DESCRIPTION

The EVKT-MOTOR-00A is a communication

interface device that provides an interface

between a USB and a serial peripheral interface

(SPI) or I

C communication interface. It is

designed to work with MPS's motor drivers that

use a serial interface, as well as the motor

driver programming graphic user interface (GUI)

tool.

EVKT-MOTOR-00A

EVKT-MOTOR-00A Rev. 1.0

5/2/2023

MPS Proprietary Information. Unauthorized Photocopy and Duplication Prohibited.

Communication Interface Device for

The EVKT-MOTOR-00A kit includes one USB

communication device interface, one USB cable,

and one 10-pin ribbon cable. By working with

MPS's Motor Driver Programming GUI, the

EVKT-MOTOR-00A provides a quick and

simple way to evaluate the performance of MPS

motor drivers with serial interfaces.

Figure 1: EVKT-MOTOR-00A

MonolithicPower.com

EVKT-MOTOR-00A

USB Motor Driver Interface

Need help?

Do you have a question about the EVKT-MOTOR-00A and is the answer not in the manual?

Page 1 MPS’s Motor Driver Programming GUI, the (SPI) or I C communication interface. It is designed to work with MPS’s motor drivers that EVKT-MOTOR-00A provides a quick and use a serial interface, as well as the motor simple way to evaluate the performance of MPS driver programming graphic user interface (GUI) motor drivers with serial interfaces.
Page 2 EVKT-MOTOR-00A – USB TO SPI OR I C COMMUNICATION INTERFACE DEVICE EVKT-MOTOR-00A CONNECTION Ribbon USB Cable Cable Figure 2: EVKT-MOTOR-00A Connection RIBBON CABLE DESCRIPTION The EVKT-MOTOR-00A supports a 10-pin On certain evaluation boards, MOSI may be ribbon cable connection between called SDI, and MISO may be called SDO.
Page 3 EVKT-MOTOR-00A – USB TO SPI OR I C COMMUNICATION INTERFACE DEVICE QUICK START GUIDE 1. Connect the EVKT-MOTOR-00A to the evaluation board with the 10-pin ribbon cable and ensure that they are connected. 2. Connect the EVKT-MOTOR-00A to the computer using the supplied USB cable.
Page 4 5/2/2023 Initial Release Notice: The information in this document is subject to change without notice. Please contact MPS for current specifications. Users should warrant and guarantee that third-party Intellectual Property rights are not infringed upon when integrating MPS products into any application. MPS will not assume any legal responsibility for any said applications.
