REMOTE CONTROL
* Check buttons already used for learning.
NOTE:
(TV) - (VCR)
id
NOTE:
46
<ARB1420>
{Procedure for presetting] :
1, Press the EDIT button to switch to the EDIT mode..."
2. Press one of the CONTROL MODE buttons (VCR 1, ven 2 OrTyy,
3. Press one of the buttons 1 te 12. :
* One kind of code is preset. a
* To continue presetting, repeat Coeration procedures 2 and 3.
4. Press the EDIT button. Bald
* The EDIT mode is canceled. oe Se
5. Confirm that the component (TV or VCR) can be operated by the
preset code. a :
if operation is not possible, repeat S72 procedures from step 2, and
press a different number button (7 —12) at step 3 to search for a
preset code that enables operation.
eter to the diagram on page 44,
[Operation example]
How to preset in VCR 1.
1. Press the EDIT button.
© The VCR 4, VCR 2, and TV
CO%\ TROL MODE buttons flash in
sequence.
2. Press the VCR 1 CONTROL MODE button,
* Only the VCR 1 button flashes.
3. Press one of the buttons 7 to 12.
* For example, if you press buttcn 1, the remote contro! signal
format selected with VCR 1 operation button 1 is preset.
The CONTROL MODE buttons li¢t in sequence (indicating that
registration has been corpletec'. and then the VCR 1, VCR 2,
and TV buttons flash in sequence. 'Returning to the condition in
procedure 1.)
* To continue presetting for VCR 2 and TV, repeat operation
procedures 2 and 3.
4. Press the EDIT button.
* The EDIT mode is canceled.
5. Point the remote control at the sensor window of the VCR you
want to operate and press an operation button to confirm that
operation is possible.
* If operation is possible, presetiimg has been completed.
* If operation is not possible, recsat operations from step 2,
selecting a different number button (1 to 12) at step 3.
If there is a button among buttons 7 to 12 that cannot operate,
press the EDIT button once more te cancel the EDIT mode, and
memorize in the LEARN mode.
NOTE:
* After pressing the EDIT button, if you do not press a button within
about one minute, the EDIT mode és canceled. :
* After presetting, you can use the LEARN mode to memorize a
command in a preset button, but m2 preset signal is erased,
° After memorizing in the LEARN mode, if you preset operations
under specified buttons, signals memorized in the LEARN mode
are Cleared.
MULTI-EDIT MODE
A maximum of seven commands cém De programmed into MULTI
COMMAND button. This enables 4 series of signals to be transmitted
simply by pushing the MULTI COMMAND button.
MULT! COMMAND button.
@ RECEIVER POWER
@ RECEIVER FUNCTION CD
@ CD PLAY (m)
sequence, ;
2. Press the MULTI COMMAND
button. {Switches to the MULTI
EDIT mode)
* The CONTROL MODE buttons fash at random.
3. Press the RECEIVER POWER button.
© The CONTROL MODE buttons ga o-1, and then flash at random.
{Registration is completed}
