  • Page 1 ROCKY-6160 ® SOCKET 478 PENTIUM 4 SBC With USB 2.0 & Gigabit LAN User’s Manual Version 1.0 November 3, 2004 ©2003 Copyright by ICP Electronics Inc. All rights reserved.
  • Page 2 Trademarks ROCKY-6160 is registered trademarks of ICP Electronics Inc.; IBM PC is a registered trademark of International Business Machines Corporation. Intel is a registered ®...

  • Page 3: Table Of Contents

    Table of Contents Introduction ............ 4 Specifications ............ 5 What You Have ..........7 Installation ............8 ROCKY–6160 Layout........... 9 Unpacking Precautions ........10 GMCH Frequency Strapping ....... 11 Compact Flash Master/Slave Function Setting ..11 Clear CMOS Setup..........11 LCD Voltage Selection........
  • Page 4 Keyboard & PS/2 Mouse Connector ..... 19 3.10 Fan Connectors..........20 3.11 Serial ATA Connectors ........20 3.12 Digital Input / Output Connector ......21 3.13 VGA Connector ..........21 3.14 DVI Connector ..........21 3.15 LCD Panel LVDS Interface Connector ....22 3.16 External Switches and Indicators ......
  • Page 5 4.13 Exit .............. 47 Appendix A. Watchdog Timer......49 Appendix B. I/O Address Map......51 Appendix C. Digital I/O........53 Appendix D. ATX Power Supply...... 55 Appendix E. How to use Wake-Up Function... 57...

  • Page 6: Introduction

    USB2.0 host controller implements an ECHI interface that provides 480Mb/s bandwidth. An advanced high performance super AT I/O Chip – Winbond W83627HF is used in the ROCKY-6160. Both on-chip UARTs are compatible with the NS16C550. The parallel port and IDE interface are compatible with IBM PC/AT architecture.

  • Page 7: Specifications

    Specifications ® Supports Intel Pentium 4/Mobile ® CPU (PGA 478) Pentium 4-M, 400/533 MHz FSB (set by BIOS) Bus Interface PCI/ISA bus, PICMG 1.0 compliant Chipset INTEL 852GME (GMCH) INTEL 82801EB (ICH5) Two 184-pin DIMM sockets support Memory DDR200/266/333 SDRAM with ECC. The maximum memory is up to 2GB.
  • Page 8 Supports two independent serial ATA Serial ATA channels with transfer rate of 150MB/s Built-in AGP 2.0 4X 3D graphics engine. Share system DDR SDRAM 8M. Flat VGA controller panel on-chip 852GME. Supports 18bit/24bit single pixel or 24bit dual pixel color LVDS TFT LCD. INTEL 82541PI Gigabit Ethernet Ethernet controller.

  • Page 9: What You Have

    What You Have In addition to this user's manual, the ROCKY-6160 package includes the following items: • One ROCKY-6160 Single Board Computer • One FDD cable • One ATA/100 IDE cable. • Two Serial ATA IDE cable. • One ATX-12V cables.

  • Page 10: Installation

    Installation This chapter describes how to install the ROCKY-6160. At first, the layout of ROCKY-6160 is shown, and the unpacking information that you should be careful is described. The jumpers and switches setting for the ROCKY-6160 configuration, such as CPU clock setting,...

  • Page 11: Rocky-6160 Layout

    ROCKY–6160 Layout...

  • Page 12: Unpacking Precautions

    Ground yourself to remove any static charge before touching your ROCKY-6160 SBC. You can do it by using a grounded wrist strap at all times or by frequently touching any conducting materials that is connected to the ground.

  • Page 13: Gmch Frequency Strapping

    GMCH Frequency Strapping • JP1: GMCH Frequency Strapping Setting DESCRIPTION Open Open 133 - 200 Open Short 100 - 200 Short Open 100 - 133 Short Short 133 - 267 Open Open 133 - 200 Open Short 133 - 267 Short Open 167 - 267...

