- Page 1 Horizon Elite 1412 Ice Machine Installation Instructions ™ for Remote Condensing Unit HMF1412R _ _ 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 www.follettice.com 01519131R00...
- Page 2 Horizon Elite 1412 series W1 Width 39.6” (100.6 cm) D1 Depth 28.2” (71.6 cm) H1 Height 26.0” (66.0 cm) Electrical three phase – 208-230/60/3 (Emerson/Copeland) Minimum circuit ampacity three phase – 12A Maximum overcurrent protection three phase – 20A Outdoor condensing unit operating limits min –20 F (–29 C)
-
Page 3: Site Preparation
Prior to installation, carefully unpack and inspect the contents of your condensing unit! Site preparation To ensure proper performance, ease of service and warranty coverage, it is critical that you follow the requirements detailed in this manual. If you cannot meet these requirements or have questions, call our technical service group at 877.612.5086 for installation support. - Page 4 Condenser installation specifications ➍ Low voltage control (24 Vac) required CONDENSER UNIT 100' max. ➍ (30.5 m) maximum ➊ line rise P-trap ➋ S-trap required required ➊ +35' (+10.7 m) +20' (+6.1 m) P-trap required CORPORATION Easton Pennsylvania MODEL SERIAL NO PART NO SINGLE FULL LOAD AMPS...
-
Page 5: Condenser Installation
• 1412N not compatible with rack system. Consult Technical Service. Electrical requirements CAUTION • Electrical disconnects required • Electrical disconnects installed in accordance with NEC and local electrical codes Horizon Elite 1412 series Minimum circuit ampacity three phase – 12A Maximum overcurrent protection three phase – 20A Outdoor condensing unit operating limits min –20 F (–29 C) - Page 6 Electrical schematic 3-PHASE, 208-230 VAC F1x12CU OUTDOOR CONDENSING UNIT ICE MAKER DISCH DOCKING SIGNAL, FIELD SIDE HIGH DISCH STATION WIRED,CLASS 2 RELAY PRESS SW T-STAT BLK H1 10 RED 16AWG TB2-1, TB2-2 CRANKCASE 11 BLK 16AWG HEATER BLK H2 1 2 3 4 5 6 GRN/YEL 1 2 3 4 5 6 12 BLU 18AWG...
- Page 7 Phase monitor adjustments (if necessary) The phase monitor is preset to 208 Vac from the factory. If building voltage is less than 208 Vac, consult technical service. See below chart for phase monitor diagnostics. PLEASE NOTE THAT ANY TIME POWER IS APPLIED TO THE CONDENSING UNIT, OR THE UNIT COMES OUT OF A FAULT STATE, IT WILL TAKE APPROXIMATELY 200 SECONDS FOR THE UNIT TO POWER ON.
- Page 8 Condensing unit refrigeration line-set connection point 1412: 7/8" OD suction line 3/8" OD liquid line REMOTE CONDENSING UNIT...
-
Page 9: Refrigeration Line Installation
Refrigeration line installation Refrigeration line installation: 7/8" OD suction line / 3/8" OD liquid line CAUTION • The installer of the refrigeration line set must be USA Government Environmental Protection Agency (EPA) certified in proper refrigeration handling and service procedures •... -
Page 10: Low Voltage Control
Route low voltage wire through the upper knockout at the condensing unit and secure with appropriate connector per NEC. Follett suggests the following wire for the ice machine signal wire (2 conductor, 18 gauge thermostat wire), but be sure to follow NEC guidelines:... - Page 11 Hail hood Install hail hood 1. Hail hood is shipped taped to the unit. 2. Install hail hood using enclosed self-tapping screws (attached to udnerside of hail hood). HOOD TAPED IN PLACE FOR SHIPPING HOOD INSTALLED REMOTE CONDENSING UNIT...
-
Page 12: Start Up And Test
ZF06KAE-TF5-118 (Copeland) Max continuous current: 11.6A Harmony, Horizon, Horizon Elite, Ice Manager, and Vision are trademarks of Follett Products, LLC. Chewblet, RIDE and Follett are registered trademarks of Follett Products, LLC, registered in US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 •...
