TP-Link Omada DS105G-M2 Installation Manual page 2

Specifications
General Specifications
IEEE802.3i, IEEE802.3u, IEEE802.3ab,
Standard
IEEE802.3bz, IEEE802.3x, IEEE802.1p
Protocol CSMA/CD
100Base-TX: UTP category 5 cable or above
(max. 100 m)
1000Base-T: UTP category 5e cable or above
Network Media (Cable)
(max. 100 m)
2.5GBase-T: UTP category 5e cable or above
(max. 100 m)
5/8 100 Mbps/1 Gbps/2.5 Gbps Auto-Negotiation
Interface
RJ45 Ports
DS105G-M2: 25 Gbps
Switching Capacity
DS108G-M2: 40 Gbps
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically aging
100Base-TX: 148810pps/Port
Frame Forward Rate 1000Base-T: 1488095pps/Port
2.5GBase-T: 3720238pps/Port
Wall mountable
Yes
Distance bewteen DS105G-M2: 52 mm
mounting holes
DS108G-M2: 110 mm
Environmental and Physical Specifications
Operating Temperature 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Operating Humidity 10% to 90% RH non-condensing
Storage Humidity 5% to 90% RH non-condensing
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and
other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and
(EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/.
UK declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and
other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical
Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
Frequently Asked Questions (FAQ)
Q1. The Power LED is not lit.
The Power LED should be lit when the power system is working normally. If
the Power LED is not lit, check as follows:
A1: Make sure the power adapter is connected to the switch with power
source properly.
A2: Make sure the voltage of the power supply meets the requirements of
the input voltage of the switch.
A3: Make sure the power source is ON.
Q2. The right and left LED are not lit when a device is
connected to the corresponding port.
It is recommended that you check the following items:
A1: Make sure that the cable connectors are firmly plugged into the switch
and the device.
A2: Make sure the connected device is turned on and works normally.
A3: The cable must be less than 100 meters long (328 feet).
To ask questions, find answers, and communicate with
TP-Link users or engineers, please visit
https://community.tp-link.com to join TP-Link Community.
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
Safety Information
Keep the device away from water, fire, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service,
please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Place the device with its bottom surface downward.
Please read and follow the above safety information when operating the device. We
cannot guarantee that no accidents or damage will occur due to improper use of the
device. Please use this product with care and operate at your own risk.
