Cover
Renesas Solution Starter Kit
Motor Control Evaluation System
16
- Motor Control IC: RAJ306101 -
All information contained in these materials, including products and product specifications,
represents information on the product at the time of publication and is subject to change by
Renesas Electronics Corp. without notice. Please review the latest information published by
Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
website (http://www.renesas.com).
RAJ306101 RSSK User's Manual
Rev.1.00 Nov 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAJ306101 and is the answer not in the manual?

Questions and answers

Related Manuals for Renesas RAJ306101

Summary of Contents for Renesas RAJ306101

  • Page 1 All information contained in these materials, including products and product specifications, represents information on the product at the time of publication and is subject to change by Renesas Electronics Corp. without notice. Please review the latest information published by Renesas Electronics Corp. through various means, including the Renesas Electronics Corp.
  • Page 2 Renesas Electronics disclaims any and all liability for any damages or losses incurred by you or any third parties arising from the use of any Renesas Electronics product that is inconsistent with any Renesas Electronics data sheet, user’s manual or other Renesas Electronics document.
  • Page 3 Products The following usage notes are applicable to all Microprocessing unit and Microcontroller unit products from Renesas. For detailed usage notes on the products covered by this document, refer to the relevant sections of the document as well as any technical updates that have been issued for the products.
  • Page 4 For Your Safety Do not fail to read this manual before using the RAJ306101 Renesas Solution Starter Kit ( RTK0EMXAH0S00020BJ ) (this product). • Follow the indications in this manual when using the product. • Keep this manual near the product so you can refer to it whenever necessary.
  • Page 5 • Marks directing that the specified action is required. Example: Turn Off (Disconnect) Power Supply! General Instruction Instructs the user to turn off (disconnect) the The specified action is required. power supply to the product. © 2023 Renesas Electronics Corporation. All rights reserved.
  • Page 6 • The product has no safety case. • Failure to observe the above could cause fire, electric shock, burns, or malfunction. • The product may not perform as expected if used for other than its intended purpose. © 2023 Renesas Electronics Corporation. All rights reserved.
  • Page 7 Follow the procedure specified in the manual when powering the system on or off. • Failure to do so could cause overheating or malfunction. Caution – Static Electricity • Use the antistatic band. Failure to do so could cause malfunction or unstable motion. © 2023 Renesas Electronics Corporation. All rights reserved.

  • Page 8: Table Of Contents

    CONTENTS CONTENTS ................................1 Chapter 1. Overview ............................. 1 Feature ..............................3 Chapter 2. Product Specifications ........................4 Outline ..............................4 Evaluation Board..........................5 2.2.1 Appearance..........................6 Block Diagram..........................7 2.2.2 2.2.3 Pin Assignment and Connection on Evaluation Board ..............8 2.2.3 Main Parts, Terminals, and Connectors ..................
  • Page 9 Program Write ............................ 49 5.1.1 studio ............................50 5.1.2 CS+ ............................51 5.1.3 Renesas Flash Programmer ...................... 52 Chapter 6. Renesas Motor Workbench ......................53 Chapter 7. Information ............................54 European Union Regulatory Notices ....................54 Revision History ..............................55 Index-2...

  • Page 10: Contents

    [RTK0EMXAH0S00020BJ] (now referred to as RAJ306101 RSSK) is an evaluation kit for RAJ306101. The RAJ306101 is a motor control IC consisting of the RX13T (R5F513T5ADFL) and the smart gate driver (RAA306012). The RAJ306101 evaluation board included in the evaluation kit enables motor control by inverter operation.
  • Page 11 The 0[Ω] resisters are used to change the connection, 1005[mm] or 1608[mm] size registers are available (solder shorts are available too) Note.1 USB cable for connecting with PC is necessary to use Renesas Motor Workbench or IDE. Abbreviations Abbreviations Full Name...

  • Page 12: Feature

    RAJ306101 Sample programs download website: https://www.renesas.com/RTK0EMXAH0S00020BJ Support Renesas Motor Workbench tool. Renesas Motor Workbench is a tool for monitoring and changing global variables in operation from a PC. For details of the features and instructions on using the tool, refer to Renesas website. R12UZ0129EJ0100 Rev.1.00...

  • Page 13: Chapter 2. Product Specifications

    MOSFET TPH12008NH (80[V], 24[A]) Sensor Hall sensor or sensorless ・ USB for E2 Lite (E2OB) ・ USB for Renesas Motor WorkBench (Now referred to as RMWB) ・ External MOSFET connector (CN_EXT_MOS) Note.1 ・ Hall sensor signal input connector (CN_HALL) Note.2 ・...

