Wiring Schematic - Whirlpool L30P Installation And Operation Manual

Wiring Schematic

Power
Supply
120 V AC
60 Hz
Turbine
Sensor
Back of Electronic
Controller (PWA)
Power Position/
In Turbine
24 V DC
OUT
GND
+5
22
Motor
Valve
Motor
grn
Position
NO
Switch
org
NC
C
FIG. 38
