AQUABOOST
Installation, Operation & Maintenance
Instructions
Please leave this instruction booklet in a safe place as it contains
important warranty, maintenance and safety information
Read this manual carefully before commencing installation.
This manual covers the following products:
Model
iBolt Pump
iBolt Single Pump Booster Set
iBolt Twin Pump Booster Set
iBolt Three Pump Booster Set
Please note images are representative only and may not portray your model
Advertisement
Table of Contents
Related Manuals for Stuart Turner iBOLT 0304 3H-CMT/24
Summary of Contents for Stuart Turner iBOLT 0304 3H-CMT/24
- Page 1 AQUABOOST Installation, Operation & Maintenance Instructions Please leave this instruction booklet in a safe place as it contains important warranty, maintenance and safety information Read this manual carefully before commencing installation. This manual covers the following products: Model iBolt Pump iBolt Single Pump Booster Set iBolt Twin Pump Booster Set iBolt Three Pump Booster Set...
-
Page 2: Table Of Contents
CONTENTS PRODUCT OVERVIEW ....................3 2 WARNINGS ........................ 4 3 CHECKLIST ........................ 6 4 IMPORTANT - READ BEFORE COMMENCING INSTALLATION ....... 10 5 LOCATION - GENERAL ..................... 11 6 KEY FEATURES ......................12 7 INSTALLATION & CONNECTIONS ................16 8 ELECTRICAL INSTALLATION & EARTHING .............. 17 9 COMMISSIONING &... -
Page 3: Product Overview
PRODUCT OVERVIEW Product Description The iBolt range consists of a single pump unit and single, twin and three pump booster sets comprising centrifugal pump(s) and electronic control. Application The Aquaboost iBolt range is designed to meet the demand of pressurised systems in domestic applications where the existing mains water supply is insufficient. -
Page 4: Warnings
WARNINGS • This pump/pump set must not be used for any other application without the written consent of Stuart Turner Limited. • This appliance can be used by adults aged from 18 years and above and persons with reduced physical, sensory or mental capabilities or lack of... - Page 5 • If the supply cord is to be changed or is damaged, it must be replaced with a special cord assembly available from Stuart Turner or one of their approved repairers. Please read installation details carefully as they are intended to ensure this product provides long, trouble free service.
-
Page 6: Checklist
CHECKLIST IMPORTANT: With the appliance removed from its packaging check for any damage prior to installation. If any damage is found contact Stuart Turner Ltd within 24 hours of receipt. iBolt Pump Figure 1 Item Description iBolt pump Instruction guide... - Page 7 iBolt Single Pump Booster Set Figure 2 Item Description iBolt booster set Instruction guide Your product may vary slightly from the illustration above.
- Page 8 iBolt Twin Pump Booster Set Figure 3 Item Description iBolt booster set Instruction guide Your product may vary slightly from the illustration above.
- Page 9 iBolt Three Pump Booster Set Figure 4 Item Description iBolt booster set Instruction guide Your product may vary slightly from the illustration above.
-
Page 10: Important - Read Before Commencing Installation
IMPORTANT - READ BEFORE COMMENCING INSTALLATION Water Temperature This unit is designed to pump cold water only which should not exceed the following values: The maximum allowable water temperature is 23 °C. The minimum allowable water temperature is 4 °C. Pipework - General Do not drill holes or put fastenings into the iBolt tank, this will cause leakage. -
Page 11: Location - General
LOCATION - GENERAL • Access: For emergencies and maintenance the pump must be easily accessible. • Protection: The iBolt must be located in a dry, frost free area. The iBolt must not be installed in a loft space. • Ventilation: Ensure an adequate air flow to cool the iBolt. Separate the iBolt from other appliances that generate heat. -
Page 12: Key Features
KEY FEATURES iBolt Pump Figure 4 ITEM DESCRIPTION iBolt Pump & Variable Speed Controller... - Page 13 iBolt Single Pump Booster Set Figure 5 ITEM DESCRIPTION iBolt Pump & Variable Speed Controller Nipple Non Return Valve Union Ball Valve 5 Way Connector Isolation & Drain Valve Pressure Gauge M / F Union 8 Litre Pressure Vessel Base Plate Union Ball Valve Pressure Transducer Isolation Valve...