  • Page 14: Lcd Voltage Selection

    (default) (Normal Operation) Short 2-3 Clear CMOS Setup LCD Voltage Selection • JP4: LCD Voltage Selection DESCRIPTION +3.3V ® Pentium 4/Mobile P4-M Selection ® • JP5: Pentium 4/Mobile P4-M Selection DESCRIPTION 11-12 9-10 Mobile P4-M High-Speed (1.3V) Mobile P4-M Low-Speed (1.2V) ®...

  • Page 15: Connection

    Connection Table of Connectors LABEL FUNCTION IDE1&IDE2 Primary& Secondary IDE Connectors FDD1 FDC Connector LPT1 Parallel Port Connector COM1&COM2 Serial Port 10-pin Connectors Compact Flash Storage Card Type II Connector USB1~USB4 USB Port Connectors IrDA Infrared Interface Connector Giga LAN RJ45+LED Connector CN11 10/100 LAN RJ45+LED Connector LAN State LED Connector...

  • Page 16: Pci E-Ide Disk Drive Connector

    PCI E-IDE Disk Drive Connector These connectors support Ultra-DMA100 IDE devices. Non-DMA100 devices are suggested to be connecting to the secondary IDE connector. IDE 1: Primary IDE Connector IDE 2: Secondary IDE Connector • IDE Interface Connector DESCRIPTION DESCRIPTION RESET# GROUND DATA 7 DATA 8...

  • Page 17: Parallel Port

    WRITE GATE# GROUND TRACK 0# GROUND WRITE PROTECT# READ DATA# GROUND SIDE 1 SELECT# DISK CHANGE# Parallel Port ROCKY-6160 includes on-board parallel port, accessed through a 26-pin flat-cable connector. • LPT1: Parallel Port Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION...

  • Page 18: Serial Ports

    REQUEST TO SEND (RTS) TRANSMIT DATA (TXD) CLEAR TO SEND (CTS) DATA TERMINAL READY (DTR) RING INDICATOR (RI) GROUND (GND) CompactFlash Type II Storage Card Socket ROCKY-6160 configures CompactFlash Type II Storage Card in IDE Mode. • CF1: CompactFlash Type II Socket...

  • Page 19: Usb Port Connectors

    HDD ACTIVE# DATA 0 PDIAG# DATA 1 DATA 8 DATA 2 DATA 9 DATA 10 CARD DETECT 2 GROUND USB Port Connectors ROCKY-6160 provides 8 built-in USB ports. USB1~USB4 PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND DATA- DATA+ DATA+ DATA- GROUND...

  • Page 20: Irda Infrared Interface Port

    IrDA Infrared Interface Port ROCKY-6160 has a built-in IrDA port which supports Serial Infrared (SIR) or Amplitude Shift Keyed IR (ASKIR) interface. If you want to use the IrDA port, you have to configure SIR or ASKIR model in the BIOS under Peripheral Setup COM2.

  • Page 21: Keyboard & Ps/2 Mouse Connector

    • CN7: Gigabit LAN State LED Connector PIN NO. DESCRIPTION LINK Activity • CN11: 10/100M LAN RJ45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SPLED Act / LED LINK LED • CN10: 10/100M LAN State LED Connector PIN NO. DESCRIPTION SPLED LINK LED Act / LED...

  • Page 22: Fan Connectors

    KEYBOARD DATA GROUND 3.10 Fan Connectors ROCKY-6160 provides two CPU cooling fan connectors; these connectors can supply 12V/500mA to the cooling fan. All connectors have the same pin assignments and provide a "rotation" pin to get rotation signals from fans and notice the system.

  • Page 23: Digital Input / Output Connector

    Output 0 Input 3 Input 2 Input 1 Input 0 3.13 VGA Connector The ROCKY-6160 has a built-in 15-pin VGA connector directly connects to your CRT monitor. • VGA1: 15-pin Female Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION GREEN BLUE...

