Summary of Contents for Munters RPS Sensor
- Page 1 Sensor Installation Manual RPS Manual Pressure Sensor Ag/MIS/ImEn-2769-06/20 Rev 1.4 116820...
- Page 2 Munters reserves the right to effect modifications to the apparatus in accordance with technical and legal developments.
- Page 3 TRIO supports up to two static pressure sensors, one built in and one external. Install the RPS in the second room. Figure 1: RPS Wiring Number Function S port. Raise the corresponding S3 dipswitch. COM port Shield wire © Munters AB, 2020...
- Page 4 The following section details how to configure the RPS device. For further information on configuring devices and sensors in TRIO, refer to the TRIO manual. 1. Go to System > Devices & Sensors. 2. Click . The Devices & Sensor screen appears. 3. Click 4. Click Pressure. © Munters AB, 2020...
- Page 5 5. Define an analog input port as the pressure sensor. In the following screen, ports 5 is defined as the pressure sensor. 6. Go to Climate > Static Pressure and define the parameters and settings (refer to the TRIO Manual for details). © Munters AB, 2020...
- Page 6 2 Rotem One/Rotem Pro Installation Figure 4: Rotem Pro/Rotem One – RPS Wiring Figure 5: Rotem Pro/Rotem One – RPS Schematic Refer to the Rotem Pro and Rotem One User Manuals on how to define and configure static pressure-based ventilation. © Munters AB, 2020...
-
Page 7: Specifications
3 Specifications Specification Description Input power 12 VDC Output signal 3VAC © Munters AB, 2020... -
Page 8: Warranty
Munters plant was required: if this is not done, the user is fully responsible for the damage which they could suffer. - Page 9 The liability of the manufacturer Munters ceases in the event of: dismantling the safety devices; • use of unauthorised materials; • inadequate maintenance; • use of non-original spare parts and accessories. • Barring specific contractual terms, the following are directly at the user’s expense: preparing installation sites;...
