Camera operation

■ Accessing a connected camera

A
When a camera is connected to the
DVR
The camera can be called from both the channel
and number.
A-1 Calling from the channel
① Press the CH/CAM button.
The selected channel/camera number
disappears and the cursor in the CH line blinks.
② Enter the channel of the camera (i.e.: 5)
to view using the numeric buttons and
press the ENTER button.
The image on the monitor screen switches to
camera 5.
DVR 1
CH
-
CAM No.
A-2 Calling from the camera number
① Press the CH/CAM button twice.
The cursor moves to "CAM No." line.
② Enter the camera number (i.e.: 5) to
view using the numeric buttons and
press the ENTER button.
Although the monitor image does not change,
camera 5 can be operated.
A
Refer to " Automatically switching the
camera image connected to the DVR to the
DVR's main monitor when calling the
address configured to the camera" to
automatically switch the monitors. (P31)
DVR 1
CH
CAM No.
-
DVR 1
CH 5
CAM No.
DVR 1
CH
CAM No. 5
B
When only a camera is connected

Calling from the camera number.

① Press the CH/CAM button.
The selected camera number disappears and
the cursor blinks.
CAM No.

② Enter the camera number (i.e.: 5) to

view using the numeric buttons and

press the ENTER button.

The image on the monitor screen switches to

camera 5 and the camera can be operated.
CAM No.
For example, the various protocols cannot be called
if they are not configured as follows. (P24)
• Configuring "- - -" as the protocol of Line V
LINES SETUP
ºLine V
Line A
Line B
• Configuring "Sanyo SSP" as the protocol of
Line A
LINES SETUP
Line V
ºLine A
Line B
-
5
LINE V
ºProtocol:---
Baudrate:---
LINE A
ºProtocol:Sanyo SSP
Baudrate:19200
40
Operation