- Page 14 iBolt Twin Pump Booster Set Figure 6 ITEM DESCRIPTION ITEM DESCRIPTION Base Plate Flow Through Isolating & Drain Valve iBolt Pump & Variable Speed 24 Litre Pressure Vessel Controller Suction Manifold Isolation Valve Union Ball Valve Pressure Transducer Nipple Plug Non Return Valve Junction Box Union Ball Valve...
- Page 15 iBolt Three Pump Booster Set Figure 7 ITEM DESCRIPTION ITEM DESCRIPTION Base Plate Plug iBolt Pump & Variable Speed Pressure Gauge Controller Union Ball Valve Flow Through Isolating & Drain Valve Non Return Valve Reducing Bush Nipple Junction Box Discharge Manifold Plug Plug 24 Litre Pressure Vessel...
-
Page 16: Installation & Connections
INSTALLATION & CONNECTIONS Water Connection The iBolt is to be permanently connected to a cold water storage tank using rigid pipe or suitably sized and rated flexible hose to comply with current building and plumbing regulations. Ensure there is a demountable joint in the pipe to allow the removal of the iBolt if needed. -
Page 17: Electrical Installation & Earthing
ELECTRICAL INSTALLATION & EARTHING Regulations • The electrical installation must be carried out in accordance with the current national electrical regulations and installed by a qualified person. Safety • RCD’s/ELCB’s are not recommended for use with variable speed drives/motors. If an RCD is mandatory use type B RCDs. •... - Page 18 Adjacent Pipes • Adjacent suction and delivery pipes should be fitted with earthing clamps in accordance with current regulations (Figure 7 Earth continuity connections). Figure 8 Earthing • This appliance must be earthed via the supply cord, which must be correctly connected to the earth point located in the terminal box.
- Page 19 8.10 Wiring of Connection Unit • WARNING: This appliance must be earthed. • The wires in the mains lead (supply cord) are coloured in accordance with the following code: Green and Yellow: Earth Blue: Neutral Brown: Live As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your connection unit proceed as follows: The wire which is coloured green and yellow must be connected to the...
- Page 20 8.11 Wiring Diagrams Connection Master & Slave Communication, Pressure Transducer and External Level Sensor Use cables with reinforced isolation. Unscrew the cover and loosen the PG located on the lateral side of the plastic body. Insert the cord through the PG. Remove the connector from its housing.
- Page 21 8.12 iBolt (Twin Controller) Figure 10...
- Page 22 8.13 iBolt (Three Controller) Figure 11...
- Page 23 If the supply cord is to be changed or is damaged, it must be replaced with a special cord assembly available from Stuart Turner or one of their approved repairers.
-
Page 24: Commissioning & Starting
COMMISSIONING & STARTING Pump Controller Figure 12 LCD screen. Shows the pressure in working mode. MANUAL START-STOP pushbutton. Pushbutton for ENTER or EXIT menu. Pushbuttons for changing programming values showed in the LCD screen (1). ENTER for saving programmed values. Every press is succeeded by a new field of the CONFIGURATION MENU. - Page 25 the pump stopped or when the device is not connected. D. AUTOMATIC green: it is bright in AUTOMATIC mode. When it is intermittent in MASTER&SLAVE mode it means that this device will be auxilliary in the following cycle. ON/OFF: Change from AUTOMATIC to MANUAL mode or vice versa.
- Page 26 Key Features • ON-BOARD frequency inverter for pump control. • Control and safety system against over-intensities. • Control and safety system against dry operation. • ART function (Automatic Reset Test). If the device has been stopped due to the action of the safety system against over- current, the ART tries to connect the pump, with a programmed periodicity because the water supply could have been restored.
- Page 27 Classification and Type According to EN: 60730-1 and EN:60730-2-6 this unit is a control electronic device for pressure groups, with flexible cable for permanent assembly type Y, action type 1Y (transistor output). Operating value: flow 2.5 l/min. Degree of contamination 2 (clean environment). Software Class A. Impulse rating voltage: cat II / 2500V.