  • Page 14: Evaluation Board

    Wave viewer tool The latest tool can be received from Renesas website Note.1: The maximum VM rating of the RAJ306101 is 65[V], but due to the Low Voltage Directive (LVD), this kit supports a maximum VM of 48[V]. Note.2: The Evaluation Board has through holes for mounting the connector. When using this function, please mount the connector.

  • Page 15: Appearance

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications 2.2.1 Appearance Figure 2-1 Appearance R12UZ0129EJ0100 Rev.1.00 Page 6 of 55 Nov 1, 2023...

  • Page 16: Block Diagram

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications 2.2.2 Block Diagram USB_5p0V Ferrite EX_LDO_5p0V Fuse Power Source External bead EX_LDO_SEL UVCC J1: Power 5.0[V] LDO ET_LDO_3p3V J4: GND AGND E2OB USB Connector 5p0V External (DC: 24[V]) (E2_LITE) (ICS) 3.3[V] LDO...

  • Page 17: Pin Assignment And Connection On Evaluation Board

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications 2.2.3 Pin Assignment and Connection on Evaluation Board Table 2-3 Pin Assignments and Connection on Evaluation Board Pin No. RAJ306101 Connection on Evaluation Board Note AVDD_MCU MVDD (AVCC0) AGND_MCU AGND (AVSS0) LED2/CN_LED_4 LED1/CN_LED_3 ─...
  • Page 18 RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications Pin No. RAJ306101 Connection on Evaluation Board Note P44/AN004/ DA3P/CN_ANA_7 DA3O/MUX1 P43/AN003 VR101/CN_ANA_6/(CN_VOL_2) P42/AN002 CN_ANA_5/IW_COM P41/AN001 CN_ANA_4/VBRIDGE_VOL P40/AN000 CN_ANA_3/IU_COM ─ EPAD PGND R12UZ0129EJ0100 Rev.1.00 Page 9 of 55 Nov 1, 2023...

  • Page 19: Main Parts, Terminals, And Connectors

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications 2.2.4 Main Parts, Terminals, and Connectors The Main Parts, Terminals, and Connectors on the Evaluation Board are Layout as Following. USB (E2OB) USB (ICS) E2OB Fuse EX_LDO_SEL I2C_UART _SEL MOSFET RMWB (ICS)
  • Page 20 RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications Universal area CN_SPI Spare circuit CN_UART CN_I2C CN_LED CN_EXT_MOS CN_VOL CN_DIGI1 CN_ANA Universal area Figure 2-4 Unmounted Connectors and Other Circuits Table 2-5 Unmounted Connectors and Other Circuits List Parts Name Item...

  • Page 21: Motor [Tg-55L-Ka 24V (Tsukasa Electric Co., Ltd)]

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications Motor [TG-55L-KA 24V (TSUKASA ELECTRIC CO., LTD)] Table 2-6 shows the specification of the attached motor. For the details of the motor specifications, refer to TSUKASA ELECTRIC website. Table 2-6 TG-55L-KA 24V Motor Specification...

  • Page 22: Ferrite Core [E04Sr200932 (Seiwa Electric Mfg.)]

    RAJ306101 RSSK User’s Manual Chapter 2. Product Specifications Ferrite Core [E04SR200932 (SEIWA ELECTRIC MFG.)] The RAJ306101 RSSK includes a ferrite core to comply with the EMC Directive. Please use the ferrite core with 2 turns as necessary. Figure 2-6 Ferrite Core R12UZ0129EJ0100 Rev.1.00...

  • Page 23: Chapter 3. Usage

    Chapter 3. Usage Chapter 3. Usage The RAJ306101 RSSK is available for evaluation with some kinds of motor control methods by using the Evaluation Board, and Motor attached in this evaluation kit. This evaluation kit includes the following can be evaluated for two different control methods with sample programs.

  • Page 24: Factory Default Setting

    Refer to Figure 3-2 Setting of RAJ306101 RSSK for Motor Evaluation for details on the evaluation method. To evaluate other motor control methods, it is necessary to change the wiring of the Evaluation Board and the...
  • Page 25 Setting of Need to change Sample program of Sample program of Sample program for Evaluation Board Evaluation Board (Default settings) Evaluation Board Figure 3-2 Setting of RAJ306101 RSSK for Motor Evaluation R12UZ0129EJ0100 Rev.1.00 Page 16 of 55 Nov 1, 2023...

