Hearth & Home CFTF-32 Installation Instructions

CFTF-32, CFTF-36, CFTF-42 Decorative Fronts
Leave this manual with party responsible for use
and operation.
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and must be installed for
the protection of children and other at-risk
individuals.
WARNING! Risk of Fire! Combustible materials MUST
NOT overlap or be placed under a surround.
WARNING! Risk of Fire! DO NOT apply combustible
materials beyond the minimum clearances. Comply with
all minimum clearances to combustibles as specified.
Overlapping materials could ignite and will interfere with
proper operation of decorative fronts.
CAUTION! Do not install damaged components.
Contents:
• Decorative Front Assembly
(Inner Decorative Front Assembly & Outer Decorative
Front Trim)
• Glass Vanity Panel
(Ships secured to back of decorative front assembly)
Verify and remove contents from packaging before
beginning installation.
Hearth & Home Technologies • CFTF-32, CFTF-36, CFTF-42 Decorative Front Instructions • 2491-925 Rev. H • 11/22
Installation Instructions for all available color choices
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.

Preparation:

Note: See appliance Installation Manual for specific fin-
ishing methods.
Overlap Fit Finishing: 0-1 Inch
Inside fit Finishing: 1-6 Inches
The CFTF decorative front can be installed with or without
the included outer decorative front trim. Determine wheth-
er or not to install the outer decorative front trim using the
conditions listed on page 2.
1. Remove decorative front assembly and manual bag
assembly from the packaging. Place the decorative
front assembly face down on a clean, protected work
surface.
2. Remove the three screws that secure the glass van-
ity panel to the back of the decorative front. Discard
screws. See Figure 1.
SHIPPING BRACKET
SCREWS
REMOVE SCREWS
AUXILIARY HANGING BRACKETS
SHIP ATTACHED TO APPLIANCE
Figure 1. Decorative Front Assembly - Shown as Shipped
SHIPPING BRACKETS
TOP VANITY PANEL
VANITY
PANEL
