Installation
3.1
Preparing for Installation
Figure 4 shows a typical installation configuration for the AIS transceiver. Please take the time to familiarise yourself with the system
elements and their connections prior to attempting installation.
Chartplotter
Power in
Switch
Figure 4
Typical installation configuration
In addition to the items provided with your AIS transceiver the following items will be required for installation:
USB
GPS antenna
AIS Class B
transceiver
NMEA 2000
VHF antenna
(optional)
Installation
Page 10