  • Page 26: Sensorless Vector Control

    Table 3-1 shows the control specifications. For details of the specifics of the program, please refer to the "RAJ306101 Application Note: Sensorless vector control for permanent magnetic synchronous motor (Implementation) (R18AN0060EJ)".

  • Page 27: Board Settings

    RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.2 Board Settings In sensorless vector control, the motor position is inferred from the current flowing in each phase. The phase currents can be sensed by connecting both ends of the shunt resistors (SR1, SR2, and SR3) of each phase to the built-in differential amplifiers of the smart gate driver or the external current sense circuit.

  • Page 28: Operation Guide

    Hall signals.) c. Connect the power source and the Evaluation Board. (Do not supply power at this time.) The RAJ306101 RSSK includes a ferrite core to comply with the EMC Directive. Please use the ferrite core with 2 turns as necessary.
  • Page 29 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.3.2 Initial Setting Set the toggle switches (SW101, SW102) to Low and set the potentiometer (VR101) to center. (The state in which the knob mark is directly above the knob is called center. The potentiometer used on this board has a pivot point in the center position.)
  • Page 30 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.3.3 Power Supply Supply DC 24[V] to Evaluation Board. The LED0 lights up when power is supplied. Power Source (Output: On) DC 24[V]/2[A] limit Evaluation Board LED0 LED1 LED2 LED3 LED4 High Figure 3-6 Power Supply for Evaluation Board R12UZ0129EJ0100 Rev.1.00...
  • Page 31 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.3.4 Motor Operation Set SW101 to High and turn the potentiometer (VR101). The motor rotates according to the direction and amount of turning the potentiometer (VR101). The LEDs light up according to the control state.
  • Page 32 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.3.5 Stop Motor Operation To stop the motor, return the potentiometer (VR101) to the center and set SW101 to Low. Power Source (Output: On) DC 24[V]/2[A] limit Evaluation Board LED0 LED1 LED2 LED3...
  • Page 33 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.2.3.6 Stop Power Supply. Stop the power supply. Power Source (Output: Off) DC 24[V]/2[A] limit Evaluation Board LED0 LED1 LED2 LED3 LED4 High Figure 3-9 Stop Power Supply. R12UZ0129EJ0100 Rev.1.00 Page 24 of 55...

  • Page 34: Sensorless 120-Degree Conducting Control

    (BEMF) generated by the motor rotation. Table 3-2 show the control specifications. For details of the specifics of the program, please refer to the “RAJ306101 Application Note: Sensorless 120-degree conducting control for permanent magnetic synchronous motor (Implementation) (R18AN0058EJ)".

  • Page 35: Board Settings

    RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.2 Board Settings In the sensorless 120-degree conducting control, the motor position is detected by zero-crossing of the inductive voltage (BEMF). The inductive voltage (BEMF) can be sensed by input the phase voltages to the differential amplifiers or BEMF sense amplifier of the smart gate driver.

  • Page 36: Operation Guide

    Hall signals.) c. Connect the power source and the Evaluation Board. (Do not supply power at this time.) The RAJ306101 RSSK includes a ferrite core to comply with the EMC Directive. Please use the ferrite core with 2 turns as necessary.
  • Page 37 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.3.2 Initial Setting Set the toggle switches (SW101, SW102) to Low and set the potentiometer (VR101) to center. (The state in which the knob mark is directly above the knob is called center. The potentiometer used on this board has a pivot point in the center position.)
  • Page 38 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.3.3 Power Supply Supply DC 24[V] to Evaluation Board by connecting the power source. The LED0 lights up when power is supplied. Power Source (Output: On) DC 24[V]/2[A] limit Evaluation Board LED0 LED1...

  • Page 39: Motor Operation

    RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.3.4 Motor Operation Set SW101 to High and turn the potentiometer (VR101). The motor rotates in the direction in which the potentiometer (VR101) is turned, according to the amount of turning. The LEDs light up according to the control.
  • Page 40 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.3.5 Stop Motor Operation To stop the motor, return the potentiometer (VR101) to the center and set SW101 to Low. Power Source (Output: On) DC 24[V]/2[A] limit Evaluation Board LED0 LED1 LED2 LED3...
  • Page 41 RAJ306101 RSSK User’s Manual Chapter 3. Usage 3.3.3.6 Stop Power Supply Stop the power supply. Power Source (Output: Off) DC 24[V]/2[A] limit Evaluation Board LED0 LED1 LED2 LED3 LED4 High Figure 3-16 Stop Power Supply R12UZ0129EJ0100 Rev.1.00 Page 32 of 55...

