Laptop Desk Stand
Instruction Manual
SKU: STAND-V001FGL
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v001fgl
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V001FGL
Summary of Contents for Vivo STAND-V001FGL
- Page 1 Laptop Desk Stand Instruction Manual SKU: STAND-V001FGL Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v001fgl GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22lbs Failure to do so may result in serious injury. (10kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Attach Mounting Plate (I) to Pole (A) using M6x16mm Screws (S-D) and 4mm Allen Wrench (T-A). Connect Plastic Spacer (H) to the bottom of Mounting Plate (I).
- Page 4 STEP 2 Remove protective film from Foam Pad (F). Apply to Weighted Plate (G) on the side without the tapered holes. Ensure the holes on Foam Pad are properly aligned with the Weight Plate before applying. Assemble Pole (A), Glass Base (B), and Weighted Plate (G) using M6x20mm Screws (S-C) and 4mm Allen Wrench (T-A).
- Page 5 STEP 3 Slide Cover (J) onto Mounting Plate (I) making sure the posts on Cover are aligned with the holes on Plate. Remove the protective film from Feet (K) and apply to Glass Base (B). Remove the protective film from Felt Pads (O) and apply to Feet (K). STEP 4 Slide Arm (C) onto Pole (A) and tighten Arm (C) using 5mm Allen Wrench (T-B).
- Page 6 STEP 5 Attach Laptop Tray (E) to VESA Plate (D) using M4x8mm Screws (S-A), M4 Nuts (S-B), Wrench (T-C), and a Phillips screwdriver. STEP 6 Slide VESA Plate (D) onto Arm (C) and secure using M6 Security Nut (S-E).
- Page 7 ASSEMBLY COMPLETE Assembly is now complete. Place laptop on tray. ADJUST AS DESIRED Adjust the tilt joint on Arm (C) using 5mm Allen Wrench (T-B).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
