Summary of Contents for Doughpro Proluxe DP3300BZ
- Page 1 Operations Manual Model: DP3300BZ Electromechanical Dough Press formerly DOUGHPRO. New Name. Same Quality. Superior Service. proluxe.com Rev 5...
-
Page 2: Installation
Doughpro shall not be liable for the injury, loss or damage, direct or Installation consequential, arising out of the use or the inability to use the product. - Page 3 General Specifications 1. Piston Activation Buttons (2) 6. Thickness Control Dial – 2. On/Off Power Switch Controls the thickness of the dough, (varies depending on size 3. Digital Temperature & Time Control – 0-200°F Temperature of dough ball). Setting. 7. Lower Platen – Dough is placed 4.
- Page 4 Safety Summary 3. Counter – Cycle counter counts WARNING the number of applications from In case of power cord damage, 1 to 9999 (see additional Notes – do not attempt to repair or Counter). replace the power cord. Contact the manufacturer or the local Controller Operation distributor.
-
Page 5: Additional Notes
1. Apply a quick spray of a good be programmed to display either water based food release on the °F or °C. To change: Press the lower platen. Doughpro offers MODE button until the its own food release spray temperature is displayed, then... - Page 6 Note The timer or buzzer may be stopped while the handle is in the down position by pressing both the DOWN ( ) arrow button and the UP ( ) arrow button simultaneously. The timer will automatically reset after the handle is raised.
- Page 7 *2 full squeezes from grease gun. Preventative Maintenance Suggestions The Doughpro DP3300 machines are Service Problems: relatively maintenance free. For a long and trouble-free life, the following Contact our factory or approved service preventative maintenance should be agency (U.S.
- Page 8 DOUGHPRO DP3300 Trouble Shooting Guide Symptom Probable Cause Action to be Taken Ref. #'s on Explosion Drawing Power Button on Digital Controller Power Cord is not plugged in. Plug power cord into wall 's face is depressed but doesn’t turn...
- Page 9 DOUGHPRO DP3300 Trouble Shooting Guide If setpoint is reached but slighty off Offset may need to be calibrated and Must call (800) 624-6717 ext. 129 in temperature. adjusted. for confidential instructions. Heater Platen overheating If the Relay (depending the year of...
- Page 11 PARTS LIST FOR MODEL DP3300BZ REF. # PART NAME 120 ~ AC HOUSING, INSTRUMENT 110330022 SCREW, HOUSING SF142034 WASHER LOCK (HOUS. SUPPORT STRAP) WL516 MOTOR/HOUSING SUPPORT STRAP 1101017130 ACTUATOR (MOTOR) 1101017601 SENSOR (TEMP. CONTROL) 110949110 PISTON ASSEMBLY 11086074 LOCKING BOLT, ADJUSTMENT BH51618134G5 BOLT, LEVEL ADJUSTMENT 1109367 SHROUD, UPPER PLATEN 11072936...
- Page 12 PARTS LIST FOR MODEL DP3300BZ REF. # PART NAME 120 ~ AC SLIDE PLATE THICK / THIN ADJUSTMENT 11072085 MICRO SWITCH 1101017044 CAM PLATE THICK / THIN ADJUSTMENT 11072084 SCREW, CAM PLATE THICK / THIN ADJUST SR4401316 MICRO SWITCH ADJUSTING PLATE 700213 SCREW, MICRO SWITCH ADJ. PLATE SP83214 MICRO SWITCH V15G31C25K...
-
Page 14: Warranty And Return Policy
Rev 12916 Warranty & Return Policy Proluxe warrants all products manufactured by it against defects in workmanship or materials from the date of purchase for a period of Warranty period (1) year on parts and labor. This warranty applies to only equipment purchased and used in the United States. shall begin when equipment ships.
