3
1
8"
0 1
E -SER I ES S ERI E S
SQ U ARE CO LL ECT I O NS
T O WEL BAR
MO DEL : 24 61 SQ 1 0
24 61 SQ 7 5
3
2
"
8
7
"
8
In stal lati on In stru cti on s
1.
Place the trim parts against the assigned wall location. Make sure the bar is leveled and the bar post
positions are correct. Mark with pencil the bar post flange positions and remove the trims.
bar post
2.
Using the Allen key provided, remove the mounting posts from the bar posts. Press the mounting
posts against the bar post flange positions on the wall and mark the screw hole positions.
NOTE: MAKE SURE THE ALLEN SCREW HOLE ON THE MOUNTING POST IS FACING DOWN
WHEN SECURING TO WALL.
INSTALLING ON WOODEN SURFACE
For wooden surface, the mounting post can be
secured by screwing the screws directly into the wall.
INSTALLING ONTO DRYWALL SURFACE
Using a drill, pre-drill holes for the anchors. Insert the
anchors into the wall. The mounting post can be
secured by screwing the screws into the anchors.
INSTALLING ONTO A SOLID SURFACE
Measure the dimensions carefully.
Using a drill,
pre-drill the holes.
Secure the mounting post by
screwing the screws into the wall.
WALL
holder post mark
mounting post
0 2
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Santec SQUARE 2461SQ10
Summary of Contents for Santec SQUARE 2461SQ10
- Page 1 E -SER I ES S ERI E S SQ U ARE CO LL ECT I O NS In stal lati on In stru cti on s T O WEL BAR MO DEL : 24 61 SQ 1 0 24 61 SQ 7 5 Place the trim parts against the assigned wall location.
- Page 2 I ns ta l l ati on In s tr u cti ons Press the left bar post against the mounting post. Align the bar post and secure it by tightening the set screw. Insert the towel bar into the secured bar post. Press the right bar post onto the right mounting post. Insert the right side of the towel bar into the right bar post.