- Page 28 Configuration Use ▲▼ to change the values and press ENTER for validation. To quit the configuration sequence press MENU. After every press of the ENTER key the different screens that constitute the configuration sequence will be displayed To start the sequence of configuration press MENU during 3”...
- Page 29 EXTERNAL LEVEL SENSOR If the installation does not have a level probe press ENTER to validate NO. If the installation has a level probe, use keys ▲▼ to change NO to YES SYSTEM OPERATING PRESSURE Use keys ▲▼ to modify the initial value (2 bar). WARNING: The input pressure must be at least 1 bar lower than the maximum pressure of the pumps.
- Page 30 9.10 Screen Display Being the unit in automatic mode (LED AUTO ON) by pressing ▲ can be displayed several operation parameters. Where: Pset is the set pressure or target pressure in bar. Pbar is the instantaneous lecture of pressure in bar. Hz is the rotation frequency of the motor in Hz.
- Page 31 9.11 Expert Menu There is normally no need to adjust these values, they are factory set. Using ▲▼ we can change the values and press ENTER for validation. To quit the configuration sequence press MENU. After every ENTER the messages of the configuration sequence will be displayed.
- Page 32 Carefully check pump and pipework for leaks whilst pump running and stationary before leaving the installation unattended. 9.16 For Further Technical Support Phone the Stuart Turner TechAssist team on +44 (0) 800 31 969 80. Our staff are trained to help and advise you over the phone.
-
Page 33: Maintenance
MAINTENANCE 10.1 Pressure Vessel The pressure vessel should be checked once every 12 months to have its pre- charge checked or replenished, this should be carried out as follows: Isolate pump electrically. Remove the front cover. Isolate the water supply by closing the appropriate isolating valves. -
Page 34: Trouble Shooting
TROUBLE SHOOTING 11.1 Alarms (Single Pump Systems) In case of simultaneous alarms, quit the automatic mode and go to manual mode, pressing the pushbutton AUTOMATIC ON/OFF (led light PUMP will turn off). Using key ▲▼ will be displayed the successive alarms. Once visualized, for leaving the menu, press ENTER returning to MANUAL mode. - Page 35 A2 OVER-INTENSITY ☼ Failure verification ● Final failure DESCRIPTION: the pump is protected against over currents by mean of the intensity values established in the installation menu. These over currents are produced generally by dysfunctions in the pump or in the electric supply. SYSTEM REACTION: when detecting the thermal failure, the pump will be automatically stopped.
- Page 36 A6 EXCESSIVE TEMP ● Final failure DESCRIPTION: the system is cooled by the motor fan to keep the INVERTER in optimum working conditions. SYSTEM REACTION: if an excessive temperature is reached the own system leaves the inverter out of service and as consequence the pump too. SOLUTION: verify the temperature environment should be under 50 ºC.
- Page 37 11.2 Alarm Installation Master-Slave A10 COMUNICA (Failure verification) DESCRIPTION: If you have configured a Master-Slave or Channel Bus system and communication cable is disconnected or there is a bad connection, the system stops. SYSTEM REACTION: The Master-Slave system stops and starts to operate individually.
- Page 38 11.4 Register of Operational Data and Alarms By using simultaneously MENU + ▲ during 3” is acceded to register of operation data and alarms, by mean of ENTER we can advance through the sequence, once finished the sequence we come back to the main display. Sequence: REGISTER HOURS Counter of total time that the pump has been operating.
-
Page 39: Product Warranty
+44 (0) 800 31 969 80 You should obtain appropriate insurance cover for any loss or damage which is not covered by Stuart Turner Ltd in this provision. Please record here for your reference: TYPE NO. -
Page 40: Declaration Of Conformity
AND MANUFACTURER HENLEY-ON-THAMES, OXFORDSHIRE RG9 2AD ENGLAND. Signed ................Engineering Manager Stuart Turner are an approved company to BS EN ISO 9001:2015 Stuart Turner Ltd, Henley-on-Thames, Oxfordshire RG9 2AD ENGLAND Tel: +44 (0) 1491 572655 Fax: +44 (0) 1491 573704 info@stuart-turner.co.uk www.stuart-turner.co.uk Issue No.