  • Page 42: Chapter 4. Peripheral Circuits

    4.3.4 Motor and supply the voltage according to the motor within the operating range of RAJ306101. In addition, a fuse is mounted between TB1 and TB2 of Evaluation Board. Replace the fuse capacity according to the motor drive current. When using external MOSFET board and shunt resistor mounted on the Evaluation Board, refer to 4.3.1.1 MOSFET and connect the external MOSFET board power...

  • Page 43: Peripheral Circuit Power Supply (Vdd(3.3[V]) Or Vcc(5.0[V]))

    (R4 / R5) of the external feedback resistors shown in Figure 4-2. These resistances on the Evaluation Board are R4 = 160[kΩ] and R5 = 91[kΩ], so the output voltage of the VDD pin is 3.310[V]. For details of VDD pin and VCC5V pin, refer to 5.1.2 in the "RAJ306101 User’s Manual: Hardware (R18UZ0081EJ)".

  • Page 44: Motor Drive Circuit

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits Motor Drive Circuit The Evaluation Board has MOSFETs, shunt resistors, and a thermistor for the MOSFET as a motor drive circuit. Also, it is possible to connect the external MOSFET board to CN_EXT_MOS (external MOSFET connector).
  • Page 45 RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits Table 4-2 External MOSFET Connector (CN_EXT_MOS) Pin Assignment Connector Terminal No. Terminal Function RAJ306101 Port CN_EXT_MOS P42/AN002 (IW), WIN (DA3N) P44/AN004 (DA3O) P42/AN002 (IW), WIP (DA3P) P44/AN004 (DA3O) VIN (DA2N) P45/AN005 (IV)

  • Page 46: Half-Bridges

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.1 Half-Bridges The Evaluation Board has inverter control circuit consisting of six MOSFETs for motor control. The MCU controls the MOSFETs through the smart gate driver by using six timer output functions. In addition, the bus voltage signals, U, V, W phase voltage signals, and shunt current signals can be input from the inverter control circuit to the A/D converter input port of the MCU on the Evaluation Board to measure these signals.
  • Page 47 RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.1.1 MOSFET The Evaluation Board has MOSFETs for the motor drive. It is also possible to connect external MOSFET board to CN_EXT_MOS (external MOSFET connector). The default setting of Evaluation Board has a 0[Ω] resistors mounted on the MOSFET connection selection resistors (R79-R87), so the MOSFET mounted on the Evaluation Board is enabled.
  • Page 48 The overcurrent detection signal OC# is High when the shunt current value is within the threshold range and Low when an overcurrent is detected. Therefore, as long as the MOSFETs and RAJ306101 are not broken, the Evaluation Board and the motor are protectable by monitoring the overcurrent detection signal OC# and forcing the timer output port into Low to make the MOSFET turn off.

  • Page 49: Sense Circuits

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.2 Sense Circuits 4.3.2.1 Current Sense (Internal) This Evaluation Board is also available to detect U, V, and W phase currents by connecting U, V, and W phase shunt resistors to the built-in differential amplifier of the smart gate driver. The differential amplifiers are disabled in the sample program.
  • Page 50 MCU. The relation between the phase current (Iin) flow to the shunt resistor (Rs) and the voltage input to the MCU (Vout) is expressed by EQ 4-2. For details of the shunt resistors and differential amplifier gain, refer to 5.1.6 in the "RAJ306101 User’s Manual: Hardware (R18UZ0081EJ)". AMP_VCC [ ���� ] Vout [ ����...
  • Page 51 RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits The Evaluation Board has jumpers to input from the shunt resistors to the MCU directly by bypassing amplifiers. When using these inputs, change the jumper JP301, JP302, and JP303 on the Evaluation Board to the appropriate connections.
  • Page 52 RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.2.3 Hall Input The Evaluation Board has a Hall sensor signal input connector (CN_HALL) with 3.3[V] or 5[V] pull-up resistors. The Hall sensor of the attached motor can be connected to the Hall sensor signal input connector (CN_HALL).

