Summary of Contents for Titan PGD2875
- Page 1 Operator’s Manual PGD2875 www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com...
- Page 2 www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com...
-
Page 3: Table Of Contents
Table of Contents Introduction......................2 Safety Warnings ....................3 Main Parts…………………………………………………………………………….4 Preparation for Use…………………………………………………………………5 Operating Instructions..................7 Service and Maintenance.................8 Troubleshooting....................12 Key Product Data……………………………………………………………………13 Parts Diagrams………………………………………………………………………14 Warranty......................19 Contact Info......................20 www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com... -
Page 4: Introduction
19 of this manual). We suggest that you read the warranty information and fully understand its coverage and your responsibilities of ownership. To register your Titan Post Driver, simply fill out and return the warranty registration card enclosed with your machine. -
Page 5: Safety Warnings
Safety Warnings 1. Always follow proper operation and maintenance instructions. 2. Always use approved Personal Protective Equipment (PPE). Operators and all other persons in the immediate working area must wear protective equipment as well. Noise emitted from the machine while working can reach above 100 decibels, which can also harm others in close proximity. We recommend the following personal protective equipment: a. -
Page 6: Main Parts
Main Parts Part Name Part Name Part Name Oil Level Gauge Handle Starter Choke Valve Gas Tank Gas Cap Fuel Bubble Air Filter Positioning Sleeve Dampening Spring Handle Sleeve Grease Cap Hammer Case Serial No. Location Throttle Limit Screw Combination Switch Throttle Switch Stop Switch Piling Socket Sleeve... -
Page 7: Preparation For Use
Preparations For Use Installing Inner Pile Head If the inner pile head (#49) is not pressed on the shock (#43) at this time, you must slide the inner pile head inside the piling socket and match the small side with the shock. Tap the inner pile head a few times to make sure it is connected to the shock. - Page 8 Adding Engine Oil 1. Before the first use, drain any oil that might be inside the crankcase, and refill using the bottle of oil that is supplied with your driver. We suggest adding 2.7 US ounces and then checking the oil. Place the oil level gauge back in the oil filler neck, BUT DO NOT SCREW IN WHILE CHECKING THE OIL LEVEL, OR YOU WILL GET A FALSE READING.
-
Page 9: Operating Instructions
Operating Instructions Starting 1. The engine on the PGD2875 is inclinable, which means it can be stored and operated in any direction. BEFORE STARTING, the driver needs to be in the horizontal position for 5 minutes. 2. Before starting the post driver, press the transparent, semi-circle fuel bubble repeatedly until the carburetor is filled with fuel. -
Page 10: Service And Maintenance
Service and Maintenance Air Filter Maintenance After the driver has been used for some time, dirt and dust particles can block the flow of air, which will result in reduced power and increased oil consumption. It is necessary to clean the air filter regularly. The cleaning cycle is usually every 3 months or every 25 hours of operation. - Page 11 Spark Plug Maintenance If the spark plug has too much carbon deposit, it will result in poor engine performance. It is necessary to regularly maintain and adjust the spark plug every year or every 100 hours of operation. 1. Remove the spark plug as shown. 2.
- Page 12 Lubrication of Gearbox and Impact Parts After 40 hours of use, open the gearbox cover, and add 75 Series Grease to the connecting rod to fully lubricate the machine as shown below. www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com...
- Page 13 Maintenance Schedule This schedule is based on operating the post driver under normal conditions. Under more strenuous conditions, such as a dusty environment or long work hours, the maintenance cycle should be adjusted accordingly. Outlook Check (state, √ √ tightness of The Whole Machine screws) √...
-
Page 14: Troubleshooting
Continue until all oil has been removed from the cylinder. *WARNING: Oil may shoot from the spark plug hole as you pull the starter rope. If these steps do not address your issue, call Titan Post Drivers at (702) 293-4262 for further assistance. www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com... -
Page 15: Key Product Data
Key Product Data 4-stroke, single-cylinder, air-cooled 140FA gasoline Engine Type engine Model PGD2875 LxWxH (inches) 25" x 10" x 13" Fuel 86 octane, unleaded gasoline or higher Displacement 37.7 cc Fuel Tank Volume 0.17 US gal 2.71 US oz Oil Capacity... -
Page 16: Parts Diagrams
Exploded View of PGD2875 Driver www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com... - Page 17 Parts List and Exploded View of PGD2875 Driver Part Name Part Name Inner Hexagon Cylindrical-Head Screw 140FA Gasoline Engine M6×20 Driven Disk Cylinder Gaskets Inner Hexagon Cylindrical-Head Screw M5×12 Impact Connecting Rod Elastic Washer 5 Impact Piston Bearing Pressing Plate...
- Page 18 Part Name Part Name Switch Handle Guide Piling Socket Sleeve Sleeve Connecting Thread Head Step Nut Handle Spring 38x27Xφ2.5 Handle Sleeve Handle Soft Sleeve Handle Nut Positioning Sleeve Handle Frame Handle Frame Soft Sleeve Inner Hexagon Cylindrical-Head Screw M6×40 Combination Switch www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com...
- Page 19 Exploded View of 140FA Engine www.ChainLinkFittings.com | (800) 878-7829 | Sales@ChainLinkFittings.com...
- Page 20 Parts List and Exploded View of 140FA Engine Parts No. Name Parts No. Name Carburetor Gasket Socket M5X15 Cover Carburetor Socket M5×12 Air Cleaner Housing Cylinder Head Cover Socket M5x22 Filter Filter Element Inner Head Cover Air Cleaner Cover Screw M4x8 First Piston Ring Head Cover Grommet Second Piston Ring...
-
Page 21: Warranty
Warranty Titan Post Drivers will warrant to the original purchaser, who purchases the equipment in new condition and in its original packaging from an authorized dealer, that its gas-powered post driver will be free from defects in workmanship and materials for a period of one (1) year. This warranty period will commence on the date of retail purchase by the original purchaser.
