Section 2 - Installation
Power
Plug the DHP-P600AV into an AC wall outlet or power strip.
Note: Power supply is confirmed when the Power LED on the DHP-P600AV is illuminated.
Connect the Ethernet Cable
Connect the included Ethernet cable to
the network cable connector located on
the DHP-P600AV and attach the other end
of the Ethernet cable to the network or PC.
Network connectivity is confirmed when
the Ethernet LED on the DHP-P600AV are
illuminated.
D-Link DHP-P600AV
Hardware Installation
ROOM A
1
Internet
Router
ROOM A
3
Internet
DHP-P600AV
DHP-P600AV
Router
ROOM B
2
DHP-P600AV
PC
ROOM B
DHP-P600AV
PC
8
