It is assumed that the system controller has been configured. Details on configuring the system controller card can be found in the MIB file. (Please contact Evertz Microsystems for this information). Information on each router in the system is contained in the chassis orientation table. To configure a matrix, data on all the frames in the system must be entered and then applied in SNMP by performing a set (set to ‘true’) on the MIB parameter xrf6ApplyOrientationData. -
Page 15: Example 128X128 Configuration
7700 MultiFrame Manual SRV-XRF System Controller 4.2.1. Example 128x128 Configuration FRAME #1 Power Power Supply B Supply A Output 1 X 6 RF - P S X 6 R F -P S SLOT 1 SLOT 2 SLOT 3 SLOT 4... -
Page 16: Table 4-1: Chassis Orientation Table
7700 MultiFrame Manual SRV-XRF System Controller Table 4-1 describes the Chassis Orientation Table. Secondary Number Description Primary IP IN Start IN End Valid Clear start Frame#1 192.168.9.5 192.168.9.7 Frame#2 192.168.9.8 192.168.9.10 Frame#3 192.168.9.44 192.168.9.55 Frame#4 192.168.9.66 192.168.9.77 Table 4-1: Chassis Orientation Table The valid bit is an indicator of the validity of the data in the table. -
Page 17: X-Ncp2 Panel Operation
The Evertz X-NCP2 control panel is a multi-function control panel used to control the 7700SRV-XRF system controller or XRF6 and XRF1 routers, as well as other Evertz products. When connected to the 7700SRV-XRF system controller, the panel can be used to set crosspoints, execute salvos or configure parameters associated with inputs and/or outputs. -
Page 18: Example 1: Pushbutton Control To Switch Input 2 To Output 5
7700 MultiFrame Manual SRV-XRF System Controller The examples listed below illustrate two different methods of initiating a crosspoint take with the router and also configuring the gain setting on the inputs. To move up one level in the menus when in configuration mode, press the [ESC] key. -
Page 19: Example 3: Setting The Gain To +6Db In Manual Model On All Inputs
7700 MultiFrame Manual SRV-XRF System Controller 5.1.3. Example 3: Setting the Gain to +6dB in Manual Model on All Inputs 1. Initiate a panel session by highlighting the IP address (or router name) of the router in the display area of the panel. This is done using the leftmost scroll knob. When the frame IP address (or name) is highlighted, press [SETUP]. - Page 20 7700 MultiFrame Manual SRV-XRF System Controller This page left intentionally blank Page - 16 Revision 1.2...
