OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
MANUAL DE INSTRUÇÕES
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
HEAT & COOL MODEL
(REVERSE CYCLE)
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
P/N9315340016-01
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hiyasu ASH30UI
Summary of Contents for Hiyasu ASH30UI
- Page 1 OPERATING MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE FUNCIONAMIENTO MANUALE DI ISTRUZIONI ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ MANUAL DE INSTRUÇÕES РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ ROOM AIR CONDITIONER WALL MOUNTED TYPE HEAT & COOL MODEL (REVERSE CYCLE) KEEP THIS OPERATION MANUAL FOR FUTURE REFERENCE P/N9315340016-01...
-
Page 2: Table Of Contents
CONTENTS Fig. 1 SAFETY PRECAUTIONS ........En-1 ADJUSTING THE DIRECTION OF FEATURES AND FUNCTIONS ......En-2 AIR CIRCULATION ..........En-9 MANUAL NAME OF PARTS ..........En-3 SWING OPERATION ......... En-10 AUTO PREPARATION ............ En-4 COIL DRY OPERATION ........En-10 OPERATION ............En-5 CLEANING AND CARE ........ -
Page 3: Features And Functions
FEATURES AND FUNCTIONS INVERTER OMNI-DIRECTIONAL AIR FLOW (SWING OPERATION) At the start of operation, a large power is used to bring the room quickly to the desired temperature. Afterwards, the Three-dimensional control over air direction swing is possi- unit automatically switches to a low power setting for eco- ble through dual use of both an UP/DOWN air direction swing nomic and comfortable operation. - Page 4 NAME OF PARTS Fig. 1 Indoor Unit Fig. 6 Remote Control Unit 1 Operating Control Panel (Fig. 2) J SLEEP button 2 MANUAL AUTO button K MASTER CONTROL button L SET TEMP. button ( When kept on pressing the MANUAL AUTO button for more than 10 seconds, M COIL DRY button the forced cooling operation will start.
- Page 5 PREPARATION Load Batteries (R03/LR03 × × × × × 2) CAUTION! G Take care to prevent infants from accidentally swallowing batteries. Press and slide the battery compartment lid on the re- G When not using the Remote Control Unit verse side to open it. for an extended period, remove the batteries to avoid possible leakage and Slide in the direction of the arrow while pressing the...
-
Page 6: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 R). The indoor unit’s OPERATION Indicator Lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MASTER CONTROL button (Fig.6 K) to se- lect the desired mode. Each time the button is pressed, the mode will change in the following order. - Page 7 To Stop Operation Press the START/STOP button (Fig. 6 R). The OPERATION Indicator Lamp (red) (Fig. 3 5) will go out. About AUTO CHANGEOVER Operation G When AUTO CHANGEOVER operation first selected, the fan will oper- AUTO: ate at very low speed for about one minute, during which time the unit detects the room conditions and selects the proper operating mode.
- Page 8 TIMER OPERATION Before using the timer function, be sure that the Remote Control Unit is set to the correct current time ( P. 4). To Use the ON timer or OFF timer Press the START/STOP button (Fig. 6 R) To Cancel the Timer (if the unit is already operating, proceed to step 2).
- Page 9 SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP Timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER MODE button to select SLEEP button (Fig.
- Page 10 ADJUSTING THE DIRECTION OF AIR CIRCULATION G Adjust the up, down, left, and right AIR directions with the AIR DIRECTION buttons on the Remote Control Unit. G Use the AIR DIRECTION buttons after the Indoor Unit has started operating and the airflow-direction louvers have stopped moving.
- Page 11 SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING button (Fig. 6 U). The SWING Display (Fig. 7 d) will light. Each time the SWING button is pressed, the swing operation will change in the following order.
-
Page 12: Cleaning And Care
CLEANING AND CARE G Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! G Be sure the Intake Grille (Fig. 1 8) is installed securely. G When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. - Page 13 CLEANING AND CARE Air Cleaning Filter Installation Replacing dirty Air cleaning filters Replace filters with the following components (purchased 1. Open the Intake Grille and remove the Air separately). filters. G POLYPHENOL CATECHIN AIR CLEANING FILTER : UTR-FA13-1 G Negative air ions deodorizing filter: UTR-FA13-2 1.
- Page 14 TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the elec- WARNING! trical breaker or disconnect the power supply plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source.
-
Page 15: Troubleshooting
TROUBLESHOOTING Symptom Items to check See Page G Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE G Has there been a power failure? — G Has a fuse blown out, or a circuit breaker been tripped? G Is the timer operating? 7 - 8 G Is the Air Filter dirty? - Page 16 OPERATING TIPS Temperature and Humidity Range Dry Mode Heating Mode Cooling Mode Outdoor temperature About -10 to 43 °C About –15 to 24 °C About -10 to 43 °C Indoor temperature About 18 to 32 °C About 30 °C or less About 18 to 32 °C G If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to prevent internal circuit damage.
