DS-H2U
UVC HDMI 4K Capture
USB-C 4K Video Capture Box with Scaler,
HDMI 2.0 loop-Out, Audio & HDR10 to SDR Conversion
User Manual English
AREC Inc.© All Rights Reserved 2023. l www.arec.com
All information contained in this document is Proprietary

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-H2U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arec DS-H2U

Summary of Contents for Arec DS-H2U

  • Page 1 DS-H2U UVC HDMI 4K Capture USB-C 4K Video Capture Box with Scaler, HDMI 2.0 loop-Out, Audio & HDR10 to SDR Conversion User Manual English AREC Inc.© All Rights Reserved 2023. l www.arec.com All information contained in this document is Proprietary...

  • Page 2: Table Of Contents

    WARRANTY INTRODUCTION The AREC DS-H2U USB-C 4K Video Capture Box with Scaler, HDMI 2.0 loop out, Audio & HDR10 to SDR Conversion provides a professional way to capture HDMI video signals. It adopts USB 3.1 Type-C Gen 1 (USB 3.0) interface, which can realize high-speed transmission. In addition, the HDMI input and loop out can support up to 4K2K@60.

  • Page 3: Features

    4. Video output format is related to the software limitation. For example, the AMCap software does not support NV12 format * Scale-up supports up to 1080P@60 ** NOT supports HDR10 plus, HLG, and Dolby Vision to SDR conversion PACKAGE CONTENTS ▪ 1x AREC DS-H2U ▪ 1x Quick Guide...

  • Page 4: Specifications

    Power supply Via USB-C Power consumption 3.5 Watts [ max ] Operation temperature 0~40°C [ 32~104°F ] Storage temperature -20~60°C [ -4~140°F ] Relative humidity 20~90% RH [ no condensation ] * “DS-H2U follows the High-bandwidth Digital Content Protection (HDCP) rule.”...

  • Page 5: Panel Descriptions

    DS-H2U User Manual PANEL DESCRIPTIONS 1. STEREO AUDIO OUT: Audio extracts from HDMI input 2. STEREO AUDIO IN: Connect to the analog stereo audio source 3. LED INDICATOR: HDMI input signal indicator LED 4. USB-C OUT: Connect to a USB host (PC, NB, MAC…) 5.

  • Page 6: Video Streaming

    DS-H2U User Manual VIDEO STREAMING Create a Video Streaming Users can create video streams on the streaming service platform. The below steps show how to complete the video streaming settings from Twitch and YouTube. Twitch 1. Browse the Twitch website (https://www.twitch.tv/) and log in, then select "Creator...
  • Page 7 DS-H2U User Manual 3. Go back to Twitch and select "Channel" from your account drop-down menu. 4. At this point, you will see the player start live streaming. LIVE...
  • Page 8 * If your account is using YouTube for the first time to create a video stream, you need to wait 24 hours to enable the function. 2. Go to the "Webcam" and edit the streaming details. Click on the next. 3. Select “4K Capture DS-H2U” as your source.
  • Page 9 DS-H2U User Manual 4. The player on YouTube will start live streaming.
  • Page 10 DS-H2U User Manual Stream and record videos with OBS OBS is popular USB capture freeware and has excellent compatibility. Please start with OBS if users are not familiar with USB capture devices. Stream and record videos with OBS Browse the download page of the OBS official website (https://obsproject.com/download), then select the suitable computer operating system and start downloading.
  • Page 11 DS-H2U User Manual 1. First, find the "Scenes" window, click "+" in the lower left corner, and then enter the name of the scene to create a new scene.
  • Page 12 DS-H2U User Manual 2. Find the "Source" window, click "+" in the lower left corner, and then select "Display Capture" or "Video Capture Device" to create a new source.
  • Page 13 DS-H2U User Manual 3. Next, you can set display capture properties. If you select "Display Capture" in step 2, you can select the primary monitor or other extended monitors as the display source. If you select "Video Capture Device" in step 2, you can select a USB video device as the display source. After al,l settings are completed, click “OK”.
  • Page 14 DS-H2U User Manual 5. Paste the stream key provided by the service provider into the "Stream Key" field, then click "Apply" and "OK" after setting. In addition, users can click "Get Stream Key" at this step to open the service provider website.

  • Page 15: Troubleshooting

    DS-H2U User Manual TROUBLESHOOTING DS-H2U has done comprehensive tests before shipment. Most of the incompatibilities we have experienced are not from the USB capture device itself but from the sophisticated software and hardware combination of PC or laptop. Please follow the following suggestions to see any help.

  • Page 16: Warranty

    DS-H2U User Manual WARRANTY The SELLER warrants the DS-H2U 4K HDMI USB Capture with Scaler, HDMI 2.0 loop-out, Audio & HDR10 to SDR Conversion to be free from defects in the material and workmanship for 1 year from the date of purchase from the SELLER or an authorized dealer.
  • Page 17 All information contained in this document is Proprietary Made in Taiwan Date : 2023.01.01 Version : 221110 AREC have the right to change or improve product specifications, without obligation to notify any user. Go to www.arec.com get the latest information related to the product or additional information.