  • Page 24: Lcd Panel Lvds Interface Connector

    GROUND CLK- GROUND 3.15 LCD Panel LVDS Interface Connector ROCKY-6160 provides an LVDS transmitter with a scaled resolution up to SXGA for single pixel input. It supports up to 48-bit color LVDS LCD. • LVDS1: LVDS Interface Connector PIN NO. DESCRIPTION PIN NO.

  • Page 25: External Switches And Indicators

    GROUND BKL_POWER GROUND 3.16 External Switches and Indicators There are several external switches and indicators for monitoring and controlling your CPU board. All the functions are in the CN3 connector. • CN3: External Switches and Indicators PIN DESCRIPTION PIN DESCRIPTION Speaker Power LED GROUND...

  • Page 26: Atx-12V Power Source Connector

    • LINE_IN1: Audio LINE-IN Connector (Input) • CD_IN1: Audio CD-IN Connector (Input) • MIC1: Audio MIC-IN Connector (Input) DESCRIPTION PIN NO. LINE_IN1 CD_IN1 MIC1 LEFT LEFT MIC-IN RIGHT RIGHT 3.18 ATX-12V Power Source Connector This connector supports the ATX-12V power. CN4(CPU) DESCRIPTIO DESCRIPTIO...

  • Page 27: Ami Bios Setup

    AMI BIOS SETUP Introduction This manual discusses AMI's Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off.

  • Page 28: Using Setup

    <Alt>, and <Delete> keys. If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to... Using Setup In general, you use the arrow keys to highlight items, press <Enter>...

  • Page 29: Bios Menu Bar

    If, after making and saving system changes with Setup, you discover that your computer no longer is able to boot, the AMI BIOS supports an override to the CMOS settings which resets your system to its defaults. The best advice is to only alter settings which you thoroughly understand.

  • Page 30: Main

    Main When you enter the BIOS Setup program, the Main menu screen appears giving you an overview of the basic system information. AMI BIOS This item displays the auto-detected BIOS information. Processor This item displays the auto-detected CPU specification. System Memory This item displays the auto-detected system memory.

  • Page 31: Advanced

    Advanced The Advanced menu items allow you to change the settings for the CPU and other system devices. 4.7.1 CPU Configuration The items in this menu show the CPU-related information auto- detected by BIOS.
  • Page 32 Hyper-Threading Technology [Disable] This item allows you to enable or disable the processor Hyper- Threading Technology. Configuration options: [Disabled] [Enabled] P4M SUPPORT [By Hardware] This item allows you to by hardware or enable / disable the P4- M CPU support. Configuration options: [Disabled] [Enabled] [By Hardware] 4.7.2 IDE Configuration The items in this menu allow you to set or change the...
  • Page 33 IDE Configuration [P-ATA Only] This item allows you to select the IDE mode Configuration options: [Disabled] [P-ATA Only] [S-ATA Only] [P-ATA & S-ATA] Primary and Secondary IDE Master/Slave Third and Fourth IDE Master The values opposite the dimmed items (Device, Vendor, Size, LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA, and SMART monitoring) are auto-detected by BIOS and are not user-configurable.
  • Page 34 Enables or disables the LBA mode. Setting to Auto enables the LBA mode if the device supports this mode, and if the device was not previously formatted with LBA mode disabled. Configuration options: [Disabled] [Auto] Block (Multi-sector Transfer) [Auto] Enables or disables data multi-sectors transfers. When set to Auto, the data transfer from and to the device occurs multiple sectors at a time if the device supports multi-sector transfer feature.
  • Page 35 4.7.4 Super IO Configuration On Board Floppy Controller [Enabled] Allows you to enable or disable the floppy disk controller. Configuration options: [Disabled] [ Enabled] Serial Port1 Address [3F8/IRQ4] Allows you to select the Serial Port1 base address. Configuration options: [Disabled] [3F8/IRQ4] [3E8/IRQ4] [2E8/IRQ3] Serial Port2 Address [2F8/IRQ3] Allows you to select the Serial Port2 base address.
  • Page 36 Parallel Port IRQ [IRQ7] Configuration options: [IRQ5] [IRQ7] Digital I/O Function [Disabled] Allows you to enable or disable the Digital I/O controller. Configuration options: [Disabled] [ Enabled]...
  • Page 37 4.7.5 Hardware Health Configuration 4.7.6 ACPI Configuration Allows you to change the settings for the Advanced Power Management (APM). Select an item then press Enter to display the configuration options.
  • Page 38 General ACPI Configuration Allows you to select the ACPI state to be used for system suspend. Configuration options: [S1 (POS)] [S3 (STR)] [Auto] Advanced ACPI Configuration Use this section to configure additional ACPI options. ACPI 2.0 Support [No] Allows you to add more tables for ACPI 2.0 Support. Configuration options: [No] [Yes] ACPI APIC support [Enabled] Allows you to enable or disable the ACPI support in the ASIC.
  • Page 39 4.7.7 MPS Configuration Configure the Multi-Processor table MPS Revision [1.4] Configuration options: [1.1] [1.4] 4.7.8 Remote Access Configuration Configure Remote Access. Remote Access [Disabled] Configuration options: [Disabled] [Enabled] 4.7.9 USB Configuration The items in this menu allows you to change the USB-related features.

