Arm Type Blood Pressure Monitor
Model:
INSTRUCTION MANUAL
PLEASE READ THIS INSTRUCTION MANUAL COMPLETELY
BEFORE OPERATING THIS UNIT
EN
BPM67
MDSS GmbH
Schiffgraben 41
30175 Hannover Germany
AViTA Corporation
9F., No. 78, Sec. 1, Kwang Fu Rd.,
San Chung Dist., New Taipei City 24158, Taiwan,
China
China, AViTA(WUJIANG)
Importer
Distributor
RoHS REACH
Advertisement
Table of Contents
Related Manuals for Avita BPM67
Summary of Contents for Avita BPM67
- Page 1 Arm Type Blood Pressure Monitor Model: BPM67 INSTRUCTION MANUAL PLEASE READ THIS INSTRUCTION MANUAL COMPLETELY BEFORE OPERATING THIS UNIT RoHS REACH MDSS GmbH Schiffgraben 41 30175 Hannover Germany AViTA Corporation 9F., No. 78, Sec. 1, Kwang Fu Rd., San Chung Dist., New Taipei City 24158, Taiwan,...
-
Page 2: Table Of Contents
Contents Intended Use........................1 Important Information before Use ................2 Product Identification ..................... 6 Description of LCD Display ................... 7 Battery Installation ......................8 Setting the Date and Time .................... 9 Placement of the Pressure Sleeve................10 Measurement of Pulse Rate and Blood Pressure ..........12 Hypertension Indicator .................... -
Page 3: Intended Use
Intended Use The product automatically measures human being‟s Systolic, Diastolic blood pressure and pulse rate by oscillometric method. The measurement results are displayed on the LCD. Measurement position is at human being‟s upper arm. The intended use of this over-the-counter device is for adults with upper arm circumference ranging from 220 mm to 420 mm (Approx.8.7 ~ 16.5 inches) and for home use. -
Page 4: Important Information Before Use
Important Information before Use 1. Blood pressure measurements should only be interpreted by a physician or a trained health care professional who is familiar with your medical history. Through regular use of this device and recording of your measurements, you can keep your physician informed of the changes in your blood pressure. - Page 5 (every 3 years). To obtain the service please contact AViTA Corp. for the address of the repair location. Enclose with the Proof of Purchase. Include $10.00 USD for the return shipping and handling.
- Page 6 CAUTION: • Beware of blood flow interference and resulting harmful injury to the patient caused by continuous cuff pressure. • While using monitoring ME equipment and blood pressure monitor simultaneously being used on the same limb, pressurization of the cuff may cause monitoring ME equipment temporarily dysfunction. •...
- Page 7 • Do not use the cuff on people who have undergone a mastectomy. • Do not apply the cuff over a wound, as this can cause further injury. • Do not apply the cuff other then the original manufacturer provided. •...
-
Page 8: Product Identification
Product Identification Display Cuff Memory button (M key) Start/Stop button (Power key) Set button (S key) -
Page 9: Description Of Lcd Display
Description of LCD Display Low battery indicator WHO indicator Date & Time Irregular Heartbeat Symbol AF Symbol Memory Symbol Memory Set Heartbeat Symbol Pulse rate Inflation / Releasing air Systolic Pressure Diastolic Pressure User Symbol... -
Page 10: Battery Installation
Battery Installation Low battery warning: It is necessary to replace the batteries when the Low Battery symbol “ ” appears on the display, or when the display does not turn on after the POWER key is pressed. Replacing the Battery: 1. -
Page 11: Setting The Date And Time
Setting the Date and Time It is necessary to set the date and time for the device every time batteries are initially installed or replaced. To set the date and time, proceed as follows: • While in power off mode, press and hold the “S” key for at least 3 seconds to enter Date and Time setting procedure and the Year value will begin to flash. -
Page 12: Placement Of The Pressure Sleeve
Placement of the Pressure Sleeve It is important to avoid smoking, eating, taking medication, alcohol consumption or physical activity 30 minutes prior to taking a reading. If for any reason you are unable to or should not use your left arm, please modify the instructions for cuff application to your right arm. - Page 13 Note: If you are not comfortable with applying your cuff, please seek the assistance of another member of your household or work with your physician to practice the cuff application. Incorrectly applied cuffs may result in inaccurate readings.
