- Page 1 LIP Phone 6830 User Guide SIP (Session Initiation Protocol) for Sylantro, SIP4B Please read this guide carefully before operating your set. Retain this guide for future reference. LGN6830-1235SSUG-01.03 Sept 07...
- Page 2 This material is copyrighted by LG-Nortel Co Ltd. Any unauthorized reproduction, use or disclosure of this material, or any part thereof, is strictly prohibited and is a violation of Copyright Laws. LG-Nortel reserves the right to make changes in specifications at any time without notice.
- Page 3 • Do not use during lightning storms. Lightning presents a potential shock hazard. • Clean the LIP Phone 6830 with a soft dry cloth; do not use liquid cleaners. • Always use caution when connecting to AC power. Use only with a properly grounded standard AC power outlet.
-
Page 4: Table Of Contents
Accessing Your Voice Mail ......................8 3.16. DSS/BLF Coverage ........................8 3.17. Hotline/Warm-Line ........................9 Advanced Services and the LIP Phone 6830 LCD Menu .........10 4.1. Using the Call Logs Menu......................10 4.2. Using the Phone Book Menu ...................... 10 4.3. - Page 5 LIP Phone 6830 User Guide 5.6.2. Time Zone........................... 21 5.6.3. DST Auto Adjustment ......................21 5.6.4. Time Format........................22 5.6.5. Date Format ........................22 5.7. Lock Outgoing Call ........................23 5.8. Enabling Speed Number Dialing ....................23 Appendix A Dial Pad Character Set ................24 Appendix B Time Zones....................25...
-
Page 6: Lip Phone 6830 Overview
IP network. Features available to LIP Phone 6830 through SIP call servers are similar to those of a conventional business telephone. In addition to the features described in this guide, your call server may provide additional features, often using dialed feature codes. - Page 7 Flexible buttons not assigned for line access may access features such as Speed dial, DND, Redial and others. Refer to the Setting Flexible buttons section under Setting Your Preferences for instruction on defining flexible buttons. The figure below shows other major components of LIP Phone 6830. These components include: • Handset • Speaker and microphone •...
-
Page 8: Installing Your Lip Phone 6830
LIP Phone 6830 User Guide 2. Installing your LIP Phone 6830 The figure below shows the cable connections for your LIP Phone. The LAN and desktop PC connections employ standard category 5 cables terminated with RJ-45 connectors. The LIP Phone supports PoE (Power over Ethernet) in accordance with the IEEE-802.1af standard. -
Page 9: Using Features Of Lip Phone 6830
3.2. Placing a Call You place calls with the handset on-hook or off-hook. Similar to your mobile phone, LIP Phone 6830 uses a technique called ‘store and forward dialing’. After you dial a digit, the LIP Phone waits about 10 seconds for additional digits. -
Page 10: Announcing A Call Transfer
LIP Phone 6830 User Guide [Rsum] o Press the slow flashing line button, or the softkey. To toggle between two calls on the same line: o Press the line button, the active call status changes to hold and the held call connects. -
Page 11: 3-Party Conference
LIP Phone 6830 User Guide [CFwd] o Press softkey. The message “Fwd to xxxx” disappears from the LCD. 3.7. 3-Party Conference The LIP Phone has a 3-Party Conference feature that lets you converse with two other parties simultaneously. To set-up a conference: o Place first call as normal. -
Page 12: Speed Dial Buttons
Speed dial button. o Lift the handset for privacy or press the headset button to use the headset 3.12. Speed Number Dialing LIP Phone 6830 incorporates a Phone Book with up to 100 records. Refer to section 4.2 for information on use of the Phone Book. -
Page 13: Accessing Your Voice Mail
To listen to your messages, follow the instructions for your voice mail system. 3.16. DSS/BLF Coverage The LIP Phone 6830 has a DSS line type that addresses the special needs associated with an Attendant or Secretarial answering position. The specific needs for these users are: •... -
Page 14: Hotline/Warm-Line
LIP Phone 6830 User Guide 3.17. Hotline/Warm-Line With Hotline/Warm-Line operation configured, the LIP Phone automatically calls the defined destination when you take the handset off-hook or press the speaker button. The call initiates immediately, Hotline, or after a delay of up to 10 seconds, Warm-Line. The later permits you the time to access another feature or line as needed. -
Page 15: Advanced Services And The Lip Phone 6830 Lcd Menu
4.1. Using the Call Logs Menu The LIP Phone 6830 has access to a log of all calls placed or received by the phone, including incoming calls that were not answered (missed calls). The LCD displays the call logs that you can use to place a call to the logged party. - Page 16 LIP Phone 6830 User Guide [Prev]-[Next] o Use the softkeys to display the desired record or dial the digit preceding the desired record. [Dial] o Press the softkey. To add a record to the Phone Book: Phone Book (Page 1) o Press the Phone Book flexible button.
