- Page 1 Installation Guide Mini Series Hero...
-
Page 2: Package Contents
Hero Package Contents 1X32.8ft SMAM-NM Outdoor Cable Booster Booster Outside Antenna Indoor Whip Antenna 1X16.4ft SMAF-SMAM Outdoor Cable 1X30ft SMAM-NM indoor cable Through-Window-Cable Waterproof tape Indoor Antenna Indoor Antenna Power Supply Other accessories to protect connections SMA-Male to SMA-Female No drilled hole Notes for LCD Display Power light Bluetooth light... -
Page 3: Getting Started
Booster Light Patterns LED Type LED condition Remark Successfully connected to Bluetooth Bluetooth Bluetooth is not connected Successfully connected to Wi-Fi Wi-Fi Wi-Fi is not connected Normal operating condition Solid Green Power Solid Red Booster is working abnormally Booster is not receving power from DC power supply Booster is working normally Alarm Booster is working abnormally... - Page 4 Find the cell tower & Determine the outdoor antenna’s position Step 3 3.1 Find the band you are using For Android Download NetWork Cell Info Lite in the Google store and open it. It can be seen from the example picture that the frequency band is band 13. (According to the form before, you need to pay attention to Gauge LTE700) Then click MAP.
- Page 5 For ios AT & T AT & T (1)Dial *3001#12345#* (2)Follow the instructions, take the screenshots as required. 3.2 Find the cell tower (1) Enter cellmapper.net (2) Choose your own carrier and band here.
- Page 6 (3) Then enter the coordinate of where you are trying to install the signal booster, and press Enter key. (In fact when you open Cellmapper, the map on the right will automatically locate your area if you've given the site permission to access your location. If you found tower sites not even displayed on the map, it might because the app intercepts the locations for security reasons.) (4) After the map jumps to the location, you can scroll the mouse pulley and zoom it out,...
- Page 7 3.3 Determine the outdoor antenna’ s position The outdoor antenna is usually placed at one of the 4 ends of the roof. Please choose the position according to the tower’ s location. Make sure there are no barriers between the antenna and the tower. Connect the outdoor antenna with the booster Step 4 Outdoor Antenna...
- Page 8 Adjust and fix the Outdoor Antenna Step 5 Have your outdoor antenna pointed to the cell tower you found before and observe the reading on the app. Adjust the outdoor antenna accordingly. Notes: (1) The output power should be the higher the better. (2) The full output power for Hero is 12dBm.
- Page 9 6.3 Signal quality test You could do the following: (1)First make sure the signal gauge value is unchanged from that during the outdoor antenna installation. (2)Do speed tests with the booster on and off, and make a comparison. (3)Check if the number of signal bars increases. (4)Make a phone call or send messages and check if the voice and streaming are better.
- Page 10 6.3 Signal quality test You could do the following: (1)First make sure the signal gauge value is unchanged from that during the outdoor antenna installation. (2)Do speed tests with the booster on and off, and make a comparison. (3)Check if the number of signal bars increases. (4)Make a phone call or send messages and check if the voice and streaming are better.
- Page 11 LOOP BACK DL GAIN OUTPUT POWER LED LIGHT PATTERN REASON SOLUTION LTE700 <60dB <8dBm 1、Increase vertical and Alarm light flashing horizontal distance. Inadequate and Power light solid CELL800 <60dB <8dBm 2、Add barriers(e.g. walls) separation of the red(strong loop Please try these solutions until indoor and outdoor back) or green(slight PCS1900...
-
Page 12: Technical Specifications
Input AC100~240 V, 50/60 Hz, Output DC 12 V / 3 A Power Supply For more information Download Signal Supervisor or enter our website www.hiboost.com. a. You can download the specific user manual. b. You can reach our technical support for help. 3150 Premier Drive,Suite 130,... - Page 13 3150 Premier Drive,Suite 130, Irving, TX 75063 (972) 870-5666 service@hiboost.com www.hiboost.com...
