11. ERSATZTEILE

POS IDENT BEZEICHNUNG
SK 50 UHF
001 48642 Gehaeuseschale, hinten
002 48641 Gehauseschale, vorne
003 48639 Riegel, rechts
004 48640 Riegel, links
005 48309 Druckfeder (MOQ:10x)
006 48310 Zapfenschraube M2x2 DIN927 (MOQ:50x)
007 44898 Zylinderschraube M2x8 (MOQ:10x)
008 47479 Blende
009 47481 Klammer
010 48819 Wurfantenne
011 33151 Schrumpfschlauch
012 22451 Zylinderschraube M1,4x4 DIN84 (MOQ:10x)
013 47476 Typenschild
014 48178 Schluessel fuer Kanalwahl
C001 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C002 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C003 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C004 45195 SMD Kondensator KERKO 1nF 50V X7R (MOQ:50x)
C005 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C006 45363 SMD Trimmkondensator 4,5/20pF (MOQ:50x)
C007 45180 SMD Kondensator KERKO 33pF 50V NPO (MOQ:50x)
C008 45184 SMD Kondensator KERKO 68pF 50V NPO (MOQ:50x)
C009 45195 SMD Kondensator KERKO 1nF 50V X7R (MOQ:50x)
C010 45201 SMD Kondensator KERKO 10nF 50V X7R (MOQ:50x)
C011 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C012 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C013 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C014 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C015 45195 SMD Kondensator KERKO 1nF 50V X7R (MOQ:50x)
C016 45179 SMD Kondensator KERKO 27pF 50V NPO (MOQ:50x)
C017 45239 SMD Kondensator KERKO 150nF 50V X7R (MOQ:50x)
C018 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C019 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C020 41414 SMD Kondensator TA-KO 1uF 16V
C021 45364 SMD Trimmkondensator 2,0/6,0pF (MOQ:50x)
C022A 45186 SMD Kondensator KERKO 100pF 50V NPO (MOQ:50x)
450-550MHz
C022B 45186 SMD Kondensator KERKO 100pF 50V NPO (MOQ:50x)
550-680MHz
C022C 45174 SMD Kondensator KERKO 10pF 50V NPO (MOQ:50x)
680-800MHz
C022D 45164 SMD Kondensator KERKO 1,5pF 50V NPO (MOQ:50x)
800-960MHz
C023 45195 SMD Kondensator KERKO 1nF 50V X7R (MOQ:50x)
C024 45043 SMD Kondensator TA-KO 2,2uF 16V IEC 384,3
C025 45086 SMD Kondensator TA-KO 100nF 35V (MOQ:50x)
C026A 45172 SMD Kondensator KERKO 6,8pF 50V NPO (MOQ:50x)
450-550MHz
C026B 45172 SMD Kondensator KERKO 6,8pF 50V NPO (MOQ:50x)
550-680MHz
C026C 45173 SMD Kondensator KERKO 8,2pF 50V NPO (MOQ:50x)
680-800MHz
C026D 45173 SMD Kondensator KERKO 8,2pF 50V NPO (MOQ:50x)
800-960MHz
C027A 45174 SMD Kondensator KERKO 10pF 50V NPO (MOQ:50x)
450-550MHz
C027B 45174 SMD Kondensator KERKO 10pF 50V NPO (MOQ:50x)
550-680MHz
C027C 45170 SMD Kondensator KERKO 4,7pF 50V NPO KEFQ (MOQ:50x)
680-800MHz
C027D 45170 SMD Kondensator KERKO 4,7pF 50V NPO KEFQ (MOQ:50x)
800-960MHz
C028A 45172 SMD Kondensator KERKO 6,8pF 50V NPO (MOQ:50x)
450-550MHz
C028B 45172 SMD Kondensator KERKO 6,8pF 50V NPO (MOQ:50x)
550-680MHz
C028C 45171 SMD Kondensator KERKO 5,6pF 50V NPO (MOQ:50x)
680-800MHz
SK 50 UHF / SK 250 UHF
01 / 93 – 26

11. SPARE PARTS

DESCRIPTION
SK 50 UHF
Housing shell, rear
Housing shell, front
Locking bar, right
Locking bar, left
Pressure spring (MOQ:10x)
Shank screw M2x2 DIN927 (MOQ:50x)
Chees head screw M2x8 (MOQ:10x)
Cover
Clip
Antenna
Shrinking tube
Cheese head screw M1.4x4 DIN84 (MOQ:10x)
Type plate
Adjusting tool for channel selection
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor KERKO 1nF 50V X7R (MOQ:50x)
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor variable 4.5/20pF (MOQ:50x)
SMD capacitor KERKO 33pF 50V NPO (MOQ:50x)
SMD capacitor KERKO 68pF 50V NPO (MOQ:50x)
SMD capacitor KERKO 1nF 50V X7R (MOQ:50x)
SMD capacitor KERKO 10nF 50V X7R (MOQ:50x)
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor KERKO 1nF 50V X7R (MOQ:50x)
SMD capacitor KERKO 27pF 50V NPO (MOQ:50x)
SMD capacitor KERKO 150nF 50V X7R 1206 (MOQ:50x)
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 1uF 16V
SMD capacitor variable 2.0/6.0pF (MOQ:50x)
SMD capacitor KERKO 100pF 50V NPO (MOQ:50x)
450-550MHz
SMD capacitor KERKO 100pF 50V NPO (MOQ:50x)
550-680MHz
SMD capacitor KERKO 10pF 50V NPO (MOQ:50x)
680-800MHz
SMD capacitor KERKO 1.5pF 50V NPO (MOQ:50x)
800-960MHz
SMD capacitor KERKO 1nF 50V X7R (MOQ:50x)
SMD capacitor TA-KO 2.2uF 16V IEC 384,3
SMD capacitor TA-KO 100nF 35V (MOQ:50x)
SMD capacitor KERKO 6.8pF 50V NPO (MOQ:50x)
450-550MHz
SMD capacitor KERKO 6.8pF 50V NPO (MOQ:50x)
550-680MHz
SMD capacitor KERKO 8.2pF 50V NPO (MOQ:50x)
680-800MHz
SMD capacitor KERKO 8.2pF 50V NPO (MOQ:50x)
800-960MHz
SMD capacitor KERKO 10pF 50V NPO (MOQ:50x)
450-550MHz
SMD capacitor KERKO 10pF 50V NPO (MOQ:50x)
550-680MHz
SMD capacitor KERKO 4.7pF 50V NPO KEFQ (MOQ:50x)
680-800MHz
SMD capacitor KERKO 4.7pF 50V NPO KEFQ (MOQ:50x)
800-960MHz
SMD capacitor KERKO 6.8pF 50V NPO (MOQ:50x)
450-550MHz
SMD capacitor KERKO 6.8pF 50V NPO (MOQ:50x)
550-680MHz
SMD capacitor KERKO 5.6pF 50V NPO (MOQ:50x)
680-800MHz
