Page 2: Main Specifications
Main Specifications : Overall assembled size : W9.15 x L11.97 x H3.0 (m) / 30 x 39.27 x 9.84(ft) Ridge Peak Height : 3 m / 9.84ft + container height Prior to assembly Please read the instructions carefully before installation. It is very important to follow your local safety regulations and industry standards during installation. -
Page 3: Structure Diagram
Structure diagram ▶ W W W . T M G I N D U S T R I A L . C O M P 2 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9... - Page 4 TMG-ST3041CE Part List Picture Description Length Quantity Peak arch tube L1734mm Middle rafter tube L2890mm Shoulder tube L1784mm Shoulder tube L1784mm Middle truss baseplate W150xL200mm Left corner baseplate W150xL200mm (front and rear truss) Right corner baseplate W150xL200mm (front and rear truss)
- Page 5 Top cover tension tube L490mm Bolt M8x60 M8x60mm M8x70mm Bolt M8x70 Hex bolt M10x30mm M10x30mm Top cover φ8x80m Braided rope (80m) Scratch resistant tape φ32 Water plug ▶ W W W . T M G I N D U S T R I A L . C O M P 4 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 6 Step 2 : Place the containers making sure they are parallel and the correct width apart. Make sure there is a gap of about 3 feet around the building. the center point of the round pipe of the base is the reference point, and the diagonal X and Y must be equal.
- Page 7 Step 3 : Connect all trusses. Front and rear trusses (4 trusses). Part Part ▶ W W W . T M G I N D U S T R I A L . C O M P 6 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 8 Middle trusses (6 trusses). Part Part ▶ W W W . T M G I N D U S T R I A L . C O M P 7 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 9 Lay down all (10) trusses on the ground when the assembly is all completed and before moving to next step, and then wrap (#15) around the sharp points of the joint to avoid friction between the fabric and the interface, resulting in fabric damage. Part ▶...
- Page 10 Step 4 : Put up all trusses. Install each truss on the base tube. Use hex bolt (#11) to secure the truss to the base tube firmly. We recommend to use a crane or forklift to lift the truss and have 2 to 3 people on site to work together.
- Page 11 Step 5 : Install cross tubes and wire ropes. Part Part ▶ W W W . T M G I N D U S T R I A L . C O M P 1 0 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 12 Overall structural inspection : Check all components and trusses to ensure the entire structure is rectangular as specified in (picture1). All trusses must be 90 degrees straight up from the container. Secure and tighten all bolts and nuts on this step. But do not over tie! Otherwise you might damage the tubes or components.
- Page 13 Part Rope Shear Size 2000mm ▶ W W W . T M G I N D U S T R I A L . C O M P 1 2 / 1 5 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 14 Step 7 : Tension the cover on the structure from both sides. Insert tension tubes (#9) slowly into the bottom groove pocket on both long sides. Add the water plug (#16) on the first tension tube to avoid tearing the fabric and add one to the end of last tube as well.
- Page 15 Step 8 : Install ratchet straps. Stretch and adjust the cover from left and right, back and forth, to make sure it is square and centered. Cut the groove pocket where it aligns with ratchet (#7A), and use strap (#7B) to pull tension tube (#9) to ward the ratchet and secure it.
-
Page 16: After Installation
After Installation Walk around and inspect the building periodically to make sure the parts are firmly fixed and the whole building is well supported. Check all bolts and hardware connectors to make sure they are in place and tightened. Check the base plates, adjust the ropes if necessary and clean the cover regularly.
