READ ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND LEAVE WITH THE END USER FOR FUTURE REFERENCE
WRAS
Important notes
WR AS
This product must be installed in compliance with
WRAS
WRAS
Water Bylaw Regulations.
Isolating and non-return valves should be fitted
(not supplied).
If you are unsure, please obtain the advice of a
professional plumber before attempting any work.
Minimum working pressure is 0.2 bar.
PARTS PROVIDED
Ref
Description
A
Tap
B
Washer gasket
C
Back Nut
Flow rate for tap
(Reference values only.)
Dynamic pressure
0.2 - 0.5 bar
Full cold/hot water
7.6 - 15 L/min
Website
www.akw-ltd.co.uk
Installer - please read all instructions carefully before installation
and leave this manual with the end user for future reference
Qty
2
2
2
1 - 2 bar
3 - 5 bar
18.5 - 26.5 L/min
32 - 41 L/min
Orderline
+44 (0)1905 823 298
A
B
Technical Enquiries
01905 560219
technicalenquiries@akw-ltd.co.uk.
UK
UK
UK
UK
Fig.1
C
Fig.2
