Home Styles 88 9001 007C Manual

88 9001 007C
Cuisine Cart
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A. B.
Side Panel Side Panel
1 Pc. 1 Pc.
H.
Side Rack
1 Pc.
Side Rack
1 Pc.
Hardware List
Caster
two lock
two non-lock
4 Pcs.
Tools required for assembly : Phillips screwdriver
C.
Base
1 Pc.
J.
Brush Chrome Pipes
3 Pcs.
K.
Base Rack
1 Pc.
I.
L.
Side Tower Bar
1 Pc.
M6x30
Head Cap Bolt(Middle)
for Top
Hex Wrench
4 Pcs. (+1 extra)
1 Pc.
M6x35
Small Hex Wrench
Head Cap Bolt(long)
1 Pc.
12 Pcs. (+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
D. E.
Back Upright Back Panel
2 Pcs.
1 Pc.
N.
Door
1 Pc.
M6x25
Head Cap Bolt
for Side Tower Bar
2 Pcs. (+1 extra)
M4x20
Machine Screw
for Knob
2 Pcs.
F.
Back Stretcher
1 Pc.
G.
Front Rail
1 Pc.
M.
Shelf
1 Pc.
P.
Drawer
1 Pc.
O.
Door (Please refer to the last page of these
instruction for drawer assembly steps)
1 Pc.
M4x16
Wood Screw
for Caster
16 Pcs. (+1 extra)
Adjustable Pin
4 Pcs. (+1 extra)
Knob
2 Pcs.
Wood Plug
8 Pcs. (+1 extra)