-
Page 14: Measurement Of Pulse Rate And Blood Pressure
If there is an Error message after the measurement, please refer to Page 18 Error Codes Table. Note: 1. Users are recommended to use BPM67 daily at a fixed time, frequency of usage from 1 to 3 times can be suggested from physician or doctor‟s advice. -
Page 15: Hypertension Indicator
Hypertension Indicator This device features our unique Hypertension Indicator. The World Health Organization has established globally accepted standards for the assessment of high or low blood pressure readings. The below chart should be considered only as a guideline, always consult with your physician or health care professional to interpret your individual results. -
Page 16: Irregular Heartbeat Detector
Irregular Heartbeat Detector Your digital blood pressure monitor features an Irregular Heartbeat Detector. This feature allows users to accurately monitor blood pressure even if an irregular heartbeat should occur. When an irregular heartbeat is detected, the icon“ ”will appear on the display. Note: Please consult with your physician or trained healthcare professional for further information regarding an irregular heartbeat if this symbol... - Page 17 Note: 1. Please consult with your physician or trained healthcare professional for further information regarding an atrial fibrillation if this symbol appears frequently. 2. Even if the AF symbol does not appear, there is still a possibility of Afib.
-
Page 18: Memory Function
Memory Function Recalling Measurements in Memory: You can recall up to 100 measurements for each user, plus those average values stored measurements in memory to share with your physician or trained healthcare professional. If you press the M key, the unit will first display the average of last 3 currently stored measurements. - Page 19 Two users with one device This device is designed to be capable of recording the measurements of two people separately. To switch to the other user, please follow the steps below: 1. Press the “S” key while in power off mode and the user number will appear below the Date &...
-
Page 20: Error Codes
Error Codes Err Code Meaning Corrective Action No pulse or detect Take off heavy clothes and Err 00 pulses not enough. retry again. The cuff is not fastened correctly, The Arm cuff is not fastened cuff pressure leakage properly. Re-apply the cuff, Err 01 or inflation too low or and take a measurement... -
Page 21: Troubleshooting
Troubleshooting Problem Probable Cause Recommended Action Nothing appears in Batteries are drained. Replace all batteries with the display even new ones. when the power is Battery are not correctly Reinsert batteries in the turned on. aligned with terminals. correct position. Low Battery Batteries are drained. -
Page 22: Cleaning And Disinfecting
Cleaning and Disinfecting • Only use a soft, damp cloth to clean the monitor. Please do not use thinner, alcohol, detergents or solvents. • The cuff can be cleaned carefully using a slightly damp cloth and mild soap solution. Do not completely immerse the cuff in water. •... -
Page 23: Technical Specification
Technical Specification • Measuring range : Blood Pressure : 40~255 mmHg Pulse Rate : 40~199 beats/min • Calibration Accuracy: Blood Pressure : ± 3 mmHg Pulse rate : ± 4% of reading • Operating environment : 10°C~40°C 15% to 85% relative humidity (non-condensing) 700-1060 hPa ambient pressure •... -
Page 24: Emc Tables
EMC Tables BPM67 is intended for use in the electromagnetic environment specified below. The customer or the user of BPM67 must make sure that it is used in such an environment. Guidance and manufacturer‟s declaration - Electromagnetic emissions Professional healthcare... - Page 25 RF communications equipment (transmitters) and the BPM67 can be requested from supplier using the contact information provided in this manual. However, it is advisable to keep the equipment at an adequate distance of, at least, 0.5 m from...
-
Page 26: Explanation Of Symbols
Explanation of Symbols Symbol Definition The CE marking with the Registration Number of the Notified Body. This denotes the compliance of Regulation (EU) 2017/745 Medical Device Manufacturer Authorized representative in the European Community Date of manufacture (YYYY-MM-DD or YYYY-MM) Batch code (YYMMWWWW) Serial number (YYMWWWXXXXX) - Page 27 Humidity limitation Atmospheric pressure limitation Caution Consult the instruction for use Disposal information: Should you wish to dispose of the article, do so in accordance with current regulations. Details are available from your local authority. WEEE 2012/19/EU Directives This product fulfilling the requirements of the RoHS Directive RoHS 2011/65/EU.
- Page 28 You are legally required to dispose of the batteries. Importer Distributor Model Number Country of Manufacturer Unique Device Identifier Keep away from sunlight Electronic IFU available at http://www.avita.com.tw BPM67P-22580AV 2022-12-22...