  • Page 40: Pci Pnp

    Enable support for legacy USB. Configuration options: [Disabled] [Enabled] [Auto] USB 2.0 Controller [Enabled] Allows you to enable or disable the USB 2.0 controller. Configuration options: [Disabled] [Enabled] USB 2.0 Controller Mode [HiSpeed] Allows you to configure the USB 2.0 controller in Hi Speed (480 Mbps) or Full Speed (12 Mbps).

  • Page 41: Boot

    Configuration options: [No] [Yes] PCI Latency Timer [32] Allows you to select the value in units of PCI clocks for the PCI device latency timer register. Configuration options: [32] [64] [96] [128] [160] [192] [224] [248]. Allocate IRQ to PCI VGA [Yes] When set to [Yes], BIOS assigns an IRQ to PCI VGA card if the card requests for an IRQ.
  • Page 42 4.9.1 Boot Settings Configuration Quick Boot [Enabled] Enabling this item allows BIOS to skip some power on self tests (POST) while booting to decrease the time needed to boot the system. When set to [Disabled], BIOS performs all the POST items.

  • Page 43: Security

    Allows you to enable or disable support for PS/2 mouse. Configuration options: [Disabled] [Enabled] [Auto] Wait for ‘F1’ If Error [Enabled] When set to Enabled, the system waits for F1 key to be pressed when error occurs. Configuration options: [Disabled] [Enabled] Hit ‘DEL’...
  • Page 44 Change Supervisor Password Select this item to set or change the supervisor password. The Supervisor Password item on top of the screen shows the default “Not Installed”. After you have set a password, this item shows “Installed”. Change User Password Select this item to set or change the user password.

  • Page 45: Chipset

    4.11 Chipset The Chipset menu items allow you to change the advanced chipset settings. Select an item then press Enter to display the sub-menu. 4.11.1 North Bridge Configuration DRAM Frequency [Auto] Allows you to select the frequency of DRAM memory to activate.
  • Page 46 Init. Graphic Adapter Priority [AGP/Int-VGA] Allows selection of the graphics controller to use as primary boot device. Configuration options: [Internal VGA] [AGP/Int-VGA] [AGP/PCI] [PCI/AGP] [PCI/Int-VGA] Internal Graphics Mode Select [Enable, 8MB] Select the amount of system memory used by the internal graphics device.