  • Page 53: Spare Circuit

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.2.5 Phase Voltage Detection The Evaluation Board has a voltage divider circuit to input the phase voltages (U, V, and W phase) to the A/D converter input port of the MCU through the built-in differential amplifier of the smart gate driver. The relation between the phase voltages and detection voltage is expressed by EQ 4-4.

  • Page 54: Motor

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.3.4 Motor The Evaluation Board and sample program are set according to the attached motor. When using a motor other than the attached motor, it may be necessary to change the setting parameters such as drive current settings and change the hardware.

  • Page 55: User Interface

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits User Interface 4.4.1 Potentiometer (VR101) & Toggle Switches (SW101, SW102) The Evaluation Board has a potentiometer (VR101) and toggle switches (SW101 and SW102). The potentiometer (VR101) is connected to P43/AN003 and uses it to indicate the amount of rotation and direction of rotation.

  • Page 56: Spi Connector

    UART signals. The UART is also used for the connection circuit with the motor control development support tool Renesas Motor Workbench through ICS_SEL jumpers, so when using the CN_UART connector, change all ICS_SEL jumpers to open. The CN_UART connector is not used in the sample program.

  • Page 57: General-Purpose Digital Input/Output Connectors

    RAJ306101 RSSK User’s Manual Chapter 4. Peripheral Circuits 4.4.6 General-purpose Digital Input/Output Connectors The Evaluation Board has through holes for CN_DIGI1 connectors and test points (TP_DIGI1) to confirm the input/output signals of the MCU. The CN_DIGI1 connectors are not used in the sample program.

  • Page 58: Chapter 5. Emulator Function

    Evaluation Board with USB micro-B cable for the firmware write. Use applications such as studio, CS+, or Renesas Flash Programmer to write firmware. On-board emulator circuit connected to the PC is recognized as E2 Lite, please set the connection accordingly. Refer to the document of e studio, CS+, Renesas Flash Programmer in detail.

  • Page 59: E 2 Studio

    RAJ306101 RSSK User’s Manual Chapter 5. Emulator Function 5.1.1 studio 1. Supply power to the Evaluation Board, then connect to PC by USB cable. 2. Execute e studio, click “Build All” from “Project” tab of e studio. Note.1 3. Click “Debug” from “Run” tab of e studio to write firmware.
  • Page 60 RAJ306101 RSSK User’s Manual Chapter 5. Emulator Function 5.1.2 1. Supply power to Evaluation Board, then connect to PC by USB cable. 2. Execute CS+, click “Build & Download” from “Debug” tab of CS+ to write firmware. Note.1 Figure 5-4 Firmware Write Note.1: This document is confirmed using CS+ for CC V8.09.0.

  • Page 61: Renesas Flash Programmer

    5.1.3 Renesas Flash Programmer 1. Supply power to Evaluation Board, then connect to PC by USB cable. 2. Execute Renesas Flash Programmer, then connect from menu “File” > “New Project…” in reference to Figure 5-5. Note.1 3. Select HEX file, then click “Start” in reference to Figure 5-6 to write firmware.

  • Page 62: Chapter 6. Renesas Motor Workbench

    Chapter 6. Renesas Motor Workbench The board is equipped with an evaluation version of the Renesas Motor Workbench (RMWB) and ICS host function. The sample program for this IC uses RMBK. Install RMWB on Windows PC, and connect PC and Evaluation Board with USB micro- b cable, monitor and change global variables from PC, and display graphs When using RMWB (ICS), it is necessary to set a jumper pin in ICS_SEL.

  • Page 63: Chapter 7. Information

    Address: Toyosu Foresia, 3-2-24, Toyosu, Koto-ku, Tokyo 135-0061, Japan ・Trademark and Type name Trademark: Renesas Product name: Renesas Solution Starter Kit Motor Control Evaluation System - Motor Control IC: RAJ306101 - Type name: RTK0EMXAH0S00020BJ Environmental Compliance and Certifications: ・Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU R12UZ0129EJ0100 Rev.1.00...

  • Page 64: Revision History

    RAJ306101 RSSK User’s Manual Revision History Revision History Revision Date Description Object Page 1.00 Nov 1, 2023 · Initial release. · All R12UZ0129EJ0100 Rev.1.00 Page 55 of 55 Nov 1, 2023...
  • Page 65 Renesas Solution Starter Kit Motor Control Evaluation System - Motor Control IC: RAJ306101 - Publication Date: Rev.1.00 Nov 1, 2023 Published by: Renesas Electronics Corporation...
