ATTENTION: Max Time must be set at 20.0 sec.
5) Min Time - Minimum Time: You can set this time from 0.1 sec to 'Max time - 0.1s'. To disable the
function select OFF by pressing
Torque reached below the minimum time won't activate the torque signal and will result in an error
signal. "Below minimum time" will be displayed on the status bar and the red led will light up. You will
hear two beep sounds, too.
- - - - - - - - M E N U - - - - - - - -
6 ) M a x
 7 ) A u t o
 8 ) M i n
6) Max time - Maximum time: You can select the maximum time of tightening. You can set from 'Min
time + 0.1s' to 20.0 sec.
You also can set the Maximum time to OFF by pressing the
of 20.0s. In this case the screwdriver turns without any time limit.
ATTENTION: If torque isn't reached by the maximum time, the screwdriver will stop. "Over maximum
time" will be displayed on the status bar and the red led will light up. You will hear two beep sounds, too.
7) Auto Rev: This option will automatically start a reverse after a torque reached/ correct screw signal. You
can set time from 0.1 to 20.0 sec.
To disable the function select OFF by pressing
ATTENTION: During the reverse, it is necessary to keep the lever or the start signal pressed as long as it
won't stop. "Correct screw" will be displayed on the status bar and a green led will light up. You will
hear one beep sound, too. In case the lever is released before the end of the reverse, "unfinished screw"
will be displayed and a red led will light up. You will hear two beep sounds, too.
8) Screws number: The EDU2AE/FR can act as screw counter. You can set the number of screws from 1 to
99. To disable the function select OFF by pressing
If the number of correct screws is equal to the number of set screws "Program end" will appear on the status
bar and the yellow led will light up. If the Press OK function is disabled, "Program end" will automatically
disappear at next screwing or when you enter the menu. Otherwise, press OK at the end of each program.
ATTENTION: Every time you enter the menu, the number of screws resets to zero.

Unit Options

- - - - O P T I O N S - M E N U - - - -
O K c h a n g e
 1 ) L a n g u a g e :
2 ) V e r s i o n s
1) Language: This option allows to select among 4 languages: English, French, German, Italian, Spanish
and Portuguese.
:
2) Versions in this screen you can see the versions of boards inside the unit.
Vers. 210920
as many times as needed. (Min time = 0).
t i m e :
r e v :
t i m e :
as many times as needed.
as many times as needed.
E S C
2 0 . 0 S
o f f
o f f
button when you have reached the value
q u i t
E N