-
Page 17: Park
LIP Phone 6830 User Guide To delete all records: o Press the Phone Book flexible button. Phone Book (Page 1) [DALL] >[01]Tom,1234 o Press the right arrow softkey to locate the [DALL] [Find] softkey. [DALL] o Select softkey and confirm the deletion by [Yes ] softkey. -
Page 18: Directed Call Pickup
LIP Phone 6830 User Guide [Pick] o Press the softkey. The LIP Phone activates the Input Extension speakerphone and selects your line. You may select a [Pick] different line button prior to pressing the softkey. ] [Mode] [ OK ]... -
Page 19: Acd Agent Menu
LIP Phone 6830 User Guide 4.8. ACD Agent Menu Your call services may include Automatic Call Distribution (ACD). Calls to an ACD group enter a queue and the call routes to the next available ACD agent. This feature is useful for customer support groups, user taking reservations, or making appointments. - Page 20 LIP Phone 6830 User Guide To set the extension to the “unavailable” status: o Press the ACD Agent button. ACD Status (Line 1) [Unvl] o Press the line button, and then press the Available [Unvl] softkey. The softkey appears only if the Agent [Unvl] [COut] [PRIM] is available.
-
Page 21: Setting Your Preferences
LIP Phone 6830 User Guide 5. Setting Your Preferences In the LCD Menu, you can set various preferences for the LIP Phone. Settings you can adjust include: LCD contrast Ring Setting Ringer off Headset auto mode Flexible button settings Time Configuration... -
Page 22: Setting Line Ring Type And Delay
LIP Phone 6830 User Guide 3.Phone Settings [Prev]-[Next] o Dial 3, or move the cursor to using the softkeys and press the [ OK ] softkey. 2.Ring Setting o Dial 2, or move the cursor to using the [Prev]-[Next] [ OK ] softkeys and press the softkey. -
Page 23: Ringer Off
5.4. Enabling Automatic Headset Operation LIP Phone 6830 supports use of a headset with a standard 2.5 mm plug. In the Headset Auto Mode, pressing a line button automatically connects audio to the headset. Also, redial, Speed dial, Speed number dialing and click-to-call place calls with audio through the headset. -
Page 24: Setting Flexible Buttons
5.5. Setting Flexible Buttons Your LIP Phone 6830 has twenty-four (24) flexible buttons. Normally, the first two (2) buttons are for your line. The flexible buttons not assigned as line buttons can access various functions. The table below indicates the available functions with a brief description of each. -
Page 25: Time Configuration
5.6.1. SNTP Server Address SNTP (Simple Network Time Protocol) is a standard protocol that permits a network device to obtain the network’s current time. For operation with SNTP, the LIP Phone 6830 requires an SNTP server IP address or name. -
Page 26: Time Zone
5.6.3. DST Auto Adjustment The LIP Phone 6830 automatically adjusts for DST (Daylight Savings Time) when enabled. To enable/disable automatic daylight savings time: o Press the button. -
Page 27: Time Format
LIP Phone 6830 User Guide 5.6.4. Time Format The format of the LCD time display can be set for 12-hour format or 24-hour format. In addition, the LCD time display can be disabled. To set the display format for time: o Press the button. -
Page 28: Lock Outgoing Call
5.8. Enabling Speed Number Dialing The LIP Phone 6830 includes a Phone Book that supports up to 100 entries. Each Phone Book record includes a two-digit Speed number, see Speed Number Dialing. -
Page 29: Appendix A Dial Pad Character Set
LIP Phone 6830 User Guide Appendix A Dial Pad Character Set The LIP Phone 6830 dial pad inputs digits or alphanumeric characters. The table below maps between each dial pad digit to characters. Dial Pad Mode Digit Upper Case Lower Case Symbols ‘[A]’... -
Page 30: Appendix B Time Zones
LIP Phone 6830 User Guide Appendix B Time Zones Country Country GMT-12:00 International Date Line, West GMT+01:00 Oslo, Norway GMT-11:00 Midway/Samoa GMT+01:00 Paris, France GMT-10:00 Hawaii GMT+01:00 Rome, Italy GMT-09:00 Alaska GMT+01:00 Stockholm, Sweden GMT-08:00 Los Angeles, California GMT+01:00 Vienna, Austria... - Page 31 LIP Phone 6830 User Guide Oct. 07...
- Page 32 LGN6830-1235SSUG-01.03 Oct. 07...
