Stacking Instructions

Fig. 1
1. Remove all (15) screws as shown on the top,
right, and left sides of the bottom unit. (Fig. 1)
Fig. 3
Front
Connector
Rear
Connector
3. Install (2) brackets to bottom of the cabinet that
will stack on top with (6) screws. (Fig. 3)
NOTE: Pay attention to the direction of the
bracket.
4
Fig. 2
2. Remove casters from the cabinet that will stack
on top. (Fig. 2)
Fig. 4
Top Unit
with Brackets Installed
Bottom Unit
4. Place the upper cabinet on top of the lower
cabinet. (Fig. 4a)
5. Secure the stacking brackets onto the bottom
unit with the original screws taken from the
bottom unit in step 1. (Fig. 4b)
.
