UC-SB1-CAM-L-FLEX
UC Video Conference Smart Soundbar & Camera
The Crestron® UC-SB1-CAM-L-FLEX UC Video Conference Smart
Soundbar & Camera is a front-of-room device that eliminates the need to
install additional microphones, speakers, or cameras in a conference
space. It can be placed on a credenza beneath the room display(s) or
mounted on a wall.
In the Box
1
UC-SB1-CAM-L-FLEX, UC Video Conference Smart
Soundbar & Camera
Additional Items
4
Anchor, Drywall, Plastic, 3/8 in. x 1/2 in. (2052565)
1
Cable, USB 3.0, A - B, 6 ft (1.83 m) (2053077)
2
Foot, 2.3 in. x 0.96 in. x 0.15 in., Rubber (2052169)
1
Key, Anchor (4529654)
1
Power Cord, 5 ft 10 in. (1.78 m) (2042043)
1
Power Pack, 24 VDC, 2.5 A, 100-240 VAC (2045873)
4
Screw, 8-AB x 1-1/2 in., Pan Head, Combo (2052567)
1
Template, Overlay (4529513)
Quick Start
1
Advertisement
Related Manuals for Crestron UC-SB1-CAM-L-FLEX
Summary of Contents for Crestron UC-SB1-CAM-L-FLEX
- Page 1 Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera The Crestron® UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera is a front-of-room device that eliminates the need to install additional microphones, speakers, or cameras in a conference space. It can be placed on a credenza beneath the room display(s) or mounted on a wall.
- Page 2 Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera Install The soundbar can be placed on a flat surface or mounted on a wall. The soundbar has the following dimensions. Place on a Flat Surface If the soundbar is to be placed on a flat surface, attach the included rubber feet to the bottom of the soundbar as shown.
-
Page 3: Mount On A Wall
Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera Mount on a Wall The soundbar includes anchors that are suitable for mounting it on sheetrock walls up to 1/2 in. (13 mm) thickness. Masonry and other materials may require additional installer-supplied mounting hardware. - Page 4 Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera 2. Drill two pilot holes on each side of the center reference line as shown in the previous diagram. Each side should have one pilot hole drilled in each row of the template.
- Page 5 Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera 6. Place the wall bracket over the screws, and hand tighten the screws until the wall bracket is secured to the wall. 7. Route the cables through the cable cutout, and connect the cables as described in Connect.
- Page 6 Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera Connect Make the necessary connections as called out in the following diagram. Connect power last. PC: Connect the included USB cable to the PC port and to a USB port on the UC Engine. For optimal results, use a USB 3.0 connection.
-
Page 7: Operation
Quick Start UC-SB1-CAM-L-FLEX UC Video Conference Smart Soundbar & Camera Complete Operation Once all connections are made, pivot the soundbar up to the wall bracket Status until the soundbar locks into place. The front panel status bar illuminates to provide operational information. -
Page 8: System Control
Crestron Flex Wall Mount UC Video Conference System for Microsoft Teams® Software UC-B30-Z Crestron Flex Wall Mount UC Video Conference System for Zoom Rooms™ Software System Control When used as part of a Crestron Flex system, the soundbar is controlled by the system's touch screen. - Page 9 Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
