Speco CVC-212PC Specifications

Specifications subject to change
Speco Technologies 200 New Highway, Amityville, NY 11701 Web: www.specotech.com
Toll Free: 1-800-645-5516 In Metro NY: 631-957-8700 Fax: 631-957-9142 or 631-957-3880
Door Mount Camera
CVC-212PC
(Black & White Camera)
CVC-812PC
(Color Camera)

Features

Looks like a normal peep-hole . . . . . . . . . . . . . . .Discreet surveillance
Single hole installation . . . . . . . . . . . . . . . . . . . . .Easy and quick implementation
Ultra wide angle coverage . . . . . . . . . . . . . . . . . .View area around the door and to the sides

Specifications

Resolution . . . . . . . . . . . . . . . . . .
Minimum Illumination . . . . . . . . . . .
Lens . . . . . . . . . . . . . . . . . . . . . .
Lens Angle of View . . . . . . . . . . . . .
Image Device . . . . . . . . . . . . . . . . .
Video Output . . . . . . . . . . . . . . . .
Video S/N Ratio . . . . . . . . . . . . . . .
Scanning Frequency . . . . . . . . . . . .
Number of Pixels . . . . . . . . . . . . . .
Electronic Shutter . . . . . . . . . . . . . .
Output . . . . . . . . . . . . . . . . . . . .
Power Consumption . . . . . . . . . . . .
Humidity . . . . . . . . . . . . . . . . . . .
Depth of Door Requirement
Operating Temperature
Housing . . . . . . . . . . . . . . . . . . . .
Power Supply . . . . . . . . . . . . . . . .
Dimensions . . . . . . . . . . . . . . . . . .
Camera
Power Supply
For more information contact us at:
Benefits
420 Line (B/W), 350 Line (color)
0.02 Lux (B/W), 1.0 lux (color)
2.5mm lens
110˚ Ultra wide angle of coverage
1/3" CCD image sensor
1.0 Vp-p into 75 ohm
Greater than 48 dB
15.75 kHz horizontal 60 Hz vertical
512 horizontal x 492 vertical
Auto 1/60 - 1/100,000 seconds
Video - BNC, power - DC jack
100 mA (B/W), 150 mA (color)
Within 95% RH
. . . . . . . 1 1/4" to 2" in depth
. . . . . . . . . . - 20˚ F to 122˚ F
Black
Regulated 12V DC power supply included
(UL and CSA listed)
2.75"L x 1.62"W x 1.62"H

Package Includes:

Mounting Hardware
Instructions
Warranty Card