  • Page 47: Power

    4.12 Power Power Management/APM [Enabled] Allows you to enable or disable the Advanced Power Management (APM) feature. Configuration options: [Disabled] [Enabled] Video Power Down Mode [Suspend] Allows you to select the video power down mode. Configuration options: [Disabled] [Standby] [Suspend] Hard Disk Power Down Mode [Suspend] Allows you to select the hard disk power down mode.
  • Page 48 Configuration options:[Disabled] [1 Min] [2 Min] [4 Min] [8 Min] [10 Min] [20 Min] [30 Min] [40 Min] [50 Min] [60 Min] Throttle Slow Clock Ratio [50%] Allows you to select the duty cycle in throttle mode. Configuration options: [87.5%] [75.0%] [62.5%] [50%] [37.5%] [25%] [12.5%] System Thermal [Disabled] power management event.

  • Page 49: Exit

    4.13 Exit The Exit menu items allow you to load the optimal or failsafe default values for the BIOS items, and save or discard your changes to the BIOS items. Save Changes and Exit Once you are finished making your selections, choose this option from the Exit menu to ensure the values you selected are saved to the CMOS RAM.
  • Page 50 This option allows you to discard the selections you made and restore the previously saved values. After selecting this option, a confirmation appears. Select [Yes] to discard any changes and load the previously saved values. Load Optimal Defaults This option allows you to load optimal default values for each of the parameters on the Setup menus.

  • Page 51: Appendix A. Watchdog Timer

    Appendix A. Watchdog Timer The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause CPU crash, e.g. external EMI or a software bug. When the CPU stops working properly, a hardware reset (cold boot) or a NMI (Non-Maskable Interrupt) will be issued to resume the system to a known state.
  • Page 52 Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: MOV AX, 6F02H ; setting the time-out value MOV BL, 30 ; time-out value is 48 seconds INT 15H ; ADD YOUR APPLICATION PROGRAM HERE CMP EXIT_AP, 1 ; is your application over? JNE W_LOOP ;...

  • Page 53: Appendix B. I/O Address Map

    Appendix B. I/O Address Map • I/O Address Map I/O address Description 000-00F DMA Controller 020-021 Interrupt Controller 040-043 System time 060-060 Standard 101/102 Keyboard Controller 061-061 System Speaker 070-071 System CMOS/Real time Clock 081-083 DMA Controller 0A0-0A1 Interrupt Controller 0C0-0DF DMA Controller 0F0-0FF...
  • Page 54 IRQ Mapping Chart IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 IRQ FOR PCI STEERING IRQ2 IRQ Controller IRQ10 LAN IRQ3 COM2 IRQ11 LAN IRQ4 COM1 IRQ12 PS/2 mouse IRQ5 AUDIO IRQ13 FPU IRQ6 FDC IRQ14 Primary IDE IRQ7 Printer IRQ15 Secondary IDE DMA Channel Assignment Channel...

  • Page 55: Appendix C. Digital I/O

    Appendix C. Digital I/O One of the characteristics of digital circuit is its fast response to high or low signal. This kind of response is highly needed for harsh and critical industrial operating environment. ROCKY- 6160 is designed with 4-bit digital inputs and 4-bit digital outputs.
  • Page 56 2. To write data: AH - 6FH Sub-function: AL – 9: to write data to the output port : the data to be output Example program: MOV AX, 6F09H ; writing data to the digital output port MOV BL, 09H ;...

  • Page 57: Appendix D. Atx Power Supply

    ATX power supply but has two types of power switch connection: 2.1. ROCKY-6160 (through Power Button & GND): Connect the ATX power button switch to the PWB1 (power button). And connect the power cable from...
  • Page 58 If you want to turn ON the system, just press the button once. And if you want to turn off the power supply, please press the ATX power switch button for about 4 seconds. B. For the backplanes with ATX power supply connector For some SBC without ATX power ON/OFF function, you can control the ATX power supply through backplane’s PS-ON...

  • Page 59: Appendix E. How To Use Wake-Up Function

    Appendix E. How to use Wake- Up Function ROCKY-6160 supports two kind of Wake-up Function. This page describes how to use Modem Wake-Up and LAN Wake-Up function. Wake-Up function is only working when you use ATX power supply. Wake–Up On Modem (Ring): You must set the option “Wake-Up On LAN/Ring”...
